Casio 5110 Operation Manual

MO1408-EA © 2014 CASIO COMPUTER CO., LTD.
• The watch continues to operate, even when it is not exposed to light. Leaving the
watch in the dark can cause the battery to run down, which will result in some
watch functions to be disabled. If the battery goes dead, you will have to
re-confi gure watch settings after recharging. To ensure normal watch operation, be
sure to keep it exposed to light as much as possible.
Battery charges in the light.
Bright Light
Solar panel
(Converts light to
electrical power.)
LEVEL 1
LEVEL 2
LEVEL 3
Charge
LEVEL 4
Rechargeable battery
E-2
About This Manual
E-4
Countdown Timer.................................................................................E-36
To use the countdown timer ............................................................E-37
To confi gure countdown start time and auto-repeat settings ..................E-38
Alarms ................................................................................................E-40
To set an alarm time .....................................................................E-41
To turn an alarm on and off ............................................................E-43
To turn the Hourly Time Signal on and off ..........................................E-44
Illumination .......................................................................................E-45
To illuminate the display manually ...................................................E-45
To turn the auto light switch on and off .............................................E-48
Power Supply ....................................................................................E-49
Timekeeping .......................................................................................E-57
To set the time and date manually ...................................................E-58
To change the Daylight Saving Time (summer time) setting ..................E-63
E-6
General Guide
Press C to change from mode to mode.
•
In any mode (except a setting mode), press B to illuminate the display for about
•
one second.
E-8
Operation Guide 5110
Battery discharges in the dark.
Electrical
energy
All
LEVEL 1
functions
LEVEL 2
enabled
LEVEL 3
Dis-
charge
LEVEL 4
• Depending on the model of your watch, display text
appears either as dark fi gures on a light background
or light fi gures on a dark background. All sample
displays in this manual are shown using dark fi gures
on a light background.
• Button operations are indicated using the letters
shown in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Timekeeping Mode
Press .
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Keep the watch exposed to bright light
Bright Light
Solar panel
• The actual level at which some functions are disabled depends on the watch
model.
• Frequent display illumination can run down the battery quickly and require
charging. The following guidelines give an idea of the charging time required to
recover from a single illumination operation.
Approximately 5 minutes exposure to bright sunlight coming in through a window
Approximately about 8 hours exposure to indoor fl uorescent lighting
• Be sure to read "Power Supply" (page E-49) for important information you
need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch's Power Saving function
has turned off the display to conserve power.
• See "Power Saving Function" (page E-66) for more information.
Some or all
functions
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
disabled
damage or loss suffered by you or any third party arising through the use of your
watch or its malfunction.
Contents
General Guide .................................................................................... E-8
Radio-controlled Atomic Timekeeping ...................................................E-10
To specify your Home City ............................................................E-12
To perform manual receive ............................................................E-24
To check the latest signal reception results .......................................E-26
World Time ..........................................................................................E-29
To view the current time in another time zone ....................................E-31
To toggle a city code time between Standard Time and
Daylight Saving Time ...............................................................E-32
To swap your Home City and World Time City ....................................E-33
Stopwatch ..........................................................................................E-34
To measure times with the stopwatch .............................................E-35
Hand Home Position Correction ............................................................E-64
To adjust the home positions .........................................................E-64
Reference ..........................................................................................E-66
To recover from the sleep state ......................................................E-67
To turn Power Saving on and off ......................................................E-68
Specifi cations ....................................................................................E-75
World Time Mode (page E-29)
Alarm Mode (page E-40)
The electricity generated by the solar panel of the watch is
stored by a built-in battery. Leaving or using the watch
where it is not exposed to light causes the battery to run
down. Make sure the watch is exposed to light as much
as possible.
• When you are not wearing the watch on your wrist,
position the face so it is pointed at a source of bright
light.
• You should try to keep the watch outside of your sleeve
as much as possible. Charging is reduced signifi cantly
if the face is even only partially covered.
Stopwatch Mode (page E-34)
Countdown Timer Mode (page E-36)
