InFocus Projector Setup Manual page 5

Connect a Nintendo GameCube to a projector (w/o component) using component video
Setup Requirements
Nintendo GameCube game console
Projector without component video ports
GameCube Component Video cable
1
Power
Digital AV Out Analog AV Out
Plug the GameCube
Component video cable to the
Digital AV Out port on the
GameCube.
2
VGA RS-232
M1-DA S-video
Connect the other end of
the cable to the M1 to
component adapter. Connect
the M1 adapter to the M1
connector on your projector.
3
Nintendo
N I N T E N D O power
GAMECUBE
Power on the projector, then the
GameCube. Insert your game disc.
You are ready to play your game!
GameCube Rear Connector Panel
GameCube Component Video Cable
(GameCube optional accessory)
Composite
Video
L
Projector Connector Panel
R
VGA
M1-DA
connector panel may vary from actual product
M1 to Component adapter
(InFocus optional accessory)
GameCube Stereo AV cable (GameCube AV connector to composite AV connectors)
M1 to component adapter (InFocus part #SP-M1-ADPT)
Power
Analog AV Out
Digital AV Out
Composite
Video
RS-232
L
S-video R
5
Connect the GameCube Stereo AV Cable
to get audio with your game (standard accessory)
Do not
connect
*
We recommend connecting your GameCube to an
external sound system to provide the best audio
experience.
Best
*
Optional audio connections
