Icom IC-2200H Service Manual page 64

Feb. 2010
[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R193 7030005521 S.RES ERA3YKD 334V (330K)
R194 7030003860 S.RES ERJ3GE JPW V
R195 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R201 7030003400 S.RES ERJ3GEYJ 471 V (470)
R202 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R203 7030003710 S.RES ERJ3GEYJ 184 V (180K)
R204 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R205 7030003740 S.RES ERJ3GEYJ 334 V (330K)
R207 7030003710 S.RES ERJ3GEYJ 184 V (180K)
R208 7030003780 S.RES ERJ3GEYJ 684 V (680K)
R209 7030003320 S.RES ERJ3GEYJ 101 V (100)
R212 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R213 7030003200 S.RES ERJ3GEYJ 100 V (10)
R214 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R220 7030003740 S.RES ERJ3GEYJ 334 V (330K)
R223 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R224 7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
R225 7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
R226 7030003860 S.RES ERJ3GE JPW V
R228 7520000120 POS PTFM04BC222Q2N34B0
R229 7030003860 S.RES ERJ3GE JPW V
R230 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R231 7030003860 S.RES ERJ3GE JPW V
R232 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R233 7030003860 S.RES ERJ3GE JPW V
R234 7030011140 S.RES ERJ8GEYJ 0R00V
R236 7030003860 S.RES ERJ3GE JPW V
R237 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R238 7030003640 S.RES ERJ3GEYJ 473 V (47K)
C1 4550007540 S.TAN F931C155MAABMA
C2 4030006860 S.CER C1608 JB 1H 102K-T
C4 4030011600 S.CER C1608 JB 1E 104K-T
C5 4030006900 S.CER C1608 JB 1H 103K-T
C7 4030006860 S.CER C1608 JB 1H 102K-T
C8 4030006860 S.CER C1608 JB 1H 102K-T
C9 4030007060 S.CER C1608 CH 1H 270J-T
C10 4510008520 S.ELE EEE1CA470SP
C11 4550006250 S.TAN TEESVA 1A 106M8R
C12 4550007280 S.TAN F931A336MBABMA
C13 4030007030 S.CER C1608 CH 1H 150J-T
C14 4030006860 S.CER C1608 JB 1H 102K-T
C15 4030006860 S.CER C1608 JB 1H 102K-T
C16 4030007020 S.CER C1608 CH 1H 120J-T
C17 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030007090 S.CER C1608 CH 1H 470J-T
C21 4030007050 S.CER C1608 CH 1H 220J-T
C22 4030007060 S.CER C1608 CH 1H 270J-T
C23 4030007070 S.CER C1608 CH 1H 330J-T
C24 4550006250 S.TAN TEESVA 1A 106M8R
C25 4030009920 S.CER C1608 CH 1H 050B-T
C26 4030007010 S.CER C1608 CH 1H 100D-T
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030006980 S.CER C1608 CH 1H 070D-T
C30 4030006950 S.CER C1608 CH 1H 040C-T
C31 4030006860 S.CER C1608 JB 1H 102K-T
C32 4030007020 S.CER C1608 CH 1H 120J-T
C34 4030009500 S.CER C1608 CH 1H 0R5B-T
C36 4030006860 S.CER C1608 JB 1H 102K-T
C37 4030009500 S.CER C1608 CH 1H 0R5B-T
C38 4030006860 S.CER C1608 JB 1H 102K-T
C39 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030006860 S.CER C1608 JB 1H 102K-T
C41 4030006860 S.CER C1608 JB 1H 102K-T
C42 4030006860 S.CER C1608 JB 1H 102K-T
C44 4030006860 S.CER C1608 JB 1H 102K-T
C45 4030006860 S.CER C1608 JB 1H 102K-T
C47 4030011600 S.CER C1608 JB 1E 104K-T
C48 4030006860 S.CER C1608 JB 1H 102K-T
C49 4030007010 S.CER C1608 CH 1H 100D-T
C50 4030006940 S.CER C1608 CH 1H 030C-T
C51 4030006860 S.CER C1608 JB 1H 102K-T
C52 4030006860 S.CER C1608 JB 1H 102K-T
C53 4030006860 S.CER C1608 JB 1H 102K-T
C54 4030007000 S.CER C1608 CH 1H 090D-T
C55 4030007050 S.CER C1608 CH 1H 220J-T
C56 4030006860 S.CER C1608 JB 1H 102K-T
C57 4030006860 S.CER C1608 JB 1H 102K-T
C58 4030006860 S.CER C1608 JB 1H 102K-T
C59 4030006860 S.CER C1608 JB 1H 102K-T
C60 4030006860 S.CER C1608 JB 1H 102K-T
C61 4030007050 S.CER C1608 CH 1H 220J-T
C62 4030007020 S.CER C1608 CH 1H 120J-T
C63 4030006860 S.CER C1608 JB 1H 102K-T
C64 4030011600 S.CER C1608 JB 1E 104K-T
C65 4030007050 S.CER C1608 CH 1H 220J-T
C66 4030007050 S.CER C1608 CH 1H 220J-T
C67 4030006860 S.CER C1608 JB 1H 102K-T
C68 4030007000 S.CER C1608 CH 1H 090D-T
C69 4510008540 S.ELE EEE1CA100SR
C70 4030006860 S.CER C1608 JB 1H 102K-T
C71 4030007090 S.CER C1608 CH 1H 470J-T
C72 4030006860 S.CER C1608 JB 1H 102K-T
C73 4030007050 S.CER C1608 CH 1H 220J-T
C74 4030006860 S.CER C1608 JB 1H 102K-T
C75 4030006860 S.CER C1608 JB 1H 102K-T
C76 4030006980 S.CER C1608 CH 1H 070D-T
C77 4030006900 S.CER C1608 JB 1H 103K-T
[MAIN UNIT]
H/V REF
M.
LOCATION NO.
T 86.6/54.9 C78
T 84.1/37.3 C79
B 111.1/40.7 C80
T 105.6/13.4 C81
T 107.5/10.1 C82
T 107.5/11.4 C83
T 108.4/8.8 C84
T 111.4/13.6 C85
T 110.5/4.9 C86
T 108.4/4.3 C87
T 104.7/10.1 C88
T 106.3/5.2 C89
T 105.6/7.3 C90
B 101.8/27.4 C91
T 83.7/51 C93
T 58.1/10 C94
[AUS] B 117.1/25.4 C95
[SEA-1] C97
[EXP-1] C98
[CHN-02] C100
[AUS] T 110.1/25.8 C101
[SEA-1] C105
[EXP-1] C108
[CHN-02] C111
B 100.7/22.8 C113
C117
B 51.9/22.8 C118
B 84.2/50.3 C120
T 44.3/53.7 C122
T 84.2/45.5 C123
B 80.8/44.4 C124
T 81/40.8 C125
B 56.8/17.5 C127
T 53.3/6.2 C128
T 53.5/8 C131
C133
C134
B 39.9/17.5 C136
B 36.1/40.2 C137
T 70.1/19.4 C138
T 38.9/14.9 C139
T 33.7/18.3 C140
T 89.5/20 C141
T 41.5/15.6 C145
T 37.6/37.5 C146
B 49.6/13.1 C148
B 43.3/12.9 C149
T 87.3/19.2 C152
B 31.2/38 C153
B 44.3/33.5 C154
T 86.5/21.3 C157
B 28.4/29.8 C158
T 37/21 C160
T 40.8/20.2 C161
B 76/19.1 C162
B 74.1/22.7 C163
B 53.2/18.2 C164
T 37/23.8 C166
T 42.7/25.9 C168
T 35/28.2 C169
T 35/26.9 C170
B 73.3/20.7 C172
T 40.4/21.5 C173
T 47.3/25.2 C174
T 41.6/29.3 C175
T 32.9/23 C176
T 41.6/28
T 40.4/22.8 C177
B 57.5/20.1 C178
T 72.9/12.8 C179
T 68.2/10.1 C180
T 66.6/11.4 C181
T 52.4/26.4 C182
B 56.2/20.1 C184
B 59.3/19.3 C185
T 48/27.3 C187
T 53.9/24 C188
T 52.4/19.1 C189
T 48.9/37.8 C190
T 48.9/39.1
B 59.7/22.5 C191
T 56.8/26.9 C192
T 57.6/18.4 C193
T 56/29.5 C194
T 52.4/20.4 C195
T 52.4/21.7 C196
T 41.7/46.5
B 67.9/16 C197
B 54.1/27.1 C198
T 54.2/15.1 C200
T 30/52 C201
T 41.3/51.5 C204
B 54.1/28.5 C205
B 63.1/24.5
B 55.6/30.6
T 54.2/16.6
T 36.5/46.9
B 68.3/29.9
B 67.3/24.5
B 50.7/33.8
B 71.5/24.5
B 45.1/37
B 109.8/21.2
B 43/37.4
B 103.3/21.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7
PARTS
DESCRIPTION
NO.
4030011600 S.CER C1608 JB 1E 104K-T
4030007080 S.CER C1608 CH 1H 390J-T
4030007050 S.CER C1608 CH 1H 220J-T
4030006900 S.CER C1608 JB 1H 103K-T
4510008540 S.ELE EEE1CA100SR
4030012600 S.CER C2012 JB 1A 105M-T
4030007170 S.CER C1608 CH 1H 221J-T
4030007170 S.CER C1608 CH 1H 221J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030007100 S.CER C1608 CH 1H 560J-T
4030007100 S.CER C1608 CH 1H 560J-T
4030006900 S.CER C1608 JB 1H 103K-T
4030007070 S.CER C1608 CH 1H 330J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006910 S.CER C1608 CH 1H 0R5C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006960 S.CER C1608 CH 1H 050C-T
4030008900 S.CER C1608 JB 1H 333K-T
4030007120 S.CER C1608 CH 1H 820J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030009990 S.CER C1608 CH 1H 200J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006900 S.CER C1608 JB 1H 103K-T
4510008520 S.ELE EEE1CA470SP
4030006900 S.CER C1608 JB 1H 103K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006960 S.CER C1608 CH 1H 050C-T
4510008540 S.ELE EEE1CA100SR
4030006920 S.CER C1608 CH 1H 010C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030007120 S.CER C1608 CH 1H 820J-T
4030006920 S.CER C1608 CH 1H 010C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030009560 S.CER C1608 CH 1H R75B-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030007120 S.CER C1608 CH 1H 820J-T
4030006900 S.CER C1608 JB 1H 103K-T
4030006930 S.CER C1608 CH 1H 020C-T
4030006920 S.CER C1608 CH 1H 010C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030007150 S.CER C1608 CH 1H 151J-T
4030011600 S.CER C1608 JB 1E 104K-T
4030009510 S.CER C1608 CH 1H 010B-T
4030011600 S.CER C1608 JB 1E 104K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008810 S.ELE EEE1CA331UP
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030009550 S.CER C1608 CH 1H 2R5B-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008500 S.ELE EEE1CA101WP
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008810 S.ELE EEE1CA331UP
4030011040 S.CER GRM31M4C2H2R0CY21L
(GRM42-6 CK)
4510008540 S.ELE EEE1CA100SR
4030006950 S.CER C1608 CH 1H 040C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008550 S.ELE EEE1HA010SR
4030007150 S.CER C1608 CH 1H 151J-T
4030006960 S.CER C1608 CH 1H 050C-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008550 S.ELE EEE1HA010SR
4030006860 S.CER C1608 JB 1H 102K-T
4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK)
4030007020 S.CER C1608 CH 1H 120J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4510008500 S.ELE EEE1CA101WP
4510008520 S.ELE EEE1CA470SP
4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK)
4030007020 S.CER C1608 CH 1H 120J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030007050 S.CER C1608 CH 1H 220J-T
4510008870 S.ELE EEE1AA471UP
4030006860 S.CER C1608 JB 1H 102K-T
H/V
M.
LOCATION
B 111.4/16.7
B 72.5/32
B 102/22.8
B 112/18.7
T 103.9/19.2
B 113.6/19.1
B 112.5/12.7
B 111.9/14.7
B 106.9/21.2
B 73.8/32
B 74.6/35.5
B 98.7/23.4
B 41.3/44.8
B 41.3/43.5
B 97.1/28.7
B 100.7/20
B 98.1/20
B 88.7/28.7
B 99.4/17.2
B 98.7/12.3
B 103.5/14.2
B 103.5/12.9
B 78.5/40.1
B 77.2/32.5
B 80/35.4
B 86.9/24.3
T 62.5/64.7
B 81.8/23.3
T 68.4/65.6
T 46.9/57
B 81.4/42.2
T 44.5/50.2
B 83.5/42
B 84.3/37.1
B 84.8/42
B 87.4/42
B 91.6/12.5
B 86.1/42
T 46.4/58.3
B 88.2/37.1
B 88.7/42
B 88.2/24.3
B 90.1/42
B 91.4/42
B 93.5/37.1
B 94/42
B 91.8/54.1
B 92.7/42
B 89.2/55.4
B 19.5/51.1
T 24.9/48
B 95.3/42
B 96.6/41
T 87.7/42.5
B 102/42.2
B 93.7/58
B 104.6/39.4
T 16.9/47.9
B 10.8/52.2
B 83.5/55.1
B 106.7/39.9
B 10.8/53.5
B 21.3/58.5
T 86.6/57.8
T 18.9/56.9
T 87.3/64.5
T 37/54.9
B 111.1/43.3
T 25.8/60.1
B 117.8/40.3
T 26.9/10.7
B 115.7/43.8
B 115.7/47.6
B 18.5/5
B 112.3/47.1
T 16.3/12.5
B 20.4/62.3
T 111.6/68.7
T 107.2/67.7
T 19.9/15
B 112.3/48.4
T 20/40
T 24.9/31.5
T 105.9/74.7
T 101.9/75.1
T 103.5/70.2
T 23.7/62.2
T 111.4/52.5
T 12.5/82.6
B 16.8/70.5
S.=Surface mount
