Setting Transmitter Code
Note: A transmitter must be coded into the opener's
memory before use.
1 Press the LEARN BUTTON for 2 seconds the LEARN
LED will turn on.
2 Press the same button on the transmitter twice, the
LEARN LED will flash 8 times and then turns off. The
transmitter has now been coded and the security
code stored in the memory on board.
3 Press the transmitter to see if it operates the door.
Repeat the above steps to code additional transmitters.
Note: Up to 20 transmitters can be stored into memory.
If more than 20 transmitters are stored the system
will disregard the additional attempts to code new
transmitters.
DELETING ALL TRANSMITTERS
1 Press and hold the LEARN BUTTON, the LEARN
LED will turn on.
2 Hold the LEARN BUTTON 8 seconds approximately,
the LEARN LED will turn off.
3 Release the LEARN BUTTON, all the stored
transmitter codes will be deleted.
4 Confirm this by pressing one of the deleted
transmitters.
It is recommended to delete all transmitters and re-coding
when one of the stored transmitters is lost.
Maintenance
No particular maintenance is required for the logic circuit
board.
At least twice a year check that the door is properly
balanced and that all working parts are in good working
condition.
IMPORTANT: A poorly operating door can effect the life of
the automatic opener due to incorrect loads and will void
the warranty.
Check the reversing sensitivity at least twice a year and
adjust if necessary.
Make sure that the safety devices are working effectively
(photo beams, etc.)
Technical Specifications
Power Input:
Motor:
Courtesy light time:
Working temperature:
Relative Humidity:
Open and close force: 250N
Reception frequency:
Storage Capacity:
Decoding:
Transmitter power:
Courtesy Light:
NOTE: Smart Openers Pty Ltd reserves the right to
modify its product and product specifications at any
time without prior notice.
-12-
240 VAC ±10% 50Hz
24V DC 100W
3 minutes approx.
-20° ~ 70°C
<90%
433.22MHz
20 Transmitters
Rolling code
27A 12V Battery
LED Array
