Pro-Max CG14SPT Installation And Operation Instructions Manual
Split lid table top two sided grill
Hide thumbs
Also See for CG14SPT:
- Instalation and operation instructions (17 pages) ,
- Installation and operation instructions manual (17 pages) ,
- Installation and operation instructions manual (17 pages)
Subscribe to Our Youtube Channel
Related Manuals for Pro-Max CG14SPT
Summary of Contents for Pro-Max CG14SPT
- Page 1 ® SPLIT LID TABLE TOP TWO SIDED GRILL MODEL CG14SPT, CG14STE, CG14SPTI, CG14SPTIG GR14SPTA, GR14SPTC, GR14STE GR14SPTK, GR14SPTI, GR14SPTIP Installation and Operation Instructions 2M-Z5818 Rev. N 9/14/2011 GR14SPT...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: General Specifications
Inches Inches Voltage Wattage Amps Shipping Installed Surface Inches (cm) Inches (cm) Plug (cm) (cm) lbs. (kg) lbs. (kg) CG14SPT-120C 14 1/4” (36.3) 31 5/8” (80.3) 2,300 19.2 5-30P CG14SPT-120V 14 1/4” (36.3) 31 5/8” (80.3) 2,300 19.2 5-20P Alum. -
Page 4: General Installation Data
GENERAL INSTALLATION DATA This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. CAUTION Before using your new equipment, read and understand all the instructions &... - Page 5 OPERATING INSTRUCTIONS 1. Turn unit on by placing switch in "ON" position. The "Heat On" indicator, program number and heating time is approximately 30 minutes). 2. Place product on the bottom cooking surface of the unit and close the lids. 3.
- Page 6 Right Side (Timer only): 1. To Change the time on the right side, press and hold the "TEMP" button, and press and hold any program button on the right for one second. The LED above the program button will light and the Right Display will read "_ _ _ _."...
- Page 7 1. Improperly installed. 2. Incorrect voltage applied to electric Pro-Max units allowing the surface to overheat and discolor. 3. The misuse of any instrument or tool which scratches or makes indentations in the surface which 4.
- Page 8 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation company who delivered the item to you and initiate your claim with same.
-
Page 9: Wire Diagram
WITH THE BOTTOM PLATE REMOVED. THE TOP DESCRIPTIONS ARE THEIR POSITIONS WHEN UPRIGHT. SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN WIRE DIAGRAM CERTAIN INSTANCES MAY NOT BE AVAILABLE 120V/240V, 2300 WATT MODEL CG14SPT-120V (2J-Z6323 CONTROLLER ONLY) CG14SPT-240V CG14SPTI-240V GR14SPTA-120V GR14SPTA-240V GR14SPTK-120C STAR MANUFACTURING INTERNATIONAL, INC. - Page 10 UNITS WITH IEC CONNECTOR: POWER INLET CONNECTOR: IEC 320 C-20 POWER INLET, ON ALL 208 - 240V UNITS. FOR USE WITH DETACHABLE CORDSETS SUPPLIED WITH A STRAIGHT, FEMALE, IEC 60320 C-19 CONNECTOR. TOP ELEMENT TOP ELEMENT RIGHT LEFT (ELEMENT MAS ALTO) (ELEMENT MAS ALTO) SENSOR - RIGHT (SENSORIO)
- Page 11 120V UNITS PLUG TOP ELEMENT TOP ELEMENT NEMA 5-20P 2,300 WATTS RIGHT LEFT NEMA 5-30P 2,300 WATTS (ELEMENT MAS ALTO) (ELEMENT MAS ALTO) 240V UNITS PLUG NEMA 6-15P 2,300 WATTS NEMA 6-20P 3,550 WATTS SENSOR - RIGHT (SENSORIO) SENSOR - LEFT (SENSORIO) GREEN WHITE...
- Page 12 120V UNIT PLUGS NEMA 5-20P 2,300 WATTS NEMA 5-30P 2,300 WATTS 208V UNIT PLUGS NEMA 6-15P 3,100 WATTS NEMA 6-20P 3,100 WATTS 240V UNIT PLUGS NEMA 6-15P 2,300 WATTS NEMA 6-20P 3,550 WATTS GREEN WHITE BLACK REAR OF CONTROLLER FOR REFERENCE WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED WITH THE BOTTOM PLATE REMOVED.
- Page 13 28.1 B Style Hinge Counterbalance NAMEPLATE GR14SPTIP240 4“ LEGS ONLY SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential = B Style Hinge Units Only to Star Manufacturing International, Inc. No reproduction or disclosure of its contents is permitted.
-
Page 14: Parts List
2F-Z9651 CASTING - TOP SMOOTH, CHROME 2F-Z8349 CASTING - TOP SMOOTH, IRON 2F-Z7967 CASTING - TOP GROOVE, IRON 2V-Z3152 HANDLE 2B-Z3336 14” CG14SPT ARM 2B-Z9515 SPTC, SPTI 2B-Z10355 CG14SPTK-120/240V, GR14SPTKM-UK CG14STKE-120, GR14STB, GR14STE, 2B-Z12554 ARM, LEFT ST GR14STKE120C CG14STKE-120, GR14STB, GR14STE,... - Page 15 D9-GR0152 D9-GR0393 BODY ASSEMBLY CG14SPTK-120/240V D9-GR0394 GR14SPTIP D9-GR0507 BODY ASSY - 14” CG/CG14 GR14STE D9-GR0461 BODY ASSY 14” SPT GR14STB CG14SPT, CG14SPTI, CG14STE, GR14SPTA, 2M-Z5817 OVERLAY-STANDARD GR14SPTC, GR14SPTI, GR14SPB,. GR14STE 2M-Z3337 GR14SPT-120/240V & CUL 2M-Z10851 CG14SPTK-120/240V 2M-Z11984 GR14STE-120 OVERLAY 2M-Z11983...
- Page 16 BUSHING - STRAIN RELIEF 2E-Z4119 CORD POWER 120V D9-GR0193 CORD POWER 120C 240V D9-GR0194 CORD POWER CG14SPT-230V between 1-15-01 thru 8-16-04 2E-Y9251 CORD SET CONT EUR 16AMP CG14SPT-230V, GR14STE-230 2E-Z2905 CORD POWER SPTI- 240V 2E-Z9192 CORDSET (DETACHABLE) - UK GR14SPTKM-UK...
- Page 17 SPTIP 2R-Z4621 KNOB, 1-3/4 - .250”D”HOLE SPTIP D9-Z11304 PLATE, COVER SPTIP PS-GR134 KIT, BEARING ASSY, COUNTER BALANCE CG14SPT, CG14SPTI, CG14SPTIG, GR14SPTA, D9-GR0520 GR14SPTC, GR14SPTI, GR14SPTIP, GR14STB, GR14SPTE BASE ASSY / GREASE CABINET CG14SPTK, CG14STKE, GR14SPTK, D9-GR0522 GR14SPTKM120, GR14STKE 2C-1516 #10-24 UNC X 1.00 LG RHP SCREW...
