Summary of Contents for Hoveround MPV5

  • Page 1 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 1...
  • Page 2 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 2 D82008753M 10/13...

  • Page 3: Special Notes

    ® ® HOVEROUND and MPV5 are registered trademarks of the HOVEROUND CORPORATION. Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Hoveround ®...
  • Page 4 MPV5 to fulfill your personal mobility needs. The MPV5 has the same innovation of design that is the hallmark of our company. It is compact yet very stable; attractive yet rugged; simple yet functional; gentle yet powerful; and above all, the MPV5 provides an outstanding level of maneuverability.

  • Page 5: Table Of Contents

    Entering Your MPV5 ......15 Driving Your MPV5 ......16 Joystick Controller .

  • Page 6: Am Page

    Chapter 6 Routine Maintenance ......44 Chapter 7 Disassembling and Reassembling Your MPV5 ..47 Removing and Replacing Your Controller .

  • Page 7: Introduction

    Whenever your mobility needs require special attention and equipment delivered with an extra measure of care and concern, you can count on Hoveround ® Service Service is our commitment to our clients and their continued mobility is our priority.

  • Page 8: General Warnings / Before You Use Your Mpv5

    Never modify your wheelchair, and do not use accessories ® other than those developed for use specifically with your Hoveround MPV5 power wheelchair. Information about the design of ramps appropriate for wheelchair access for your home are contained in guidance from the Americans with Disabilities Act, which can be located at http://www.accessboard.gov/adaag/html/adaag.htm.
  • Page 9 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 9 Stop using your power wheelchair immediately, and call for assistance if: • Your power wheelchair is not working correctly. • Your seat belt does not latch or stay latched. • You are taking medications, drugs, or alcohol that affect your ability to safely drive.
  • Page 10 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 10 To reduce the chance of serious injury or death from tip-over, collision with obstacles and other people, loss of control, or falling from the power wheelchair, drive in proper environments: • Do not drive across or sideways on a ramp or slope;...
  • Page 11 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 11 To avoid serious injury or death from being struck by a motor vehicle, when driving your power wheelchair near traffic: • Obey all local pedestrian traffic rules. • Cross roads at locations where you are most visible to motor traffic, if possible at a light-controlled pedestrian crossing with handicapped cutouts.

  • Page 12: Hoveround Mpv5 / Diagram

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 12 Hoveround ® MPV5 - Diagram Joystick Controller Adjustable Arm Rest • • Seat Belt Seat • (Swivel Optional) • Batteries • Brake Release • • Battery Cable Levers Connection • (if equipped) Dual Motor Front •...

  • Page 13: Hoveround Mpv5 / Warning Labels

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 13 Hoveround ® MPV5 - Warning Labels For New VSI S/N 5800000+ Turn power off before exiting the seat or For EMI warning changing the joystick position. label see page 14. WARNING: EMI Refer to owners manual.
  • Page 14 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 14 EMI, Warning Label General Warnings D82008753M 10/13...

  • Page 15: Chapter 1 Operating Instructions

    • Always fasten seat belt to maintain proper positioning in the seat. Set speed/response control of joystick to minimum while learning to drive the power wheelchair. Entering Your MPV5 1. Be sure the power is turned “OFF” before entering or exiting your Hoveround ®...

  • Page 16: Driving Your Mpv5

    6. Move the footplate down and position your feet on the foot plate. Driving Your MPV5 Power Wheelchair • Sudden change in motion, loss of control, or tip-over may cause a collision or fall from the seat and result in serious injury or death.
  • Page 17 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 17 1. With the power turned OFF, hold the joystick and move it to determine the limits of movement. Observe that, when released, the joystick returns to center (neutral). 2. Allow plenty of space to test drive your power wheelchair.
  • Page 18 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 18 7. Gently move the joystick lever backward, and the chair will move slowly backward. Note that the backward movement is about half the speed of the forward movement. 8. If you move the joystick lever gently back and to the right, the chair will move backward to the left.

  • Page 19: Joystick Controller

    10:36 AM Page 19 Joystick Controller All the controls and indicators necessary to drive your MPV5 are located on the joystick controller. See Figures 1A - 1B to identify your controller. 1. ON/OFF - Press to turn the system on and off.
  • Page 20 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 20 Figure 1A- VSI Controller Chapter 1 D82008753M 10/13...
  • Page 21 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 21 Figure 1B - new VSI Controller D82008753M 10/13 Chapter 1...

  • Page 22: Chapter 2 Batteries And Charging

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 22 Chapter 2 Batteries and Charging Caring For Your Batteries • Completely read and follow all warnings about the batteries in this user instruction manual and any labels applied to the product. Failure to do so could result in fire, explosion, injury and/or death.
  • Page 23 • NEVER use a battery that has been frozen or might have been frozen. The MPV5 uses two sealed 12-volt batteries of the UI size, with capacity of 33 ampere hours. The battery pair is connected into a series configuration to provide 24-volts of power.

  • Page 24: Battery Replacement

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 24 Battery Replacement When it becomes necessary to replace batteries, consult with Hoveround ® Technical Support 1-800-96-HOVER (1-800-964-6837). We will provide you with the replacement battery to ensure the proper operation of your power wheelchair.
  • Page 25 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 25 • DO NOT expose the charger to moisture such as rain, sleet or snow. • ALWAYS charge your power wheelchair in a well-ventilated area free of any sparks, high heat or open flame. Explosive gas is emitted during the charging process.
  • Page 26 Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 26 1. Select a clean, dry, cool, well ventilated area to use the charger. 2. If your charger is equipped with an off button, ensure that the charger is in the OFF position, along with the joystick controller in the OFF position.

  • Page 27: Flying Power Fy-4101 Charger

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 27 If you have a: Flying Power FY-4101 Charger 1. Switch the power on. A light will illuminate on the output side of the charger, indicating power is available. If the light does not go on, please check to make sure the household power is working.

  • Page 28: Chapter 3 Manual Brake Release Levers

    10:36 AM Page 28 Chapter 3 Manual Brake Release Levers On occasion it may be necessary to push your Hoveround ® power wheelchair. Each motor has a manual brake release lever. Refer to Figure 3A below to locate the manual brake release levers on your power wheelchair.

  • Page 29: Chapter 4 Seating And Pressure Relief

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 29 Chapter 4 Seating and Pressure Relief • Unintentional or unexpected motion increases the chances of a collision or fall from the seat and can result in serious injury or death. Press the power button to OFF before making any adjustments to your power wheelchair.

  • Page 30: Seat Belt Adjustment

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 30 Seat Belt Adjustment • Always fasten seat belt to maintain proper positioning in the seat and avoid injury. • Replace seat belt immediately at first signs of wear or improper latching. To fasten the seat belt, push the metal tab into the buckle until it clicks.

  • Page 31: Arm Angle Adjustment

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 31 Arm Angle Adjustments The seat arms have angle adjustments to suit your driving and comfort requirements. To adjust the arm angle on the seat arms, lift the arm and locate the adjustment bolt near the pivot point. Refer to Figure 4D below.

  • Page 32: Swivel Seat

    This feature is provided to make side transferring easier. The swivel release lever is mounted on the left side in the standard position, and can be changed to the right side by a Hoveround ® Field Service Technician.

  • Page 33: Arm Width

    Hoveround-MPV5ManualRevM 1/17/14 10:36 AM Page 33 Rapid rotation may cause seat to skip the locking position, increase the chances of a fall from the seat, and can result in serious injury or death. Rotate seat slowly. Arm Width Adjustment The standard seat has arm width adjustment (Figure 4F and 4G).

  • Page 34: Seat Back Angle

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 34 Figure 4H Seat Back Angle Adjustment The seat back has fixed positions to select from (Figure 4I). To change the back angle position: 1. Locate the screw and nut on the left hinge and right hinge.

  • Page 35: Seat Height Adjustment

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 35 Seat Height Adjustment You can raise or lower the seat by loosening the locking bolt on the corner of the seat post. Use the 1/4 inch hex wrench supplied with the chair. When the seat is raised, you will see holes in the seat post (see Figure 4J below).

  • Page 36: Recline Back Seat And Adjustments

    1/17/14 10:37 AM Page 36 Figure 4K If the footplate does not remain upright, the footplate tension requires adjustment. Please immediately contact Hoveround ® Technical Support at 1-800-96-HOVER (1-800-964-6837). Reclining Back Seat (May require medical necessity) Driving with the seatback reclined makes it difficult to see where you are going and increases the chance of serious injury or death from collision and tip-over.
  • Page 37 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 37 • The seatback can drop backward when the “recline lever” is not locked. • To avoid a fall from the seat, always make sure the “recline lever” is in the locked position before applying weight to the seatback or arms.
  • Page 38 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 38 Folding The Seatback Down - Starting in the straight-up position, push the lever down and fold the seat forward (see Figure 4O below). To raise the seatback from the folded position, lift the seatback until it locks.
  • Page 39 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 39 Reclining Back Seats Arm Height Adjustment - The arms can be raised from the standard position by repositioning the bolts that hold the arm in place. See Figure 4P below for bolt location. Locate the upper threaded hole by putting your finger on the fabric above the top bolt.

  • Page 40: Chapter 5 Options And Accessories

    To obtain information or pricing on accessories, contact HOVEROUND ® CORPORATION at 800-96-HOVER (800-964-6837). Optional Tie-Down Brackets When transporting the MPV5 in a motor vehicle, your wheelchair must be adequately secured within the motor vehicle. Optional ® tie-down kit is available. Please contact Hoveround for additional information.
  • Page 41 Press either seat symbol button to activate the PSL mode (see Figure 5A below). When the indicator light is lit, move the joystick forward to raise the seat, back to lower. The MPV5 will not drive while seat is raised and light is on. When seat is fully down, press either button to restore drive mode.
  • Page 42 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 42 Optional Legrests or Footrests Install each leg/footrest on to the appropriate hanger bracket and swing into the forward facing position. If elevating legrests are installed, set the angle to the lowest possible position. Fold down the foot plates. Your feet should comfortably rest on the plates without a tendency to lift your thighs from the seat cushion.
  • Page 43 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 43 D82008753M 10/13 Chapter 5...

  • Page 44: Chapter 6 Routine Maintenance

    Routine Maintenance Service and maintenance are very important to ensure the performance and the safe operation of your power wheelchair. Service Please contact Hoveround ® Technical Support at 1-800-96-HOVER (1-800-964-6837) for any service or maintenance needs. Stop using your power wheelchair immediately, and call for assistance if: •...
  • Page 45 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 45 Owner Maintenance Daily • Check drive tires. • Charge batteries (or as required). • Check that the seat belt latches and does not show signs of wear. Weekly • Check tire treads and pressure. (Should be 45-50 psi.).
  • Page 46 1/17/14 10:37 AM Page 46 Cleaning your MPV5 The MPV5 is designed to operate both inside and outside the home. To keep the vehicle clean: Seat – Wipe with a damp cloth or towel, using a mild detergent or window cleaner.

  • Page 47: Chapter 7 Disassembling And Reassembling Your Mpv5

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 47 Chapter 7 Disassembling and Reassembling Your MPV5 Controller Removal/Replacement Removal 1. Check that vehicle power is OFF. 2. Lift the arm and loosen the socket head cap screw closest to the controller. Use the 1/4 inch hex wrench supplied with your chair (See Figure 7A, below).

  • Page 48: Removing And Replacing The Seat

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 48 Seat Removal/Replacement Removal 1. Remove controller. 2. Remove the controller cable from the seat base by releasing the Velcro strap at the rear of the seat or opening the seat clip at the side of the seat, depending on the type of seat you have.
  • Page 49 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 49 Replacement 1. Grasp the seat at the front and back. 2. Align the male post of the seat bracket with the seat post and allow seat bracket to descend into the seat post. 3. Tighten the socket head cap screw at the top-front corner of the seat post with the 1/4 inch hex wrench that is supplied with the vehicle.

  • Page 50: Removing And Replacing Batteries

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 50 Battery Removal/Replacement (if equipped with separate removable batteries) Removal 1. Remove each of the battery connectors by pinching the tab on the connector at the junction box and gently pulling free (See Figure 7G, Page 49).
  • Page 51 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 51 Battery Removal/Replacement MPV5 S/N 5800000+ Turn the joystick off before attempting to remove the batteries. To prevent short circuit, fire or other hazards, prevent contact between the battery terminals and any surface that may cause a short, spark or other hazard.

  • Page 52: Chapter 8 Electromagnetic Interference (Emi)

    The higher the immunity level, the greater the protection. At this time, current technology is capable of achieving at least a 20 V/m immunity level, which would provide useful protection from the more common sources of radiated EMI. This MPV5 power Chapter 8 D82008753M 10/13...
  • Page 53 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 53 wheelchair model, as shipped, without any further modification has a tested immunity level of at least 20 V/m. There are a number of sources of relatively intense electromagnetic fields in the everyday environment. Some of the sources are obvious and easy to avoid.

  • Page 54: Important Information

    1. 20 volts per meter (V/m) is a generally achievable and useful immunity level against interference from radio wave sources (as of May 1994, the higher the level, the greater the protection). 2. The MPV5 wheelchair has an immunity level of at least 20 V/m. Chapter 8 D82008753M 10/13...

  • Page 55: Chapter 9

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 55 Chapter 9 Appendixes Appendix A: Programmable Parameters The controller used on your power wheelchair is programmable for basic functions. It requires a programmer to make changes. Any changes must be made by a qualified technician only.

  • Page 56: Appendix B Fault Codes

    The controller may prevent the chair from driving should a critical fault condition exist. Refer to the appropriate fault code section for the system used on your MPV5. When there is a fault please follow this procedure: A.
  • Page 57 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 57 If a fault occurs, you can find out what has happened by counting the number of bars on the battery gauge that are flashing. VSI Controller 1 bar: Low battery or a bad connection.
  • Page 58 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 58 New VSI Controller 1 flash: The battery needs charging or there is a bad connection to the battery. Try charging the battery. 2 flashes: The left hand motor has a bad connection. 3 flashes: The left hand motor has a short circuit to a battery connection.

  • Page 59: Appendix C Locking Feature

    1/17/14 10:37 AM Page 59 Appendix C: Locking Feature Your MPV5 is equipped with a locking feature. Please refer to the appropriate instructions for the controller on your MPV5. Lock Sequence System ON / OFF Button Joystick Figure 9A - VSI Controller and new VSI Controller 1.

  • Page 60: Appendix D Specifications

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 60 Appendix D: MPV5 Specifications Performance Maximum Speed* 5 mph Range (per battery charge)* 15 miles Capacity 300 lbs Turning Radius 22.7” Ground Clearance 2.5” Maximum step climb 2” Maximum grade climb 6° (5° ADA ramp recommended) Dimensions and weight (with 20”...

  • Page 61: Appendix E Record Of Service

    Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 61 Appendix E: Record of Service Date Technician Service Performed D82008753M 10/13 Chapter 9...
  • Page 62 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 62 Record of Service Date Technician Service Performed Chapter 9 D82008753M 10/13...

  • Page 63: Limited Warranty

    10:37 AM Page 63 Limited Warranty Hoveround ® Corporation warrants the base frame of the MPV5 to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase. Hoveround ® Corporation...
  • Page 64 Hoveround ® shall not be liable for any consequential or incidental damages whatsoever.
  • Page 65 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 65 D82008753M 10/13...
  • Page 66 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 66 D82008753M 10/13...
  • Page 67 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 67 D82008753M 10/13...
  • Page 68 Hoveround-MPV5ManualRevM 1/17/14 10:37 AM Page 68...
