Press MENU key to bring up the OSD. Press UP/DOWN key to move between the 5 primary
screen functions. Press the Select button at Picture, to select it. Press the UP/DOWN key, you
can now move between functions and press Select to adjust the value of each item with the
key. Press MENU key to return previous state and press MENU key twice to exit OSD.
BRIGHTNESS Function of adjusting main screen brightness.
CONTRAST
FREQUENCY Function of adjusting main screen sampling clock frequency.
PHASE
H POSITION
V POSITION
ADVANCED
Press MENU key to bring up the OSD. Press UP/DOWN key, to move between the 5 primary
screen functions. Press the Select button at Advanced, to select it. Press the UP/DOWN key, you
can now move between functions and press Select to adjust the value of each item with the
key. Press MENU key to return previous state and press MENU key twice to exit OSD.
Color Temp
User RED
User BLUE
User GREEN
Gamma
COLOR WARP
Press MENU key to bring up the OSD. Press UP/DOWN key to move between the 5 primary
screen functions. Press the Select button at Color Warp, to select it. Press the UP/DOWN key,
you can now move between functions and press Select to adjust the value of each item with the
key. Press MENU key to return previous state and press MENU key twice to exit OSD
Color Warp
Mode
Custom Center Function of adjusting color warp on center.
Custom range Function of adjusting range on color warp.
Saturation
Custom hue
OPTIONS
Press MENU key to bring up the OSD. Press UP/DOWN key to move between the 5 primary
screen functions. Press the Select button at Options, to select it. Press the UP/DOWN key, you
can now move between functions and press Select to adjust the value of each item with the
key. Press MENU key to return previous state and press MENU key twice to exit OSD
OSD V Pos
OSD H Pos
OSD
UTILITIES
Press MENU key to bring up the OSD. Press UP/DOWN key to move between the 5 primary
screen functions. Press the Select button at Utilities, to select it. Press the UP/DOWN key, you
can now move between functions and press Select to adjust the value of each item with the
key. Press MENU key to return previous state and press MENU key twice to exit OSD
OSD Timeout
OSD Bkground Function of adjusting at transparency on main screen to OSD image.
Auto Adjust
Factory Reset Function of resetting all value on OSD.
Power On Time Function of indicating system on time.
Bklight OnTime Function of indicating panel on time.
NOTE: The OSD membrane has a Source button. This button is used to select other inputs to the
LCD, Such as DVI, S-Video, or NTSC.
Function of adjusting main screen contrast.
Function of adjusting main screen sampling clock phase.
Function of adjusting the horizontal position of main screen.
Function of adjusting the vertical position of main screen.
Function of setup of main color. (Bluish, Normal, Reddish)
Function of adjusting value of RED.
Function of adjusting value of BLUE.
Function of adjusting value of GREEN.
Function of adjusting value of color ratio.
Function of adjusting curve on main screen.
Function of selecting curve on main screen.
Function of adjusting saturation warp on center.
Function of adjusting the tone of color.
Function of adjusting the vertical position of OSD image.
Function of adjusting the horizontal position of OSD image.
Function of moving OSD image quickly.
Function of adjusting OSD disappear time.
Function of finding optimized main screen automatically.
