Page 1
3009161-Rev B 1 - I N C L U D E S I T E M S 3 - 1 6 Parts & Maintenance Manual HR 4600 Turbo Rotary Mower ™ 67862 – Kubota V1505-TE, 2WD 67863 – Kubota V1505-TE, 4WD...
To Order Parts 1. Write your full name and complete address on the 5. Send or bring the order to an authorized Textron Turf order. Care And Specialty Products Dealer. 2. Explain where and how to make shipment. 6. Inspect all shipments on receipt. If any parts are dam- aged or missing, file a claim with the carrier before 3.
789012 Valve, Lift Includes Items 2 and 3 345678 • Handle Serviced part included with Item 2 Non serviced part included with Item 2 • Seal Kit Indicates a part painted Jacobsen Orange 901234.6 Screw, 1/4-20 x 2” Hex Head...
SAFETY SAFETY OPERATING SAFETY ______________________________________________________ WARNING EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS. Familiarize yourself with the location and proper use of all controls. Inexperienced operator’s should receive instruction from someone familiar with the equipment before being allowed to operate the machine. Safety is dependent upon the awareness, concern and Never disconnect or bypass any switch.
SAFETY IMPORTANT SAFETY NOTES ________________________________________________ This safety alert symbol is used to alert you to potential hazards. DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.
SPECIFICATIONS SPECIFICATIONS PRODUCT IDENTIFICATION_________________________________________________ 67862 ......HR 4600 Turbo, 2 Wheel Drive Always provide the serial number of the unit when ordering replacement parts or requesting service information. 67863 ......HR 4600 Turbo, 4 Wheel Drive Serial Number ....An identification plate, like the one...
ADJUSTMENTS ADJUSTMENTS GENERAL________________________________________________________________ Replace, do not adjust, worn or damaged components. WARNING Do not wear jewelry or loose fitting clothing when making adjustments or repairs. To prevent injury, lower implements to the ground, disengage all drives, engage parking brake, stop engine and remove key from ignition switch before making any CAUTION adjustments or performing maintenance.
ADJUSTMENTS BRAKES _________________________________________________________________ Adjust brakes after replacing or servicing brake assembly, or if pedal travel becomes excessive. Loosen adjusting nuts (C). Adjust cable so brake pedal has 1 in. (25 mm) free (E) before brake pads engage brake disk. travel Tighten nut (C) to lock adjustment in place.
ADJUSTMENTS FORWARD / REVERSE SPEED ______________________________________________ Forward and reverse speeds are adjusted at the traction Start engine and check reverse travel speed with pedal. Set forward speed before adjusting reverse. engine at full throttle. Reverse speed should measure 5-6 mph (8-9 kph) To adjust forward speed: Stop engine.
ADJUSTMENTS CUTTING HEIGHT _________________________________________________________ Cutting height for decks can be adjusted from 1 to 4 in. (25-100 mm) in 1/2 in. (13 mm) increments. Actual cutting height may vary somewhat from the heights given depending on turf conditions and other factors. 1 1/2 Note: When cutting undulating areas, lower cutting heights may cause scalping.
ADJUSTMENTS STEERING TOE-IN _________________________________________________________ Turn wheels to straight ahead position. Loosen jam nuts (J) on both sides of tie rod (M). Turn tie rod (M) to provide proper toe-in. Toe-in must not exceed +1/16” (1.5 mm) (K). Retighten jam nuts. After adjusting tie rod, adjust steering cylinder by threading the rod (N in or out of ball joint so spindle arm (L) clears the stop on the axle by 1/32 to 3/32in.
ADJUSTMENTS 3.10 TORQUE SPECIFICATION ___________________________________________________ CAUTION All torque values included in these charts are approximate and are for reference only. Use of these torque values is at your sole risk. Textron Turf Care And Specialty Products is not responsible for any loss, claim, or damage arising from the use of these charts.
MAINTENANCE MAINTENANCE GENERAL________________________________________________________________ Keep all moving parts properly adjusted and lubri- WARNING cated. Replace worn or damaged parts before operating Before you clean, adjust, or repair this equipment, the machine. disengage all drives, lower implements to the ground, engage parking brake, stop engine and remove key from Keep all fluids at their proper levels.
MAINTENANCE AIR FILTER _______________________________________________________________ Check the service indicator daily. If red band appears in the Reassemble cap making sure it seals completely window (B) replace the element. around the filter housing. Dust evacuator must be facing down. Do not remove the element for inspection or cleaning. Check all hoses and air ducts.
MAINTENANCE BATTERY ________________________________________________________________ Make absolutely certain the ignition switch is “Off” and the Verify battery polarity before connecting or disconnecting the battery cables. key has been removed before servicing the battery. When installing the battery, always assemble the RED, CAUTION positive (+) battery cable first and the ground, BLACK, negative (-) cable last.
MAINTENANCE 4.10 MUFFLER AND EXHAUST___________________________________________________ To protect from carbon monoxide poisoning, inspect the WARNING complete exhaust system regularly and always replace a defective muffler. Exhaust fumes contain carbon monoxide that is toxic and can be fatal when inhaled. If you notice a change in the color or sound of the exhaust, stop the engine immediately.
Page 18
MAINTENANCE 4.13 HYDRAULIC FILTERS ______________________________________________________ The hydraulic system is protected by two 10 micron filters; a Check hydraulic oil level in reservoir and fill to full mark charge filter (B) and return line filter (A). Flow though the on dipstick. filters is monitored during operation.
MAINTENANCE 4.15 RADIATOR _______________________________________________________________ Use a blow gun to clean the radiator and oil cooler fins. WARNING Note: A sliding panel located under the frame can be loosened and pulled back to allow dirt and debris to fall To prevent serious bodily injury from hot coolant or though frame .
MAINTENANCE 4.18 WHEEL MOUNTING PROCEDURE ____________________________________________ Remove dirt, grease and oil from stud thread. Do not lubricate threads. WARNING Position wheel on hub and inspect to insure full contact between mounting surface of wheel and hub or brake Make sure the tractor is parked on a solid and level surface.
MAINTENANCE 4.21 SHARPENING BLADES _____________________________________________________ 1. Place a wooden block between the blade and mower housing to stop the blade from moving. To remove blade on left wing and center decks, turn screw holding blade counterclockwise. To remove blade on Maximum right hand deck, turn screw holding blade clockwise.
MAINTENANCE 4.22 STORAGE________________________________________________________________ Wash the tractor thoroughly and lubricate. Repair and After Storage paint damaged or exposed metal. Check and reinstall battery Inspect the tractor, tighten all hardware, replace worn Check or service fuel filter and air cleaner. or damaged components. Check the radiator coolant level.
TROUBLESHOOTING TROUBLESHOOTING GENERAL ________________________________________________________________ The troubleshootijng chart below lists basic problems that may occur during start-up and operation. For more detailed information regarding the hydraulic and electrical systems contact your area Textron Turf Care And Specialty Products dealer. Symptoms Possible Causes Action Section Ref.
TROUBLESHOOTING CONTROLLER LAMPS _____________________________________________________ The controller is a solid state device that monitors and indicates an active circuit and will turn an input lamp on, an controls electrical functions. The controller receives input open switch indicates an inactive circuit and will turn a lamp signals from various switches and sensors throughout the off.
MAINTENANCE & LUBRICATION CHARTS MAINTENANCE & LUBRICATION CHARTS GENERAL ________________________________________________________________ Lubricate with grease that meets or exceeds NLGI WARNING Grade 2 LB specifications. Apply grease with a manual grease gun and fill slowly until grease begins to seep Before you clean, adjust, or repair this equipment, out.
Page 27
PARTS LIST PARTS LIST TABLE OF CONTENTS______________________________________________________ 1.1 ..Decals ..............28 26.1..Lift Hydraulics ........... 68 2.1 ..Hood ..............30 27.1..Hydraulic Clamps..........70 3.1 ..Seat Pan ............. 32 28.1..Front Wheel Motor and Deck Motor Drains ..71 4.1 ..
HR-4600 Serial No. All 1.1 Decals OPERATION READ MANUAL BEFOR OPERATING. REPLACEMENT MANUAL AVAILABLE FROM: TEXTRON TURF CARE AND SPECIALTY STARTING THE TRACTOR CONTROLLER FUNCTIONS BY LAMP NUMBER PRODUCTS, RACINE WI. LAMP SIGNAL CIRCUIT THE FOLLOWING LAMPS MUST BE ON WHEN THE 3..INPUT...PROGRAM ACTIVE (INDICATES CONTROLLER To Start To Stop/Park...
Page 29
Decal, Hydraulic Oil 3008576 Decal, Diesel Fuel 3010226 Decal, Instrument Panel 3008327 Decal, 4WD 4WD Only 3007505 Decal, Jacobsen 3007514 Decal, Textron 3007750 Decal, Left Side Blue Stripe 3007751 Decal, Right Side Blue Stripe 3009164 Decal, HR 4600 TURBO > Change from previous revision...
Page 31
HR-4600 Item Part No. Qty. Description Serial Numbers/Notes 1004981 Hood Assembly Includes Items 16 ~ 20 on Illustration 1.1 3007549 • Foam, Front 3007550 • Foam, Right Side 3007551 • Foam, Left Side 3007552 • Foam, Top 3007661 • Seal, Rear 557620 •...
Page 51
HR-4600 Item Part No. Qty. Description Serial Numbers/Notes 1 1002857 Engine, Kubota V1505-TE 557759 • Engine Oil Filter 366879 Isolator, Engine 1003239 Front Engine Mount 1003260 Left Side Engine Mount 1003261 Right Side Engine Mount 164102 Cable, Throttle 558021 • Clip 303962 •...
HR-4600 Serial No. All 13.1 Engine Exhaust Item Part No. Qty. Description Serial Numbers/Notes 1002931 Muffler 1004598 Tailpipe 363586 Screw, M8-1.25 x 20mm Hex Head 452006 Flat Washer, 5/16 363485 Lockwasher, M10 Heavy 362263 Bolt, M10-1.25 x 25mm Hex Head 446136 Lockwasher, 5/16 Heavy 553020...
HR-4600 Serial No. All 15.1 Wing Lift Arms Part of Frame...
Page 55
HR-4600 Item Part No. Qty. Description Serial Numbers/Notes 1003006 Wing Lift Frame 2809794 • Bushing 1003531 Right Wing Lift Arm 1003532 Left Wing Lift Arm 342049 • Bushing 2 Per Lift Arm 3006882 Pin, Lift Arm Pivot 3009078 Cylinder, Wing Lift 5003664 •...
HR-4600 Serial No. 67837-1601 and Up 20.1 2WD Traction Hydraulics Serial No. 67839-1601 and Up Item Part No. Qty. Description Serial Numbers/Notes 1003439 Hose, Pump To Upper Traction Tube 339994 Adapter, Straight 339999 Adapter, Straight 1004445 Hose, Pump To Lower Traction Tee 340339 Tee, Union 1003810...
HR-4600 Serial No. 67838-1601 and Up 21.1 4WD Traction Hydraulics Serial No. 67840-1601 and Up Item Part No. Qty. Description Serial Numbers/Notes 1003440 Hose, Pump To Reverse 4WD Tee 339994 Adapter, Straight 339999 Adapter, Straight 1003813 Tube, Reverse 4WD Tee 1003439 Hose, Pump To Forward 4WD Tee 1003814...
HR-4600 Serial No. All 22.1 Charge Pressure and Steering Hydraulics To Lift Valve P Port From Gear Pump To Lift Valve SO Port To Steering Cylinder Item Part No. Qty. Description Serial Numbers/Notes 1003461 Hose, Charge Pressure Inlet 364945 Fitting, Diagnostic 339998 Adapter, Straight 365466...
HR-4600 Serial No. All 28.1 Front Wheel Motor and Deck Motor Drains To Center Deck Motor Drain To RightWing Deck Motor Drain To LeftWing Deck Motor Drain Item Part No. Qty. Description Serial Numbers/Notes 340215 Adapter, Bulkhead Tee 340375 Adapter, 90° 1004132 Hose, Lift Bulkhead to Drain Tube Hose, Center Deck Motor Drain...
HR-4600 Serial No. All 29.1 Wing Deck Control Valves To Gear Pump To Right Wing Deck Motors To Gear Pump Direction of Flow Left Wing Deck To Left Wing Deck Motors Direction of Flow Right Wing Deck Item Part No. Qty.
HR-4600 Serial No. All 30.1 Center Deck Control Valve To Gear Pump Direction of Flow Center Deck Item Part No. Qty. Description Serial Numbers/Notes 340264 Adapter, Tee 452004 Flat Washer, 1/4 3008508 Bracket, Valve Mount 446128 Lockwasher, 1/4 443102 Nut, 1/4-20 Hex 400122 Screw, 1/4-20 x 2-1/4”...
HR-4600 Serial No. All 31.1 Wing Deck Hydraulics Left Deck Shown To Bulkhead Adapter To Deck Control Valve Item Part No. Qty. Description Serial Numbers/Notes 340055 Adapter, 90° 1004113 Hose, Deck Valve to Inside Motor REFERENCE A, See 29.1 1004114 Hose, Inside Motor to Outside Motor 1004115 Hose, Deck Valve to Outside Motor...
HR-4600 Serial No. 32.1 Center Deck To Deck Control Valve To Traction Pump Case Drain Tube Item Part No. Qty. Description Serial Numbers/Notes 340055 Adapter, 90″ 1004642 Hose, Deck Valve to Left Motor REFERENCE C, See 30.1 1004643 Hose, Deck Valve to Right Motor 1004644 Hose, Left Motor to Right Motor REFERENCE D, See 30.1...
HR-4600 Serial No. All 33.1 Wire Harness and Controller Box P/O 21 P/O 14 3 AMP 20 AMP To (-) 25 AMP Post on Battery 3 AMP Fuse Locations A - Headlight B - Lift Arm Limit Switch C - Fuel Level Sender/ Instrument Panel D - Seat Switch E - Oil Float Switch F - Glow Plugs...
HR-4600 Serial No. All 35.1 4WD Valve Part Number 1002622 Top View Front View Item Part No. Qty. Description Serial Numbers/Notes 5001354 Coil 5003096 Solenoid Valve 5003578 • Solenoid Valve Seal Kit 5003121 Solenoid Valve 5003554 • Solenoid Valve Seal Kit 5003097 Pilot Operated 2-Way 5003580...
HR-4600 Serial No. All 36.1 Steering Valve Part Number 1003458...
Page 81
HR-4600 Item Part No. Qty. Description Serial Numbers/Notes 443108 Locknut, 5/16-18 Center Port Cover Seal, O-Ring Seal, O-RIng Seal, O-RIng 443828 Nut, 5/16-18 Hex Jam Special Bolt Port Manifold Spring, Port Side Hex Drive A and E Needle Roller 503398 Valve Ring 503398 Valve Plate...
HR-4600 Serial No. All 37.1 Front Wheel Motor Part Number 1001757 18 19 Included In Seal Kit 557651 Included In Seal Kit 5002111 Item Part No. Qty. Description Serial Numbers/Notes 558066 Screw, Torx 5002110 Front Retainer 558063 Shaft and Bearing Kit 554779 Nut, Hex 554780...
HR-4600 Serial No. 67838-1601 and Up 38.1 Rear Wheel Motor Serial No. 67840-1601 and Up Part Number 5003218 Item Part No. Qty. Description Serial Numbers/Notes Seal Exclusion Seal, 3” I.D. Back Up Ring Shaft Seal 5003384 Shaft and Bearing Kit 554780 554779 Hex Nut...
HR-4600 Serial No. All 39.1 Brake Assemblies Item Part No. Qty. Description Serial Numbers/Notes 340603 Bracket, Brake Mounting 503308 Disk Brake, R.H. 503309 Disk Brake, L.H. 590259 • Nut, 3/8-24 549441 • V-Plate 503306 • Cam Lever Used on 503308 Only 502517 •...
HR-4600 Serial No. All 40.1 Deck Valve Part Number 1004137 Item Part No. Qty. Description Serial Numbers/Notes Manifold 5003508 Coil 5003747 Solenoid Valve 5002540 Seal Kit, Deck Valve > Change from previous revision...
HR-4600 Serial No. All 41.1 ROPS Optional Kit 67844 Item Part No. Qty. Description Serial Numbers/Notes 555892 Seat Belt Assy. 400374 Screw, 7/17-20 x 1-1/2” Hex Hd 452010 Washer, 7/16 Flat, Wide 446148 Lockwasher, 7/16 Hvy 400370 Screw, 7/16-20 x 1” Hex Hd 5000465 Screw, GR8, Hex Cap 446154...
HR-4600 Serial No. All 42.1 Decals, Deck 1 1/2 2 1/2 2 1/2 3 1/2 COUNTER CLOCKWISE BLADE ROTATION ON THE DECK ONLY - BLADE BOLTS ARE L.H. THREAD COUNTER CLOCKWISE ROTATION L.H. THREAD Left Wing Deck Right Wing Deck 1-1/2 NO STEP 2-1/2...
HR-4600 Serial No. All 46.1 Caster Wheels Part Number 1003999 Item Part No. Qty. Description Serial Numbers/Notes 551440 End Cap 551439 Seal, Grease 551437 Stop Washer 551438 Roller Bearing 471218 Grease Fitting, 45° 360111 Valve, Inflation 5003066 Wheel Rim 551436 Tire, 9 x 3.5 - 4 >...
Fluids and Compounds Hydraulic Fluid* 5001405 Two 2-1/2 Gallon Container of ISO VG68 Oil 5001404 One 5 Gallon Pail of ISO VG68 Oil 502696 Two 2-1/2 Gallon Container of 10W30 Oil 502693 One 5 Gallon Pail of 10W30 Oil 503409 Two 2-1/2 Gallon Container of ATF Fluid 503407 One 5 Gallon Pail of ATF Fluid...
HR-4600 Serial No. All 47.1 Electrical Schematic Components K-20 Bn/Ye A B C D E F G H Bn/Ye Battery Og/Wh Bn/Ye CB-1 Circuit Breaker 3 Amp Fuse 20 Amp Fuse SW-5 25 Amp Fuse 3 Amp Fuse Glow Plug Relay Fuel Solenoid 4WD Solenoid Starter Relay...
Page 97
HR-4600 Components SW-19B Temp Gauge Gy/Pu Fuel Gauge Hour Meter Fuel Sender Gn/Rd Light Gauge Temp Sender K-15 Alternator Gn/Wh Horn Gy/Pu Gy/Ye Controller U-10 Joystick K-16 K-13 K-10 Gy/Pu Gy/Rd Colors K-17 LG/Bk K-21 Black Brown Gy/Pu Gy/Bu LG/Tn Blue Dark Blue K-11...
HR-4600 Serial No. All 48.1 Hydraulic Schematic Reverse Diag. Valve 3625 psi 2.81 ci Gear 3000 .5 ci .5 ci .5 ci .5 ci Pump 3625 psi Traction Pump Drain Supply .031 .028 285 psi Displacement Forward Control Diag 0.43 ci 0.43 ci Strg.
LF 3400/ LF 3800 Serial No. All 49.1 O-Ring Chart O-Ring Face O-Ring Boss O-Ring Face O-Ring Face O-Ring Boss O-Ring Boss Seal Size Dash Size Seal Size Seal Size Dash Size Dash Size W-X-Y W-X-Y W-X-Y O-Ring Face O-Ring Not O-Ring Face O-Ring Boss O-Ring Face...
