Loading Envelopes

5 envelopes may be loaded in the multi purpose tray.
Acceptable envelope sizes are as follows.
Acceptable Envelope
Youkei 2
Youkei 4
Monarch
Envelope #10 (Commercial #10)
Envelope DL
Envelope C5
Executive
Envelope #9 (Commercial #9)
Envelope #6 (Commercial #6 3/4)
Switching to Envelop Mode (PG L2140)
To print on an envelope, follow the procedure below to switch to envelope mode.
Note When the printing on envelopes is completed, return the envelope switch to its original position (at the
bottom).
1
Open the rear cover.
2
To print on an envelope, raise the envelope switch.
Envelope
Switch
Size
114 × 162 (mm)
105 × 235 (mm)
3 7/8" × 7 1/2"
4 1/8" × 9 1/2"
110 × 220 (mm)
162 × 229 (mm)
7 1/4" × 10 1/2"
3 7/8" × 8 7/8"
3 5/8" × 6 1/2"
CAUTION The fuser unit inside the printer is hot. Do
not touch it with your hands as it may result in burn
injury.
2-27
Preparation before Use
