6-4 UT-115 (OPTIONAL UNIT)
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1180002390 S.REG
IC2 1180002370 S.REG
IC50 1130011630 S.IC
IC101 1130008360 S.IC
IC103 1130006890 S.IC
IC151 1130010920 S.IC
IC202 1130010460 S.IC
IC203 1110005730 S.IC
IC204 1140010770 S.IC
IC251 1110005290 S.IC
IC252 1110005430 S.IC
IC253 1110006200 S.IC
IC254 1130004200 S.IC
IC351 1120002980 S.IC
Q50 1510000770 S.TRANSISTOR
Q51 1590000430 S.TRANSISTOR
Q201 1590000430 S.TRANSISTOR
Q202 1590000430 S.TRANSISTOR
Q251 1590000430 S.TRANSISTOR
Q252 1590000430 S.TRANSISTOR
Q301 1590000430 S.TRANSISTOR
Q302 1590000430 S.TRANSISTOR
Q303 1590000430 S.TRANSISTOR
Q305 1590001660 S.TRANSISTOR
Q306 1590001660 S.TRANSISTOR
Q400 1510000770 S.TRANSISTOR
Q401 1590000430 S.TRANSISTOR
D151 1790001240 S.DIODE
D152 1790001250 S.DIODE
X101 6050011240 S.XTAL
X201 6050011700 S.XTAL
L50 6200003960 S.COIL
L151 6200003960 S.COIL
L201 6200003960 S.COIL
L351 6200003960 S.COIL
R1 7030005240 S.RESISTOR
R2 7030000180 S.RESISTOR
R50 7030005010 S.RESISTOR
R51 7030005120 S.RESISTOR
R52 7030004980 S.RESISTOR
R53 7030005240 S.RESISTOR
R54 7030005240 S.RESISTOR
R55 7030005090 S.RESISTOR
R56 7030004980 S.RESISTOR
R57 7030005240 S.RESISTOR
R58 7030010040 S.RESISTOR
R59 7030005090 S.RESISTOR
R60 7030005050 S.RESISTOR
R100 7030010040 S.RESISTOR
R101 7030005160 S.RESISTOR
R102 7030004980 S.RESISTOR
R103 7030005120 S.RESISTOR
R151 7030005120 S.RESISTOR
R152 7030005240 S.RESISTOR
R201 7030005120 S.RESISTOR
R202 7030005120 S.RESISTOR
R203 7030005040 S.RESISTOR
R204 7030005040 S.RESISTOR
R205 7030005040 S.RESISTOR
R206 7030005120 S.RESISTOR
R209 7030005120 S.RESISTOR
R211 7030005240 S.RESISTOR
R212 7030005240 S.RESISTOR
R216 7030005240 S.RESISTOR
R217 7030005240 S.RESISTOR
R218 7030005240 S.RESISTOR
R219 7030005240 S.RESISTOR
R221 7030010040 S.RESISTOR
R251 7030005240 S.RESISTOR
R252 7030005090 S.RESISTOR
R253 7030005240 S.RESISTOR
R254 7030005240 S.RESISTOR
R255 7030005240 S.RESISTOR
R256 7030005090 S.RESISTOR
R257 7030005240 S.RESISTOR
R258 7030005090 S.RESISTOR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
S-812C33AMC-C2N-T2 T
R1111N321B-TR T
AD73311ARS T
TC7SHU04FU (TE85L) B
TC7S04FU (TE85R) T
AMBE-2020 T
TC7SH08FU (TE85L) B
S-80928CNMC-G8Y-T2 B
HD64F3687FP B
NJM2115V-TE1 B
CMX589AD5 B
NJM13404V-TE1 B
TC4S66F (TE85R) B
MAX3226EAE-T T
2SA1586-GR (TE85R) T
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
DTC144EUA T106 B
XP4312 (TX) B
XP4312 (TX) B
2SA1586-GR (TE85R) B
DTC144EUA T106 B
MA2S728-(TX) T
MA2S111-(TX) B
CR-708 (16.384 MHz) T
CR-760 (9.8304 MHz) T
MLF1608A 1R0K-T T
MLF1608A 1R0K-T B
MLF1608A 1R0K-T B
MLF1608A 1R0K-T T
ERJ2GEJ 473 X (47 kΩ) T
MCR10EZHJ 22 Ω (220)
T
ERJ2GEJ 681 X (680 Ω)
T
ERJ2GEJ 102 X (1 kΩ) T
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GE-JPW B
ERJ2GEJ 104 X (100 kΩ) T
ERJ2GEJ 103 X (10 kΩ) T
ERJ2GE-JPW T
ERJ2GEJ 105 X (1 MΩ) B
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GEJ 102 X (1 kΩ) T
ERJ2GEJ 102 X (1 kΩ) T
ERJ2GEJ 473 X (47 kΩ) T
ERJ2GEJ 102 X (1 kΩ) B
ERJ2GEJ 102 X (1 kΩ) B
ERJ2GEJ 472 X (4.7 kΩ) B
ERJ2GEJ 472 X (4.7 kΩ) B
ERJ2GEJ 472 X (4.7 kΩ) B
ERJ2GEJ 102 X (1 kΩ) B
ERJ2GEJ 102 X (1 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GE-JPW B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 104 X (100 kΩ) B
[MAIN UNIT]
REF ORDER
NO. NO.
R260 7030005090 S.RESISTOR
R261 7030005240 S.RESISTOR
R262 7030005220 S.RESISTOR
R264 7310004610 S.TRIMMER
R267 7030005090 S.RESISTOR
R268 7030006610 S.RESISTOR
R269 7030005060 S.RESISTOR
R270 7030005240 S.RESISTOR
R308 7030004980 S.RESISTOR
R309 7030004980 S.RESISTOR
R315 7030004980 S.RESISTOR
R316 7030004980 S.RESISTOR
R317 7030004980 S.RESISTOR
R318 7030004980 S.RESISTOR
R400 7030005090 S.RESISTOR
R401 7030009290 S.RESISTOR
C1 4550006250 S.TANTALUM
C2 4550006250 S.TANTALUM
C5 4030017460 S.CERAMIC
C7 4550005980 S.TANTALUM
C8 4030016930 S.CERAMIC
C9 4550006250 S.TANTALUM
C10 4030016930 S.CERAMIC
C11 4550006480 S.TANTALUM
C50 4030016930 S.CERAMIC
C51 4030016970 S.CERAMIC
C53 4030016930 S.CERAMIC
C54 4550006250 S.TANTALUM
C55 4030016930 S.CERAMIC
C56 4030016950 S.CERAMIC
C57 4030016930 S.CERAMIC
C58 4030016930 S.CERAMIC
C102 4540000070 S.TRIMMER
C103 4030017590 S.CERAMIC
C104 4030016930 S.CERAMIC
C106 4030016930 S.CERAMIC
C150 4550000460 S.TANTALUM
C151 4030016930 S.CERAMIC
C152 4030016930 S.CERAMIC
C153 4030016930 S.CERAMIC
C154 4030016930 S.CERAMIC
C155 4030016930 S.CERAMIC
C156 4030016930 S.CERAMIC
C157 4030016930 S.CERAMIC
C159 4030016930 S.CERAMIC
C201 4030016930 S.CERAMIC
C202 4030017590 S.CERAMIC
C203 4030016930 S.CERAMIC
C204 4030017390 S.CERAMIC
C205 4030016930 S.CERAMIC
C206 4030016790 S.CERAMIC
C207 4540000080 S.TRIMMER
C250 4030016930 S.CERAMIC
C252 4030017490 S.CERAMIC
C253 4030017400 S.CERAMIC
C255 4030017490 S.CERAMIC
C256 4030016930 S.CERAMIC
C257 4030017030 S.CERAMIC
C258 4030017030 S.CERAMIC
C259 4030017760 S.CERAMIC
C260 4030017490 S.CERAMIC
C261 4030016930 S.CERAMIC
C262 4030017490 S.CERAMIC
C263 4030016930 S.CERAMIC
C333 4030017460 S.CERAMIC
C351 4030011810 S.CERAMIC
C352 4030011810 S.CERAMIC
C353 4030011810 S.CERAMIC
C354 4030011810 S.CERAMIC
C355 4030011600 S.CERAMIC
C401 4550006250 S.TANTALUM
J301 6510018440 S.CONNECTOR
EP1 0910057812 PCB
6 - 9
DESCRIPTION M.
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 223 X (22 kΩ) T
EVM-2WSX80 B15 (104) T
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 394 X (390 kΩ) B
ERJ2GEJ 333 X (33 kΩ) B
ERJ2GEJ 473 X (47 kΩ) B
ERJ2GEJ 101 X (100 Ω)
T
ERJ2GEJ 101 X (100 Ω)
T
ERJ2GEJ 101 X (100 Ω)
T
ERJ2GEJ 101 X (100 Ω)
T
ERJ2GEJ 101 X (100 Ω)
B
ERJ2GEJ 101 X (100 Ω)
T
ERJ2GEJ 104 X (100 kΩ) B
ERJ2GEJ 562 X (5.6 kΩ) B
TEESVA 1A 106M8L T
TEESVA 1A 106M8L T
ECJ0EB1E102K B
TEESVA 1A 475M8L T
ECJ0EB1A104K T
TEESVA 1A 106M8L T
ECJ0EB1A104K T
TEESVA 1C 475M8L T
ECJ0EB1A104K T
ECJ0EB1C223K T
ECJ0EB1A104K T
TEESVA 1A 106M8L T
ECJ0EB1A104K T
ECJ0EB1A473K B
ECJ0EB1A104K T
ECJ0EB1A104K T
TZY2Z100A001 T
ECJ0EC1H070C T
ECJ0EB1A104K B
ECJ0EB1A104K T
TEESVA 1C 105M8L T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K T
ECJ0EB1A104K B
ECJ0EC1H070C B
ECJ0EB1A104K B
ECJ0EC1H180J T
ECJ0EB1A104K B
ECJ0EB1C103K B
TZY2R200A001 T
ECJ0EB1A104K B
C1608 JB 1A 105K-T B
ECJ0EC1H220J B
C1608 JB 1A 105K-T B
ECJ0EB1A104K B
ECJ0EB1A273K B
ECJ0EB1A273K B
ECJ0EB1H222K T
C1608 JB 1A 105K-T B
ECJ0EB1A104K B
C1608 JB 1A 105K-T B
ECJ0EB1A104K B
ECJ0EB1E102K T
C1608 JB 1A 224K-T T
C1608 JB 1A 224K-T T
C1608 JB 1A 224K-T T
C1608 JB 1A 224K-T T
C1608 JB 1E 104K-T T
TEESVA 1A 106M8L B
AXN430C330P B
B 6071B
