Panel Mounting Procedure
1. Cut and drill the panel (refer to Figure 2; Panel Mount Drawing).
Measurements are in inches. A template of the hole pattern has been
supplied with your monitor to assist in making the mounting holes accurately.
Also, there is an AutoCad .dxf file included on the provided CD. This
computer file can be used in a design drawing or forwarded to your panel
fabricator for the proper mounting
2. If access to the side of the monitor is not available following installation,
attach the power and video cables to the side of the monitor at this time.
3. Install the monitor in the prepared cutout.
4. Install
the
washers
Note: Use #10-32 nuts for mounting.
5. Tighten all mounting nuts evenly to a torque of 24 inch-pounds.
ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to
provide panel seal and avoid potential damage. AutomationDirect.com
assumes no responsibility for water or chemical damage to the monitor or
other equipment within the enclosure due to improper installation.
6. Attach the power, video and touch screen cables (if this is a –TS unit) to the
side of the monitor.
5
Section
and
lock
nuts
Figure 2: Panel Mount Drawing
Mounting
Instructions
supplied
with
the
monitor.
