Recline Back Seat And Adjustments; Reclining Back Seat - Hoveround MPV5 Owner's Manual

Hoveround-MPV5ManualRevM
If the footplate does not remain upright, the footplate tension
requires adjustment. Please immediately contact Hoveround
Technical Support at 1-800-96-HOVER (1-800-964-6837).

Reclining Back Seat

Driving with the seatback reclined makes it difficult to see where
you are going and increases the chance of serious injury or
death from collision and tip-over. Do not attempt to drive this
vehicle with seatback reclined.
The optional reclining seat will permit the seatback to recline
approximately 45 degrees.
Seatback Adjustment for 17" and 19" Reclining Back Seats - To
adjust the seatback, locate the recline lever, at the lower right
hinge area (See Figure 4L below). Restrain the spring-loaded
seatback either with your arm or by sitting in the chair and resting
your back against the seatback.
Move the spring loaded lever counterclockwise by pulling the
lever up or pushing it back, depending on the configuration on
your seat, to release the latch and position the seatback until a
comfortable position is reached. Release the lever and move the
lever clockwise to lock in the position.
36 Chapter 4
1/17/14 10:37 AM Page 36
Figure 4K
(May require medical necessity)
®
D82008753M 10/13
