Icom IC-2200H Service Manual page 24

[LOGIC UNIT]
REF ORDER
NO. NO.
R104 7030005080 S.RESISTOR
7030008290 S.RESISTOR
R105 7030005090 S.RESISTOR
R106 7030005050 S.RESISTOR
R107 7030005090 S.RESISTOR
R108 7030005050 S.RESISTOR
R109 7030005600 S.RESISTOR
R112 7030008010 S.RESISTOR
R114 7030008010 S.RESISTOR
R128 7030005050 S.RESISTOR
R129 7030005090 S.RESISTOR
R133 7030005240 S.RESISTOR
R134 7030005050 S.RESISTOR
R135 7030005050 S.RESISTOR
R136 7030005090 S.RESISTOR
R137 7030005240 S.RESISTOR
R515 7030004980 S.RESISTOR
R516 7030010040 S.RESISTOR
R517 7030005160 S.RESISTOR
R519 7030005010 S.RESISTOR
R520 7030005240 S.RESISTOR
R521 7030005240 S.RESISTOR
R522 7030005100 S.RESISTOR
R523 7030005160 S.RESISTOR
R524 7030005050 S.RESISTOR
R525 7030004980 S.RESISTOR
R526 7030005120 S.RESISTOR
R527 7030005050 S.RESISTOR
R530 7030005240 S.RESISTOR
R531 7030005240 S.RESISTOR
R532 7030005240 S.RESISTOR
R533 7030005240 S.RESISTOR
R534 7030005240 S.RESISTOR
R536 7030005050 S.RESISTOR
R537 7030005010 S.RESISTOR
R538 7030005240 S.RESISTOR
R539 7030005240 S.RESISTOR
R541 7030005240 S.RESISTOR
R542 7030005240 S.RESISTOR
R543 7030005240 S.RESISTOR
R545 7410000770 S.ARRAY
R546 7030005090 S.RESISTOR
R548 7030000240 S.RESISTOR
R549 7030000240 S.RESISTOR
R550 7030010040 S.RESISTOR
R551 7030005050 S.RESISTOR
C1 4030017460 S.CERAMIC
C4 4030017460 S.CERAMIC
C5 4030017420 S.CERAMIC
C7 4030017460 S.CERAMIC
C8 4030016790 S.CERAMIC
C9 4030017460 S.CERAMIC
C10 4030017460 S.CERAMIC
C11 4030017460 S.CERAMIC
C13 4030017460 S.CERAMIC
C14 4030017460 S.CERAMIC
C15 4030017460 S.CERAMIC
C16 4030017460 S.CERAMIC
C19 4030016790 S.CERAMIC
C20 4030017460 S.CERAMIC
C23 4030017460 S.CERAMIC
C28 4030017460 S.CERAMIC
C30 4030017420 S.CERAMIC
C31 4030017420 S.CERAMIC
C32 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C33 4030013960 S.CERAMIC
C34 4030017790 S.CERAMIC
C35 4030017040 S.CERAMIC
C36 4030016930 S.CERAMIC
C37 4030016790 S.CERAMIC
C38 4030018080 S.CERAMIC
C39 4030017460 S.CERAMIC
C40 4030017460 S.CERAMIC
C41 4030016930 S.CERAMIC
C42 4030016950 S.CERAMIC
C43 4030016950 S.CERAMIC
C44 4030018240 S.CERAMIC
C45 4030016790 S.CERAMIC
C46 4030016970 S.CERAMIC
C47 4030016930 S.CERAMIC
C48 4030017760 S.CERAMIC
C49 4030016930 S.CERAMIC
C51 4030017030 S.CERAMIC
C52 4030017420 S.CERAMIC
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
ERJ2GEJ 823 X (82 kΩ)
[USA] only B
ERJ2GEJ 183 X (18 kΩ) [other] B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 273 X (27 kΩ)
[USA] only B
ERJ2GEJ 123 X (12 kΩ) B
ERJ2GEJ 123 X (12 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GE-JPW T
ERJ2GEJ 105 X (1 MΩ) B
ERJ2GEJ 681 X (680 Ω)
B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 154 X (150 kΩ) B
ERJ2GEJ 105 X (1 MΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GEJ 102 X (1 kΩ) B
ERJ2GEJ 103 X (10 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 103 X (10 kΩ) T
ERJ2GEJ 681 X (680 Ω)
T
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
EXB-V4V 102JV (1 kΩ) T
ERJ2GEJ 104 X (100 kΩ) T
MCR10EZHJ 68 Ω (680)
T
MCR10EZHJ 68 Ω (680)
B
ERJ2GE-JPW B
ERJ2GEJ 103 X (10 kΩ) B
ECJ0EB1E102K B
ECJ0EB1E102K T
ECJ0EC1H470J T
ECJ0EB1E102K B
ECJ0EB1C103K T
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1C103K B
ECJ0EB1E102K B
ECJ0EB1E102K T
ECJ0EB1E102K B
ECJ0EC1H470J B
ECJ0EC1H470J T
B
C1005 JB 1C 473K-T-N B
ECJ0EB1E682K B
ECJ0EB1A333K B
ECJ0EB1A104K B
ECJ0EB1C103K B
ECJ0EB1H182K B
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1A104K B
ECJ0EB1A473K B
ECJ0EB1A473K B
ECJ0EB1E562K B
ECJ0EB1C103K B
ECJ0EB1C223K B
ECJ0EB1A104K B
ECJ0EB1H222K B
ECJ0EB1A104K B
ECJ0EB1A273K B
ECJ0EC1H470J T
[LOGIC UNIT]
REF ORDER
NO. NO.
C53 4030017500 S.CERAMIC
C54 4030016790 S.CERAMIC
C55 4030017600 S.CERAMIC
C56 4030017760 S.CERAMIC
C57 4030018110 S.CERAMIC
C59 4030017640 S.CERAMIC
C62 4030017460 S.CERAMIC
C64 4030016790 S.CERAMIC
C65 4030016790 S.CERAMIC
C66 4030016790 S.CERAMIC
C67 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C68 4030016930 S.CERAMIC
C69 4030016930 S.CERAMIC
C70 4030016790 S.CERAMIC
C71 4030016790 S.CERAMIC
C72 4030017040 S.CERAMIC
C73 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C74 4030018240 S.CERAMIC
C75 4030017450 S.CERAMIC
C76 4030017040 S.CERAMIC
C77 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C78 4030016790 S.CERAMIC
C79 4030017440 S.CERAMIC
C80 4030016790 S.CERAMIC
C81 4030016790 S.CERAMIC
C82 4030017730 S.CERAMIC
C583 4030016930 S.CERAMIC
C584 4030016930 S.CERAMIC
C585 4030016930 S.CERAMIC
C586 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C587 4550006250 S.TANTALUM
C588 4030017490 S.CERAMIC
C591 4030017460 S.CERAMIC
C592 4030017460 S.CERAMIC
C593 4030016930 S.CERAMIC
C594 4030017460 S.CERAMIC
C595 4030017460 S.CERAMIC
C596 4030017460 S.CERAMIC
C597 4030017460 S.CERAMIC
C599 4030016930 S.CERAMIC
C600 4030017460 S.CERAMIC
C601 4550006210 S.TANTALUM
C602 4550006250 S.TANTALUM
J1 6450002210 CONNECTOR
J3 6510024230 S.CONNECTOR
J4 6510021970 S.CONNECTOR
DS1 5030002660 LCD
DS2 5040001760 S.LED
DS3 5040001760 S.LED
DS4 5040001760 S.LED
DS5 5040001760 S.LED
DS6 5040001760 S.LED
DS7 5040001760 S.LED
DS8 5040001760 S.LED
DS9 5040001760 S.LED
DS10 5040001760 S.LED
DS11 5040001760 S.LED
DS12 5040001760 S.LED
DS13 5040001760 S.LED
S1 2260001890 S.SWITCH
S2 2260001890 S.SWITCH
S3 2260001890 S.SWITCH
S4 2260001890 S.SWITCH
S5 2260001890 S.SWITCH
S6 2260001890 S.SWITCH
S7 2260001890 S.SWITCH
S8 2260001890 S.SWITCH
S9 2250000460 ENCODER
S10 2260001890 S.SWITCH
EP1 6910012350 S.BEAD
EP2 6910012350 S.BEAD
EP3 6910012350 S.BEAD
EP4 6910012350 S.BEAD
EP5 6910012350 S.BEAD
EP6 6910012350 S.BEAD
EP7 6910012350 S.BEAD
EP8 6910012350 S.BEAD
EP9 6910012350 S.BEAD
EP10 6910012350 S.BEAD
EP11 8930062251 LCD CONTACT
6 - 2
DESCRIPTION M.
ECJ0EC1H560J B
ECJ0EB1C103K B
ECJ0EC1H080C B
ECJ0EB1H222K B
ECJ0EB1H272K B
ECJ0EC1H150J B
ECJ0EB1E102K B
ECJ0EB1C103K B
ECJ0EB1C103K B
ECJ0EB1C103K T
B
ECJ0EB1A104K B
ECJ0EB1A104K B
ECJ0EB1C103K T
ECJ0EB1C103K B
ECJ0EB1A333K B
B
ECJ0EB1E562K B
ECJ0EB1E271K B
ECJ0EB1A333K B
B
ECJ0EB1C103K B
ECJ0EC1H221J B
ECJ0EB1C103K B
ECJ0EB1C103K B
ECJ0EB1E471K B
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K B
B
TEESVA 1A 106M8L B
C1608 JB 1A 105K-T B
ECJ0EB1E102K T
ECJ0EB1E102K B
ECJ0EB1A104K B
ECJ0EB1E102K B
ECJ0EB1E102K T
ECJ0EB1E102K B
ECJ0EB1E102K B
ECJ0EB1A104K B
ECJ0EB1E102K T
ECST1CX106R T
TEESVA 1A 106M8L B
3017-8821 <KIN> T
08-6210-0363-40-800 B
AXN330C130P B
IS08264E00V2 T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SEC 2422C T
SKQDPA T
SKQDPA T
SKQDPA T
SKQDPA T
SKQDPA T
SKQDPA T
SKQDPA T
SKQDPA T
EVQ-VENF0224B T
SKQDPA T
MMZ1608Y 102BT T
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT T
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT B
SRCN-2698-SP-N-W-1 T
S.=Surface mount
