Quick Setup Guide FPM-150 and FPM-150-TS Page 2 of 2
Adjusting The LCD:
The FPM-150 series displays incorporate a microprocessor-based converter card, which converts analog
video to what is termed digital RGB (Red, Green, Blue) for the LCD. This same microprocessor will auto-
matically adjust the picture to the center of the LCD and resize to full screen.
Adjusting The LCD Video Settings:
•
Select "Menu" from rear membrane keypad. This will bring up the OSM (On Screen Menu)
•
"AutoAdjust" is the first selection.
•
Press the "+" or "-" key
The screen will go out temporarily. After the unit has completed adjusting, press the menu key to exit the
OSM. This will save the settings.
The Windows desktop should be centered, full screen, and stable. The unit is now ready for installation
of the touch screen driver installation, if the unit is so equipped. See the Touch Screen Driver Quick
Start Guide.
Industrial LCD Display
