Icom IC-2200H Service Manual page 28

[MAIN UNIT]
REF ORDER
NO. NO.
C271 4550006140 S.TANTALUM
C272 4030011600 S.CERAMIC
C273 4550006480 S.TANTALUM
C278 4510004540 S.ELECTROLYTIC ECEV0JA470SR
C279 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C280 4550006130 S.TANTALUM
C281 4510005830 S.ELECTROLYTIC ECEV1HAN010R
C282 4030006860 S.CERAMIC
C283 4030006860 S.CERAMIC
C284 4030008880 S.CERAMIC
C285 4030008920 S.CERAMIC
C286 4030006860 S.CERAMIC
C287 4030017810 S.CERAMIC
C288 4030011810 S.CERAMIC
C289 4030006860 S.CERAMIC
C290 4030006860 S.CERAMIC
C291 4030006860 S.CERAMIC
C292 4030006860 S.CERAMIC
C293 4030006860 S.CERAMIC
C294 4030006860 S.CERAMIC
C295 4030006850 S.CERAMIC
C296 4030006860 S.CERAMIC
C297 4030006860 S.CERAMIC
C299 4030012600 S.CERAMIC
C300 4030006860 S.CERAMIC
C301 4030006860 S.CERAMIC
C302 4030006860 S.CERAMIC
J4 6450002220 CONNECTOR
J6 6510014960 S.CONNECTOR
J7 6450001430 CONNECTOR
J11 6510024240 S.CONNECTOR
W1 8900011880 CABLE
W5 7120000470 JUMPER
W6 8900010980 CABLE
EP1 6910012350 S.BEAD
EP2 6910012350 S.BEAD
EP3 6910012350 S.BEAD
EP4 6910012350 S.BEAD
EP5 6910012350 S.BEAD
EP6 6910012350 S.BEAD
EP7 6910012350 S.BEAD
EP8 6910012350 S.BEAD
EP9 9040901901 TUBE
EP10 0910057743 PCB
EP11 6910000640 BEAD
EP12 6910000640 BEAD
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
ECST1EY474R T
C1608 JB 1E 104K-T T
TEESVA 1C 475M8L T
T
T
ECST1VY224R B
T
C1608 JB 1H 102K-T B
C1608 JB 1H 102K-T B
C1608 JB 1H 223K-T B
C1608 JB 1H 473K-T
except [EXP-1] T
C1608 JB 1H 102K-T B
C1608 CH 1H 102J-T B
C1608 JB 1A 224K-T B
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T B
C1608 JB 1H 102K-T B
C1608 JB 1H 471K-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T B
C2012 JB 1A 105M-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T T
C1608 JB 1H 102K-T T
PJ-0008P-5 <KUO> B
B2B-ZR-SM3-TF T
HSJ1462-01-010 B
04-6274-036-000-800 T
OPC-1210 (P=0.5 N=36 L=70)
ERDS2T0
OPC-1131 <CMI>
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT T
MMZ1608Y 102BT T
MMZ1608Y 102BT B
MMZ1608Y 102BT B
MMZ1608Y 102BT T
MMZ1608Y 102BT B
IRRAX 0.7 (d) L=12 mm
B 6076C
FSRH090160RN000B
[USA], [EUR], [EUR-1] only
FSRH090160RN000B
[USA], [EUR], [EUR-1] only
6-2 HM-133V
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1140005870 S.IC
IC2 1130008630 S.IC
IC3 1110006010 S.IC
Q1 1530001940 S.TRANSISTOR
Q2 1590000680 S.TRANSISTOR
Q3 1590001330 S.TRANSISTOR
Q4 1510000770 S.TRANSISTOR
Q5 1510000770 S.TRANSISTOR
Q6 1510000770 S.TRANSISTOR
Q7 1510000770 S.TRANSISTOR
Q8 1530001940 S.TRANSISTOR
Q9 1590001010 S.TRANSISTOR
D1 1790000950 S.ZENER
D3 1750000550 S.DIODE
D4 1750000550 S.DIODE
D5 1750000550 S.DIODE
D6 1750000550 S.DIODE
D7 1750000550 S.DIODE
D8 1750000550 S.DIODE
D9 1750000550 S.DIODE
D10 1750000550 S.DIODE
D11 1750000550 S.DIODE
D12 1750000550 S.DIODE
D13 1750000550 S.DIODE
D14 1750000550 S.DIODE
D15 1750000550 S.DIODE
D16 1730002280 S.ZENER
D17 1730002280 S.ZENER
D18 1730002280 S.ZENER
D19 1750000550 S.DIODE
X1 6060000530 CERAMIC
L1 6200001520 S.COIL
L2 6200001520 S.COIL
R2 7030000400 S.RESISTOR
R3 7030000400 S.RESISTOR
R4 7030000400 S.RESISTOR
R5 7030003400 S.RESISTOR
R6 7030003620 S.RESISTOR
R7 7030003620 S.RESISTOR
R8 7030003570 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003420 S.RESISTOR
R11 7030003420 S.RESISTOR
R12 7030003560 S.RESISTOR
R13 7030003560 S.RESISTOR
R14 7030003420 S.RESISTOR
R15 7030003400 S.RESISTOR
R16 7030003560 S.RESISTOR
R18 7030003760 S.RESISTOR
R19 7030003760 S.RESISTOR
R20 7030003760 S.RESISTOR
R21 7030003760 S.RESISTOR
R22 7030003680 S.RESISTOR
R23 7030003680 S.RESISTOR
R24 7030003680 S.RESISTOR
R25 7030003680 S.RESISTOR
R26 7030003640 S.RESISTOR
R27 7030003800 S.RESISTOR
R29 7030003320 S.RESISTOR
R30 7030003530 S.RESISTOR
R31 7030003640 S.RESISTOR
R32 7030003640 S.RESISTOR
R33 7030003640 S.RESISTOR
R34 7030003640 S.RESISTOR
R35 7030000400 S.RESISTOR
R36 7030003560 S.RESISTOR
R37 7030003460 S.RESISTOR
R38 7030003720 S.RESISTOR
R39 7030003480 S.RESISTOR
R40 7030003480 S.RESISTOR
R41 7030003560 S.RESISTOR
C1 4030006850 S.CERAMIC
C2 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C3 4030007130 S.CERAMIC
6 - 6
DESCRIPTION M.
µPD7564AG-555-E1 B
MC14028BF-EL B
S-80845CLUA-B66-T2 B
2SC2712-BL (TE85R) B
DTC114EUA T106 B
DTA114EUA T106 B
2SA1586-GR (TE85R) B
2SA1586-GR (TE85R) B
2SA1586-GR (TE85R) B
2SA1586-GR (TE85R) B
2SC2712-BL (TE85R) B
DTB113ZK T146 B
MA8056-M (TX) B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
1SS355 TE-17 B
MA8091-M (TX) B
MA8091-M (TX) B
MA8091-M (TX) B
1SS355 TE-17 B
CSBLB600KJ28T-B0 (CSB600J200T) B
MLF2012D R82K-T B
MLF2012D R82K-T B
MCR10EZHJ 1.5 kΩ B
MCR10EZHJ 1.5 kΩ B
MCR10EZHJ 1.5 kΩ B
ERJ3GEYJ 471 V (470 Ω)
B
ERJ3GEYJ 333 V (33 kΩ) B
ERJ3GEYJ 333 V (33 kΩ) B
ERJ3GEYJ 123 V (12 kΩ) B
ERJ3GEYJ 103 V (10 kΩ) B
ERJ3GEYJ 681 V (680 Ω)
B
ERJ3GEYJ 681 V (680 Ω)
B
ERJ3GEYJ 103 V (10 kΩ) B
ERJ3GEYJ 103 V (10 kΩ) B
ERJ3GEYJ 681 V (680 Ω)
B
ERJ3GEYJ 471 V (470 Ω)
B
ERJ3GEYJ 103 V (10 kΩ) B
ERJ3GEYJ 474 V (470 kΩ) B
ERJ3GEYJ 474 V (470 kΩ) B
ERJ3GEYJ 474 V (470 kΩ) B
ERJ3GEYJ 474 V (470 kΩ) B
ERJ3GEYJ 104 V (100 kΩ) B
ERJ3GEYJ 104 V (100 kΩ) B
ERJ3GEYJ 104 V (100 kΩ) B
ERJ3GEYJ 104 V (100 kΩ) B
ERJ3GEYJ 473 V (47 kΩ) B
ERJ3GEYJ 105 V (1 MΩ) B
ERJ3GEYJ 101 V (100 Ω)
B
ERJ3GEYJ 562 V (5.6 kΩ) B
ERJ3GEYJ 473 V (47 kΩ) B
ERJ3GEYJ 473 V (47 kΩ) B
ERJ3GEYJ 473 V (47 kΩ) B
ERJ3GEYJ 473 V (47 kΩ) B
MCR10EZHJ 1.5 kΩ B
ERJ3GEYJ 103 V (10 kΩ) B
ERJ3GEYJ 152 V (1.5 kΩ) B
ERJ3GEYJ 224 V (220 kΩ) B
ERJ3GEYJ 222 V (2.2 kΩ) B
ERJ3GEYJ 222 V (2.2 kΩ) B
ERJ3GEYJ 103 V (10 kΩ) B
C1608 JB 1H 471K-T B
B
C1608 CH 1H 101J-T B
S.=Surface mount
