Integrating with Cisco Unified
Communications Manager 5.1
This chapter describes a sample configuration of Cisco Unified Communications
Manager 5.1 for integration with the EasyCall Gateway through a SIP trunk. The
examples show the Cisco Unified Communications Manager (previously referred to as
CallManager) administration software screens.
The following topics describe the integration:
"Configuring the SIP Trunk Security Profile" on page 19
"Configuring the SIP Trunk" on page 20
"Configuring the SIP Profile" on page 22
"Configuring Call Forwarding" on page 24
"Verifying the Integration" on page 26

Configuring the SIP Trunk Security Profile

The following table describes the SIP trunk security profile configuration values that
are important for EasyCall Gateway integration.
Setting
Name
Outgoing Transport Type Must be UDP.
Incoming Port
Description
Must be Non Secure SIP Trunk Profile - UDP. When "Configuring the SIP Trunk"
on page 20, this name must be entered under the SIP Information section as
the SIP Trunk Security Profile.
Defaults to 5060. This is the listening port on the Unified Communication
Manager and it must match the EasyCall Gateway port, which also defaults to
5060.
