Touch Screen Driver Installation:
If your display is fitted with the optional touch screen interface, the following section will outline installation
and set up. If the unit does not have a touch screen, your configuration is complete.
To Install The Touch Screen Driver:
Things you will need to know or have to install the Touch Driver.
•
What Operating System you are using. Windows NT 4.0
•
What Serial Port you are connected to. Com 1
•
The type of touch screen.
•
The CD ROM or Floppy disk included with the system.
Installing The Touch Screen Driver: Windows NT 4.0
Insert the 3 1/2" Floppy Marked Windows NT 4.0 Touch Driver
Click "Start"
Run
Browse (A Drive)
Click "Start"
Run
Browse (Open the folder where you installed the drivers)
Select The Setup.exe - Then Run the the installation utility.
Restart the computer - When the system restarts you will will be prompted to calibrate the touch screen.
Touch each of the 3 targets as directed. If your system does not respond to your calibration touches, then
you have probably selected the wrong Com port. If so, press the Esc key on the keyboard. Go to the ELO
icon under Windows Control Panel. Select the correct Com Port, and Restart the computer. Once restarted,
select the ELO icon under Windows Control Panel, and select calibrate, then touch each of the 3 targets as
they are displayed.
You are now ready to use your touch screen.
NOTE: The touch screen calibration information is maintained in the computer. If you change computers,
you will need to reinstall the touch screen driver software and recalibrate.
If for any reason the touch screen performance is unsatisfactory, you can recalibrate at any time. This is
done from the ELO icon under the Windows control panel
Touch Screen Driver Installation Windows NT 4.0
Smartset
Select the folder for WinNT
Select XXXXX.EXE
UnZip the XXXXX.exe file
Select Next
Select Yes - To the license agreement
Select Next - To the default installation folder
Com 2
[Where XXXXX is the File Name. This will create a
folder and expand and copy the necessary files into
that folder.]
Select Next - For Single Monitor installation
Select the Com Port and Next
Select Finish to Restart the system
