SPECIFICATIONS

2 SPECIFICATIONS
2.1

PRODUCT IDENTIFICATION _________________________________________________

67042 .............................. Tri-King 1800G Tractor, 3-WD,
67043 .............................. Tri-King 1900D Tractor, 3-WD,
Serial Number ................ An identification plate, like the one
2.2

ENGINE__________________________________________________________________

1800G Gasoline Engine
Make ............................... Briggs &Stratton
Model .............................. Vanguard V-Twin OHV
Horsepower..................... 18 hp (13.5 kW) @3600 rpm
Displacement .................. 34.8 cu. in. (570 cc)
Torque ............................. 26 ft. lbs. (35 Nm) @ 2600 rpm
Fuel:
Type .......................... Unleaded Gasoline
Rating ....................... Min. 85 Octane
Capacity.................... 6.5 U.S. Gal. (24.6 liters)
Governor ......................... Flyweight Mechanical
Lubrication:
Capacity.................... 3.5 pints (1.6 liters)
Type .......................... SAE 30W
API Classification ..... SF, SG, SH
Air Filter .......................... Replacable Dual Element.
Alternator ........................ 16 amp
2.3

CUTTING UNITS: __________________________________________________________

Reel ................................ 3 Reels, 26 in. (660 mm) wide or,
Reel Diameter................. 7 in. (178 mm)
Bearings.......................... Self adjusting tapered roller
Blade Options ................. 5, 7 or 10 blades
Cutting Width:
26 in. Reels............... 72 in. (1828 mm)
30 in. Reels............... 84 in. (2134 mm)
GB-6
18 hp gasoline engine. Without
front lift arms, mowers or battery.
18.5 hp diesel engine. Without
front lift arms, mowers or battery.
shown, listing the serial number, is
attached to the frame of the
tractor and is located to the
operator's left just behind the front
wheel motor. Always provide the
serial number of the unit when
ordering replacement parts or
requesting service information.
3 Reels, 30 in. (762 mm) wide.
bearings
TEXTRON TURF CARE AND SPECIALTY PRODUCTS
RACINE, WI
67042
EEC Sound
Product
Power
67042 99.4 dba
67043 98 dba
1900D Diesel Engine
Make............................... Kubota
Model.............................. D662-E
Horsepower .................... 18.5 hp (13.9 kW) @3600 rpm
Displacement.................. 40.03 cu. in. (656 cc)
Torque............................. 26 ft. lbs. (35 Nm) @ 2600 rpm
Fuel:
Type .......................... No. 2 Diesel
Rating ....................... Min. Cetane rating 45
Capacity.................... 6.5 U.S. Gal. (24.6 liters)
Governor......................... Ball Type Governor
Low Idle ................... 1100 RPM
High Idle ................... 3400 RPM
Lubrication:
Capacity.................... 3.4 quarts (3.2 liter) with filter
Type .......................... SAE 20W, SAE 30W
API Classification ..... CD, CE
Air Filter .......................... Dry type with evacuator valve and
Alternator........................ 40 amp
Overall Width:
26 in. Reels............... 78.5 in. (1994 mm)
30 in. Reels............... 90.5 in. (2298 mm)
Cutting Frequency:
5 Blade ..................... 0.21 in./mph (5.3 mm/kph)
7 Blade ..................... 0.151 in./mph (3.8 mm/kph)
10 Blade ................... 0.106 in./mph (2.3 mm/kph)
MADE IN U.S.A.
1601
Sound Pressure
Vibration M/S
Level
Arms
Operator Ear
83.7 dba 1.4
84,7 dba 3,9
service indicator.
2
Body
1.61
<0.5
