Automation Direct FPM-150 User Manual page 47

Green LED not lit
Display image is not
properly sized
Image will not adjust
Slight distortion in text or
Graphics
Display is present but
"bars" Appear or roll
across screen
Vertical shaded bars on
Screen image
Image is not stable.
Check for proper power and power connections
Press the "Select" button to Auto Adjust the display
Adjust the Vertical and Horizontal size controls via the OSD.
(Reference setup adjustments)
Ensure that a supported mode is selected on the display card
or system being used. Consult the display card or system
manual for proper video.
Video timing outside of range.
Use the on-screen menu to adjust the Clock Setting.
Make sure timing is within VESA standard.
Not working in native resolution.
Ground loop problem between computer and display
Interference from adjacent equipment.
Horizontal size not properly adjusted. Adjust horizontal size
Monitor has incorrect or bad sync signals..
Check for proper video cable installation.
Replace suspected faulty cable.
Check to ensure that video source is within the display's
operating range.
