5. Apply a generous amount of the included grease
to the Upright Axle (48) and to two Small Wave
Washers (118).
Insert the Upright Axle (48) into the Upright (5)
and center it. Slide a Small Wave Washer (118)
onto each end of the Upright Axle.
6. Identify the Right and Left Upper Body Legs (6,
7), which are marked with "Right" and "Left" stick-
ers, and orient them as shown.
Slide the Right and Left Upper Body Legs (6, 7)
onto the Upright Axle (48).
Tighten two M8 x 16mm Patch Screws (102) with
M8 x 23mm x 2mm Washers (126) into the
Upright Axle (48) at the same time. Firmly
tighten the Patch Screws.
5
118
Grease
5
6
102
126
7
8
48
118
Grease
Avoid pinching
the Wire
Harness (60)
48
126
102
6
