Seat Back Angle Adjustment
The seat back has fixed positions to select from (Figure 4I).
To change the back angle position:
1. Locate the screw and nut on the left hinge and right hinge.
2. Remove the screw and nut and place the back in the desired
angle position. Make sure the holes in the outer hinge and
inner hinge brackets line up for the desired angle.
3. Re-install the screws and nuts into the new location and
tighten securely.
The seat back will fold forward when pushed from the rear or
pulled from the front. Always use caution when pushing the
chair from the back. If the chair must be pushed from the back,
push or pull on the arms or another solid surface.
34 Chapter 4
1/17/14 10:37 AM Page 34
Figure 4H
Figure 4I
