Installation of DSL router DrayTek Vigor 2600 VGST
Important Notice:
In case of operating system OS Windows
2000 or XP it is recommended to install
the most recent Service packs. For further
information, please contact Microsoft
Slovensko at 0850 111 300 or our Technical
Support Centre at 0900 211 111.
1. Installation procedure of network
set-up on your PC
In order to be able to work with DSL
router Vigor 2600 VGST, the network card
properties need to be set up properly on
your PC. The most convenient solution
is to set up TCP/IP protocol properties in
a manner enabling to acquire the IP address
from the DHCP server, i.e. your Vigor 2600
VGST router. Also, it is necessary to ensure
when setting the system that the DNS server
address is requested automatically.
You can set up network on your PC taking the
following steps:
1. Click on "Štart" icon.
2. Select item „Nastavenia".
3. Select item „Ovládací panel".
4. Click on the icon "Sieťové pripojenia".
5. Right-click on the icon "Local Area
Connection" and choose "Vlastnosti".
14
> Self-Installation Guide
6. Click on "Internet Protocol (TCP/IP)" and
then "Vlastnosti".
7. Select "Získať adresu IP automaticky".
8. Select "Získať adresu servera DNS
automaticky".
9. Click on "OK".
Connecting DSL router DrayTek Vigor
2600 VGST to your PC
1. Plug the LAN UTP cable (blue) into the
network card connector on your PC, the
other end of the cable plug into one of the
4 connectors (P1 through P4), e.g. P1 on the
back panel of the router Vigor 2600 VGST.
If you use more than 1 PC, connect another
computer to the P2 connector, third one to
P3 and fourth one to P4 connector.
2. Plug the adapter into power supply (230 V)
and plug the adapter cable to the DSL
router connecter labelled PWR and then
change the switch to "ON" position
3. Now, your DSL router Vigor 2600 VGST is
on and ready for selected configuration
over any PC in your network; you can verify
the status by a flashing ACT diode and
P1 diode glowing continuously (in case
several PCs are connected, also P2, P3 and
P4 diodes). It is possible that also the LINK
diode will flash on your DSL router as well;
this confirms correct configuration of the
DSL line on the part of T-Com.
4. If the WLAN diode glows on your DSL router
Vigor 2600 VGST, wireless connection
(WiFi) to the DSL router is activated using
a wireless network card (max. 54 Mbps)
connected to your PC. The default setup of
WiFi connectivity enables you to immediately
connect to a router, which automatically
assigns an IP address to your PC. This
means that no WiFi protection is activated
on the router and for the sake of security
it is recommended to set up security
as soon as possible. More information
available in the DSL router manual.
> DSL router DrayTek Vigor 2600 VGST
