CFX-DIAMOND
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
- Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
- What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
Printed in U.S.A. Copyright 2002,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manu-
factured (mobile) home, where not pro-
hibited by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Heat-N-Glo dealer with any
questions or concerns. For the number of your nearest
Heat-N-Glo dealer, please call 1-888-427-3973.
Installers Guide
Underwriters
Laboratories Listed
593-900H 8/02
Advertisement
Table of Contents
Related Manuals for Heat-N-Glo CFX-DIAMOND
Summary of Contents for Heat-N-Glo CFX-DIAMOND
- Page 1 Printed in U.S.A. Copyright 2002, Please contact your Heat-N-Glo dealer with any questions or concerns. For the number of your nearest Heat-N-Glo, a division of Hearth Technologies Inc. 20802 Kensington Boulevard, Lakeville, MN 55044 Heat-N-Glo dealer, please call 1-888-427-3973.
-
Page 2: Safety And Warning Information
SAFETY AND WARNING INFORMATION READ and UNDERSTAND all instructions carefully before starting the installation. FAILURE TO FOLLOW these installation instructions may result in a possible fire hazard and will void the warranty. Prior to the first firing of the fireplace, READ the Using Your Fireplace section of the Owners Guide. -
Page 3: Table Of Contents
Appliance Certification .......... 6 Installation Codes ..........6 High Altitude Installations ........6 Section 2: Getting Started ......... 7 Introducing the Heat-N-Glo Gas Fireplaces ... 7 Pre-installation Preparation ........7 Section 3: Installing the Fireplace ....9 Constructing the Chase ........9 Step 1 Locating the Fireplace ...... -
Page 4: Section 1: Approvals And Codes
Approval Listings Appliance Certification and Codes The Heat-N-Glo fireplace model discussed in this Installers Guide has been tested to certification standards and listed by the applicable laboratories. CERTIFICATION MODEL LABORATORY TYPE STANDARD CFX-DIAMOND Underwriters Direct Vent ANSI Z21.88 -2000/ Laboratories Gas Fireplace CSA 2.33-M98 •... -
Page 5: Section 2: Getting Started
Failure to follow these instructions will void the owner’s warranty and may present a fire hazard. The Heat-N-Glo Warranty will be voided by, and Heat- N-Glo disclaims any responsibility for, the following actions: • Installation of any damaged fireplace or vent system component. - Page 6 (552mm) (219mm) (141mm) MINIMUM DISTANCE TO HORIZONTAL COMBUSTIBLE SURFACE (FLOOR, HEARTH, ETC.) STANDOFFS VENT STARTING GLASS RETENTION COLLARS CLIPS (8) NON-COMBUSTIBLE BOARD NAILING NAILING RATING PLATE AND LABELS GAS LINE ELECTRICAL ACCESS CONTROLS ACCESS Figure 1. Diagram of the CFX-DIAMOND...
-
Page 7: Section 3: Installing The Fireplace
Vapor and air infiltration barriers should be installed in the chase as per regional codes for the rest of the home. Additionally, Heat-N-Glo recommends that the inside surfaces be sheetrocked and taped for maximum air tightness. -
Page 8: Step 1 Locating The Fireplace
18 5/6” 1/2” (1015mm) (523mm) (474mm) (13mm) Figure 2. Fireplace Dimensions, Locations, and Space Requirements for model CFX-Diamond Clearance Requirements The top, back, and sides of the fireplace are defined by stand-offs. Minimum Clearances from the Fireplace to Combustible Materials... -
Page 9: Step 2 Framing The Fireplace
21 3/4” 5 9/16” (1078mm) (978mm) (552mm) (141mm) * Minimum dimension REQUIRED Figure 3. Framing Dimensions WARNING: THE CFX-DIAMOND REQUIRES AN ELEVATED PLATFORM CONSTRUC- TION TO ACCOMMODATE THE DIAMOND SHAPED SURROUND WHICH IS LARGER THAN THE FIREPLACE (SEE FIGURE 1) -
Page 10: Step 3 Installing The Vent System
A. Vent System Approvals Step 3 This model is approved to use D-Series components Installing the and terminations. Approved vent system components Vent System are labeled for identification. NO OTHER VENTING SYSTEM OR COMPONENTS MAY BE USED. Detailed installation instructions are included with each vent termination kit and should be used in conjunction with this Installers Guide. - Page 11 8 5/8” (220mm) DV-45D 35 3/4” 47 3/4” (908mm) (1.2m) 11 3/4” (298mm) 8 3/4” 5 3/4” (222mm) (146mm) DV-09D DV-12D DV-06D NOTE: PIPES OVERLAP 1-3/8 INCHES (34.93 mm) AT EACH JOINT. Figure 5. D-Series Direct Vent Component Specifications (5-inch inner pipe / 8 5/8-inch outer pipe)
- Page 12 VERTICAL VENTING V (FT.) 46’ MAX. (14M) Figure 6. Vertical Venting For vertical venting greater than V=12 ft. (without any elbows installed), SRV593-170 vertical baffle kit may be installed for improved performance. Follow instructions provided with the kit.
- Page 13 VENTING WITH ONE (1) 90° ELBOWS V (FT.) H (FT.) 0’ 3’ MAX. (.91m) 3' MIN. (914 mm) 9' MAX. (2.7m) 4' MIN. (1.2m) 12' MAX. (3.7m) 5' MIN. (1.6m) 15' MAX. (4.6m) 6' MIN. (1.9m) 18' MAX. (5.5m) V + H = 30’ MAX. (9.3 m) Ratio V to H = 1:3 H = 20' MAX.
- Page 14 VENTING WITH TWO (2) 90° ELBOWS V (FT.) (FT.) 3' MIN. (914mm) 9' MAX. (2.7m) 4' MIN. (1.2m) 12' MAX. (3.7m) 5' MIN. (1.6m) 15' MAX. (4.6m) 6' MIN. (1.9m) 18' MAX. (5.5m) V + H + H = 30’ MAX. (9.3 m) Ratio V to H + H = 1:3 H = 20' MAX.
- Page 15 VENTING WITH THREE (3) 90° ELBOWS V (FT.) (FT.) 3' MINIMUM (914 mm) 6' MAXIMUM (1.9 m) 4' MINIMUM (1.2 m) 8' MAXIMUM (2.4 m) 5' MINIMUM (1.6 m) 10' MAXIMUM (3.1 m) RATIO V TO H = 1:2 V + V + H + H = 30’...
-
Page 16: Installing Vent Components
B. Installing Vent Components 1. Attach the First VentComponent to the Starting Collars • Apply a 3/8 inch (9.5 mm) bead of stove cement around the inner pipe fireplace starting collar. • Make sure that the fireplace rope gasket supplied with the fireplace seals between the first 8-5/8 inch (219mm) vent component and the fireplace top. - Page 17 (2) sheet metal screws. WARNING: MODEL CFX-DIAMOND REQUIRES SHIELD SRV570-290 ABOVE THE FIRST 90° ELBOW IN THE SYSTEM IF CLEARANCE IS LESS THAN 4 INCHES (102MM).
- Page 18 3. Install Support Brackets For Horizontal Runs - The vent system must be supported every five (5) feet of horizontal run by a horizontal pipe support. To install support brack- ets for horizontal runs: • Place the pipe sup- ports around the vent WALL pipe.
- Page 19 • Position the firestops on both sides of the hole previously cut and secure the firestops with nails or screws. • The heat shields of the firestops MUST BE placed towards the top of the hole. • Continue the vent run through the firestops. NOTE: There must be NO INSULATION or other combustibles inside the framed firestop opening.
- Page 20 • Drill a hole or drive a nail through this centerpoint. • Check the floor above for any obstructions, such as wiring or plumbing runs. • Reposition the fireplace and vent system, if necessary, to accommodate the ceiling joists and/or obstructions. •...
-
Page 21: Vent Termination
If the area above the ceiling IS an attic, position and secure the firestop on top of the previously framed hole. This shows an attic NAILS (4 REQUIRED) installation. 1. Keep insulation away from the vent pipe at least 1 inch (25 mm). RAFTER CEILING CEILING FIRESTOP... - Page 22 For round cap termination: ROUND CAP TERMINATION 1. Secure the pipe, using the exterior pipelock hole on the round PERFORATION CANNOT BE INSIDE THE WALL flange of the wall firestop. 7 1/2" (191mm) MINIMUM TRAPEZOID CAP TERMINATION For trapezoidal termination: 1.
- Page 23 3. All gravity air intakes within 3 feet of a termination cap must be a minimum of 1 foot below the termination cap. Heat-N-Glo assumes no responsibility for the improper perfor- mance of the fireplace when the venting system does not meet these requirements.
- Page 24 VINYL SIDING 2 VINYL PROTECTORS MUST INSTALLED Figure 21. Two Vinyl Protectors For Vertical Terminations - To locate the vent and install the vent sections: • Locate and mark the vent centerpoint on the underside of the roof, and drive a nail through the centerpoint.
- Page 25 To seal the roof hole, and to divert rain and snow from the vent system: • Attach a flashing to the roof using nails, and use a non-hardening mastic around the edges of the flashing base where it meets the roof. •...
-
Page 26: Step 4 Positioning, Leveling, And Securing The Fireplace
Step 4 The diagram below shows how to properly Positioning, position, level, and secure the fireplace. Leveling, and Securing the Fireplace 1. Place the fireplace into position. 2. Level the fireplace from side to side and from front to back. 3. -
Page 27: Step 6 The Gas Supply Line
11/16” Figure 24. Gas Controls System Step 6 NOTE: Have the gas supply line installed in accor- dance with local building codes by a qualified The Gas installer approved and/or licensed as required Supply Line by the locality. (In the state of Massachusetts installation must be performed by a licensed plumber or gas fitter). -
Page 28: Step 7 Gas Pressure Requirements
• The gap between the supply piping and gas access hole can be plugged with non- combustible insulation to prevent cold air infiltration. USE A WRENCH ON SHUT-OFF VALVE WHEN TIGHTENING • Insert insulation from GAS LINE. the outside of the fireplace and pack the insulation tightly to MANUAL... -
Page 29: Step 8 Wiring The Fireplace
Step 8 NOTE: Electrical wiring must be installed by a licensed electrician. Wiring the Fireplace DISCONNECT REMOTE CONTROLS IF YOU ARE ABSENT FOR EXTENDED TIME PERIODS. THIS WILL PREVENT ACCIDENTAL FIREPLACE OPERATION. Intermittent Pilot Ignition (IPI) Wiring Appliance Requirements This appliance requires that 110-120 VAC be wired to the factory installed junction box. -
Page 30: Step 9 Finishing
SPARK TO PILOT IGNITOR FAN OUTLET RECEPTACLE 120 VAC (NO FAN OPTION) JUNCTION BOX IGNITOR MODULE BLACK (IGNITOR) PLUG-IN 3V TRANSFORMER BLACK (SENSOR) TRANSFORMER PILOT ASSEMBLY BLACK LOW VOLTAGE FLAME SPARKER / AND VALVE ASSEMBLY SEE NOTE 1 MUST BE GROUNDED SENSOR (COMMON GROUND GROUND TO... - Page 31 CAUTION IF JOINTS BETWEEN THE FINISHED WALLS AND THE FIREPLACE SURROUND (TOP AND SIDES) ARE SEALED, A 300° F. MINIMUM SEALANT MA- TERIAL MUST BE USED. THESE JOINTS ARE NOT REQUIRED TO BE SEALED. ONLY NON- COMBUSTIBLE MATERIAL (USING 300° F. MINI- MUM ADHESIVE, IF NEEDED) CAN BE APPLIED AS FACING TO THE FIREPLACE SURROUND ABOVE THE GLASS.
-
Page 32: Step 10 Installing Trim, Logs & Ember Material
Step 10 Installing the Trim Installing Trim, Combustible materials may be brought up to the specified clearances on the side and top front Logs, and Ember edges of the fireplace, but MUST NEVER overlap Material onto the front face. The joints between the finished wall and the fireplace top and sides can only be sealed with a 300 °... -
Page 33: Positioning The Logs
Positioning the Logs Logs provided with this fireplace have been pack- aged separately, refer to the installation instructions that accompany the logs. Save the log instruc- tions with this manual. If sooting occurs, the logs might need to be reposi- tioned slightly to avoid excessive flame impingement. - Page 34 2 to EMBER MATERIAL 4 applications. Figure 32. Placement of the ember material CAUTION IT IS STRONGLY RECOMMENDED THAT OPTIONAL MESH SCREENS BE INSTALLED ONTO THE DECORATIVE SURROUND/TRIM DOOR ON PROPANE MODELS. GLASS SPECIFICATIONS: CFX-DIAMOND 30” X 48” CERAMIC...
-
Page 35: Step 11 Before Lighting The Fireplace
Step 11 Before lighting the fireplace, be sure to do the following: Before Lighting the Fireplace Remove all paperwork and documents from the fireplace. Review safety warnings and cautions • Read the Safety and Warning Information section at the beginning of this Installers Guide. Double-check for gas leaks •... -
Page 36: Your Fireplace
Fireplace Although the frequency of your fireplace servicing and maintenance will depend on use and the type of Maintenance installation, you should have a qualified service technician perform an appliance check-up at the beginning of each heating season. See the table below for specific guidelines regarding each fireplace maintenance task. - Page 37 MAKE SURE THE FLAMES ARE STEADY - NOT LIFTING OR FLOATING. Figure 33. Burner Flame Patterns NOTE: Flames too close to the ceramic insulators can cause nuisance lockouts and electrode failure. 11/16” Figure 34. Ignitor Flame Patterns...
