# Feature/Spec
USB 2.0 Type B
6
Interface
10/100Base-TX
7
Ethernet
Interface
8 80 GB Hard
Disk Drive
(Standard on
CLP42DN,
optional on
CLP37DN)
(Internal, not
shown)

Control Panel View

Once a printer is properly installed on the customer's network, daily job programming is done by the end-user
via printer drivers at a connected PC. The flexible Savin CLP37DN/CLP42DN offers a choice of programming
jobs using familiar PCL drivers or the genuine Adobe
available via download from the Savin web site is the XPS driver for Windows Vista.
Network settings and device monitoring tasks are usually managed using a remote software utility like Savin's
SmartDeviceMonitor or Web Image Monitor.
At the device, the Savin CLP37DN/CLP42DN features a large 4-line LCD operation panel that displays the
status of consumables at a glance. For easier operability, it also provides ample room to display job lists,
network settings, and error messages. One of the most noticeable areas of improvement to printer operability
is the addition of the 12-key alphanumeric keypad for the entry of User IDs and passwords in accounts with
security requirements. The following table outlines the functions of the Savin CLP37DN/CLP42DN control
panel:
40
Function
Provides for direct
connection to a single
computer.
Connects the printer to
a Local Area Network
via the RJ-45 port.
Attaches to the main
controller board to
enable advanced
printing, document
storage, and security
functions.
Customer Benefits
Allows for simple plug-and-play 1:1 connection to drive
all jobs from a single host PC.
Supports the faster 2.0 High Speed standard for faster
data transmission.
Standard NIC maximizes customer investment by
enabling shared use at no additional cost.
Supports fast data transfer speeds of 10Mbps or
100Mbps to speed printing in multi-user workgroups.
LEDs positioned on each side of the port illuminate to
confirm proper network connection and status.
Enables Hold Print/Stored Print and other security-
related features to maintain document confidentiality.
Provides memory space for job spooling, permanent
PostScript font storage, electronic collation, data
encryption, storing log data, and RIP Once/Print Many
functions.
Portion of disk space is reserved for document storage,
up to 9,000 pages or a total of 100
Locked/Stored/Hold Print jobs.
PostScript 3™ driver (see Core Technologies). Also
® ®
