SECTION 3
➀
Remove [DIAL] and unscrew the 2 allen-socket bolts from
the front panel using with an allen wrench (2.5 mm;
Allen-socket
bolts
➁
Detach the front panel from the main unit.
➂
Attach the insulation sheet (supplied as accessory) to IC
on the Front unit.
➃
Remove the protective paper attached to the bottom of
the optional unit to expose the adhesive strip.
OPTIONAL UNIT INSTALLATION
").
1 ⁄
10
➄
Intall the unit as illustrated below. Insert tightly to avoid
bad contact.
Flat cable
Insulation sheet
➅
Return the front panel and the allen-socket bolts to their
original position.
NOTE:
When attaching the front panel to the main unit,
make sure the flat cable are running in the groove to pre-
vent catching between front panel and main unit.
3 - 1
