Icom IC-2200H Service Manual page 67

Feb. 2010
[MAIN-A UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R40 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R41 7030003400 S.RES ERJ3GEYJ 471 V (470)
R42 7030003400 S.RES ERJ3GEYJ 471 V (470)
R43 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R44 7030003320 S.RES ERJ3GEYJ 101 V (100)
R45 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R46 7030003420 S.RES ERJ3GEYJ 681 V (680)
R47 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R48 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R49 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R50 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R51 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R52 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
R54 7030003240 S.RES ERJ3GEYJ 220 V (22)
R55 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R56 7030003400 S.RES ERJ3GEYJ 471 V (470)
R57 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R58 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R59 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R60 7030003260 S.RES ERJ3GEYJ 330 V (33)
R62 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R63 7030003360 S.RES ERJ3GEYJ 221 V (220)
R64 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R66 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R71 7030003400 S.RES ERJ3GEYJ 471 V (470)
R72 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
R73 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
R74 7030003860 S.RES ERJ3GE JPW V
R76 7030003320 S.RES ERJ3GEYJ 101 V (100)
R78 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
R79 7030003360 S.RES ERJ3GEYJ 221 V (220)
R80 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R81 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R82 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R86 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R88 7030003400 S.RES ERJ3GEYJ 471 V (470)
R90 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R92 7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003420 S.RES ERJ3GEYJ 681 V (680)
7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003370 S.RES ERJ3GEYJ 271 V (270)
7030003370 S.RES ERJ3GEYJ 271 V (270)
R93 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R95 7030000230 S.RES MCR10EZHJ 56 (560)
R96 7030000410 S.RES MCR10EZHJ 1.8K (182)
R101 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R103 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R104 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R106 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R107 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R108 7030003570 S.RES ERJ3GEYJ 123 V (12K)
R109 7030003510 S.RES ERJ3GEYJ 392 V (3.9K)
R110 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R111 7030003320 S.RES ERJ3GEYJ 101 V (100)
R112 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R113 7030003590 S.RES ERJ3GEYJ 183 V (18K)
R114 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R116 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R117 7030003690 S.RES ERJ3GEYJ 124 V (120K)
R118 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R119 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R120 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R121 7030000260 S.RES MCR10EZHJ 100 (101)
R122 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R123 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R124 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R125 7030003240 S.RES ERJ3GEYJ 220 V (22)
R126 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R127 7030003690 S.RES ERJ3GEYJ 124 V (120K)
R128 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R129 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R130 7030003610 S.RES ERJ3GEYJ 273 V (27K)
R131 7030003670 S.RES ERJ3GEYJ 823 V (82K)
R135 7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K) [KOR-1]
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
R136 7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K) [KOR-1]
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
R137 7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K) [KOR-1]
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
R138 7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K) [KOR-1]
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
7030003570 S.RES ERJ3GEYJ 123 V (12K)
R139 7030003580 S.RES ERJ3GEYJ 153 V (15K)
7030003580 S.RES ERJ3GEYJ 153 V (15K) [KOR-1]
7030003580 S.RES ERJ3GEYJ 153 V (15K)
7030003580 S.RES ERJ3GEYJ 153 V (15K)
7030003580 S.RES ERJ3GEYJ 153 V (15K)
[MAIN-A UNIT]
H/V REF
M.
LOCATION NO.
T 56.2/21.2 R140
T 53.1/29.5
T 54.9/21.2
B 60.6/25.8
B 69.6/18.1
T 40.7/48.7 R150
B 61.8/24.5 R152
T 32.4/51.2 R153
T 35.4/50.5 R154
B 54.3/30.6 R155
B 48.7/36.8 R156
B 67.6/32 R157
B 110.6/18.7 R168
B 44.3/39.1 R169
B 110.6/14.7 R170
B 98.7/22.1 R171
B 43.5/41.2
B 100.5/28.7
B 113.2/14.7
B 44.1/43.5
B 96.9/26.6 R172
B 96.8/20
B 113.3/10.7
B 98.1/17.2
B 101.4/13
B 78/28.7 R173
B 97.4/13.3 R174
B 100/13 R175
B 78.6/42.2 R176
B 77.2/33.8 R177
B 80/36.7 R178
B 75.9/38.8 R179
B 77.9/38 R180
B 80.7/40.5 R181
B 77.2/40.1 R182
B 90.2/23.5 R183
B 83.5/39.2 R184
[TPE-1] T 43.8/57.7 R185
[KOR-1] R186
[SEA-2] R187
[THA-1] R189
[EXP-2] R190
[AUS-1] R191
[SEA-3] R193
[EXP-3] R194
B 87.4/39.2 R195
T 44.7/62.3 R201
T 45.6/59.9 R202
B 92.7/39.2 R203
B 89.2/54.1 R204
B 95.9/65.5 R205
B 91.8/55.4 R207
B 87.3/59.4 R208
B 93.7/56.7 R209
B 87.4/56.8 R212
B 103.3/42.2 R213
B 103.3/39.4 R214
T 28.2/7.1 R220
B 111.1/42 R223
B 106.7/38.6 R224
B 109/42
B 107.7/42
B 18.4/7.9 R225
B 115.7/41
T 27.1/60.1
T 24.2/59.8 R226
B 16.6/5.8 R228
B 114.4/48.7 R229
T 106.4/72.1 R230
T 22.4/20.4 R231
T 104.3/72.2 R232
B 92.6/45.2 R233
B 87.7/44.8 R234
B 86.4/46.3 R236
B 113.1/50.5 R237
B 107.9/90.9 R238
[TPE-1] T 114/20.1
[SEA-2] C1
[THA-1] C2
[EXP-2] C4
[TPE-1] T 114/17.3 C5
C7
[SEA-2] C8
[THA-1] C9
[EXP-2] C10
[TPE-1] B 114.3/25.4 C11
C12
[SEA-2] C13
[THA-1] C14
[EXP-2] C15
[TPE-1] B 113/26.7 C16
C17
[SEA-2] C20
[THA-1] C21
[EXP-2] C22
[TPE-1] B 113.5/22.8 C23
C24
[SEA-2] C25
[THA-1] C26
[EXP-2] C28
C29
C30
C31
C32
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
