Qualcast XSZ51A-SD Assembly Manual

51cm petrol self propelled lawnmower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Qualcast
51cm Petrol Self Propelled
Lawnmower
Assembly Manual
Important
- Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from your
lawnmower, ensuring it is assembled correctly and safely.
XSZ51A-SD
Technical Support & Parts
0845 034 2279
www.gardenservicecentre.co.uk
Scan to watch
our instruction
videos!
Oct 2013 Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XSZ51A-SD and is the answer not in the manual?

Questions and answers

MR V J HARRISON
June 5, 2025

What diameter pull chord should be used to start a xsz51c qualcast mower?

0

Subscribe to Our Youtube Channel

Related Manuals for Qualcast XSZ51A-SD

Summary of Contents for Qualcast XSZ51A-SD

  • Page 1 Qualcast 51cm Petrol Self Propelled Lawnmower Assembly Manual XSZ51A-SD Technical Support & Parts 0845 034 2279 www.gardenservicecentre.co.uk Scan to watch our instruction videos! Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your lawnmower, ensuring it is assembled correctly and safely.
  • Page 2 Contents Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols Safety Information .............................3 Warning Symbols ............................3 The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the lawnmower. General Safety ..............................3 This symbol indicates there is a danger of serious personal injury or death if you do not observe the Personal Safety ............................3...
  • Page 3 In the Box Assembly Tools Parts Preparing to assemble the lawnmower Main mower deck Plastic mulching Quick release 2pcs Socket spanner for (with upper handle) plug 1pc (inside the spark plug 1pc WARNING! mower) Grass collecting - Always take care when removing the packaging to prevent damage to you or to the lawnmower. Lower handle with - This item requires a two person lift to remove from the packaging.
  • Page 4 Assembly Assembly Step 3 Step 5 Lift the upper handle, and lock in place using the quick release lever and tensioning bolts that are Ensure that the cables clips supplied are used to fix the cable to the lower handle attached to the handle.
  • Page 5 Qualcast 51cm Petrol Self Propelled Lawnmower Operation and Maintenance Manual XSZ51A-SD Technical Support & Parts 0845 034 2279 www.gardenservicecentre.co.uk Scan to watch our instruction videos! Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your lawnmower, ensuring it is assembled correctly and safely.

  • Page 6: Table Of Contents

    Replacing Cutting Blade ..........................17 Do not run the engine in closed or poorly ventilated areas. List of Consumable Qualcast Parts ......................18 Troubleshooting ............................19 Blade continues to rotate for a period after the machine is switched off. Do not touch the blade until all the machine components have been stopped completely.

  • Page 7: Safety Information

    Safety Information Safety Information Important - Please read these instructions fully before operating or maintaining Important - Please read these instructions fully before operating or maintaining General Safety Operation Safety WARNING! WARNING! - Keep this operating and maintenance manual in a safe place for reference at a later date. - Do not operate the engine in a confined space where dangerous carbon monoxide fumes can collect.

  • Page 8: Maintenance And Storage Safety

    Safety Information Preparing to Operate the Lawnmower Important - Please read these instructions fully before operating or maintaining Step 1 - Filling with Engine Oil Maintenance and Storage IMPORTANT! - The following procedures and adjustments must be performed before the engine is started. Do not WARNING! attempt to make any of these adjustments while the engine is running.

  • Page 9: Step 2 - Filling With Engine Fuel

    NOTE! Never use the lowest cutting height for the first cut of the season or in drought conditions. NOTE! The Qualcast 51cm Self Drive Lawnmower has a maximum fuel capacity of 1000ml. Only about one thirds of the grass height should be cut.

  • Page 10: Step 3 - Mowing

    Operating the Lawnmower Operating the Lawnmower Step 2 - Starting the Engine (continued) Step 2 - Starting the Engine (continued) Failure to start If the engine won’t start after you have operated the starter several times, the engine may be flooded with excess fuel.

  • Page 11: Step 4 - Emptying The Grass Bag

    Operating the Lawnmower Operating the Lawnmower Step 3 - Mowing (continued) Step 3 - Mowing (continued) Mowing with side discharge When using side discharge to throw grass, remove the grass collection bag(3a) and insert the Mowing with mulching mulching plug (3b). When mulching, remove the collection grass bag(3a), and put the plastic mulching plug into the - Raise the side safety flap with one hand, and hook the side discharge chute onto the mower rear discharge chute(3b).Then release the flap, it will close back to cover the mulching plug.

  • Page 12: Maintenance

    Maintenance Maintenance Storing the Lawnmower for Short Periods Maintenance Schedule After mowing please follow the below actions prior to placing the lawnmower in storage. • Allow the engine to fully cool. WARNING! • Ensure the grass bag is empty. - Before you tip the lawn mower onto its side, completely empty the fuel tank using a petrol suction pump.

  • Page 13: Changing The Oil

    Maintenance Maintenance Cleaning or Replacing Air Filter Changing the Oil Tilt the lawnmower towards the oil filler, have a container ready to catch the oil and remove the dipstick. Once the oil has been emptied, wipe clean any spillages. WARNING! Never run the engine without the air filter element installed. Refill with 500ml SAE30 oil or equivalent ie SAE5W/30, SAE10W/30).

  • Page 14: List Of Consumable Qualcast Parts

    Spare blades and other parts can be purchased in store or via www.gardenservicecentre.co.uk - Spark plug is defective - Replace spark plug - Fuel tank is empty - Refill with fuel List of Consumable Qualcast Parts - Engine may be flooded - remove plug and dry, see page 11 RJ19LMC...

  • Page 15: Technical Data

    Technical Data Guarantee Technical Data Table Property Value Dear Customer, Engine type Single cylinder 4-stroke In the unlikely event that your device develops a fault, please contact our customer service Engine displacement 190cc department on the telephone number shown below. Engine max.

  • Page 16: Declaration Of Conformity

    We hereby certify that the product stipulated above complies with all the relevant provisions of the following EC new approach directives. This declaration of conformity is issued under the sole responsibility of the manufacturer Type of Product: Petrol lawn mower Model Number: XSZ51A-SD Cat / Article Number: 7071238 Product Description:...
