ATCOM AT620P Setup Manual page 9

AUTOPROVISIONING USING ELASTIX'S ENDPOINT
1. In the Elastix WebUI go to "PBX => Endpoint Configurator" (Figure 4-10).
Figure 4.10 Endpoint Configurator
2. Next to the "Discover Endpoints in this Network" button, type the address where
the phone is located and click the button. This will generate a list with all the
phones available in that network (Figure 4-11).
3. In the row where the phone you want to autoprovision is located (find it according
to either its MAC or IP Address):

Mark the checkbox

From the drop-down list, select the correct "Phone Type" (phone model) of the
phone

From the drop-down list, select the "User Extension" you want to assign to the
phone
CONFIGURATOR
Figure 4.11 Endpoint Configurator
9
PaloSanto Solutions
Atcom AT620P Server Setup Guide
