Summary of Contents for Blaupunkt oslobludab
- Page 2 Warning /Troubleshooting/Specifications.............. Introduction Thank you for buying the Blaupunkt Digital Radio.The following instructions will assist you in operating all the features of this product. You may already be familiar with using a similar unit, but please take the time to read the instructions relevant for your model.
-
Page 3: Safety Instructions
Safety Instructions Please ensure that you read all of the safety instructions before using this unit. Safety Considerations Position the power cable and other connected cables so that they are not likely to be walked on, pinched or where items can be placed on or against them. Do not use the unit in humid or damp conditions. -
Page 4: Your Dab
Your DAB+ Radios Top view 1.STANDBY Press to start,press to go to STANDBY mode. 2.SCAN Press to scan radio channels. 3.MODE Press to select DAB or FM radio and AUX input. 4.MENU Press to view channel/time/ date/RDS. 5.ALARMS 9 10 11 12 Press to setup alarm . - Page 5 What Is DAB+ Digital DAB+ was developed in Europe by a consortium of broadcasters and manufactures. DAB+ uses digital compression techniques to transform the source material, i.e. music and speech,into better quality audio. Interference free reception Analogue systems suffer from an effect called "multipath distortion". This is caused because waves do not behave in a orderly fashion, but bounce and reflect off buildings etc.
-
Page 6: Getting Started
Getting Started Carefully remove your DAB+ receiver form the box.(we recommend you keep the package for future reference.) 1.Connect the power 2.Exetend the telescopic aerial Connect the power adaptor provided Extend the telescopic aerial for the to the unit and then connect to you wall best reception possible outlet and turn on the power. -
Page 7: Getting Started
Getting Started 4.Connecting headphones Connect your headphones to the 3.5mm headphone socket on the back of the unit as shown above. 5. Changing the volume Adjust the volume level by pressing the VOL+ button to increase the volume or decrease the volume by pressing the VOL- button. -
Page 8: Operating Instructions
Operating Instructions Playing your DAB+ radio 1.Please make sure your unit is switched on. 2.Press the MODE button to select the DAB+ radio mode. 3.Press the and buttons to scroll through the stations in the station list. < < << 4.To scan for all new stations or to rescan for weak stations, press the SCAN button and the radio will scan and store all available stations. - Page 9 Operating Instructions <DRC> Dynamic range control(DRC) adds or removes a degree of compensation for the differences in the dynamic range between radio stations. 1.Press the MENU button to access the main menu. 2.Press the and button until DRC is displayed. <<...
-
Page 10: Alarm Setting
Operating Instructions Playing your FM radio To switch f om DAB+ to FM , press the MODE button to select the FM mode. Auto tune 1.Press the SCAN button to automatically search for the next available frequency. 2.If you find the reception is poor, use the Manual tuning option to fine tune station or make sure your aerial is adjusted accordingly. -
Page 11: Operating Instructions
Operating Instructions Snooze function The alarm will stop sounding and will sound again after a 9 minutes period. Brightness function Press the SNOOZE button to cycle through the 10 light setting. AUX connection The radio has an auxiliary input. This can be used to connect an external source such as MP3 players and other audio sources by using the included 3.5mm cable. -
Page 12: Technical Specification
Warning/Troubleshooting/Technical Specifications If a fault occurs, first check the points listed below before taking the set for repair. If you are unable to remedy a problem by following these hints ,consult you retailer or service centre. WARNING: Under no circumstances should you try to repair the set yourself ,as this would void your guarantee. - Page 13 Warranty Please keep your receipt as proof of purchase. This products is warranted for any defect in materials or workmanship for 1year after the original date of purchase. This product is for normal domestic & office use only. This warranty does not cover damage from misuse or neglect, accidental damage, vermin infestation,excessive voltages such us lightning or power surges or any alternation that affects the performance or reliability of the product.
