Touch Screen Driver Installation:
If your displays is fitted with the optional touch screen interface, the following section will outline the installa-
tion and set up. If the unit does not have a touch screen your configuration is complete.
To Install The Touch Screen Driver:
Things you will need to know or have to install the Touch Driver.
•
What Operating System you are using. Windows 2000
•
What Serial Port you are connected to. Com 1
•
The CD ROM or Floppy disk included with the system.
Installing The Touch Screen Driver: Windows 2000
Insert the 3 1/2" Floppy Marked Windows 95/98/2000 Touch Driver
Click "Start"
Run
Browse (A or B Drive)
Click "Start"
Run
Browse (Go to the folder where you installed the drivers)
Select The Setup.exe - The RUN
The installation utility will now run.
Click Next
Click Yes To accept the license agreement
Select The COM Port that the touch screen is connected to
Select Next
The driver will now start to install
Select YES - To continue
Select Finish
Remove the floppy disk and restart the system. Select YES to restart
Touch each of the 3 targets as directed
When the system restarts touch each of the 3 targets as directed to calibrate (align) the touch screen.
If your system does not respond to your calibration touches, press the Esc key on the keyboard. Go to the
ELO icon under the Windows Control Panel. Select the correct Com Port, then Restart the computer. Select
the ELO icon again and select Align and calibrate the touch screen then touch each of the 3 targets as they
are displayed.
You are now ready to use your touch screen.
NOTE: The touch screen calibration information is maintained in the computer. If you change computers,
you will need to reinstall the touch screen driver software and recalibrate.
If for any reason the touch screen performance is unsatisfactory, you can recalibrate at any time. This is
done from the ELO icon under the Windows control panel
Touch Screen Driver Installation Windows 2000
Select the folder for Win2000
Select XXXXX.EXE
UnZip the XXXXX.exe file
Com 2
[Where XXXXX is the 98 or 2000 File Name. This will
create a folder and expand and copy the necessary files
into that folder.]
