InFocus Projector Setup Guide for a Mac Desktop Computer
Table of Contents
- If you have an Apple eMac, see
- If you have an Apple iMac G3, see
- If you have an Apple iMac G4, see
- If you have an Apple iMac G5, see
iMac
- If you have an Apple Mac mini, see
- If you have an Apple Power Mac, see
audio
optical
out
in
For more information and troubleshooting...
Read the common issues on
Copyright © 1999-2005 InFocus Corporation. All Rights Reserved.
How to connect a desktop computer to an InFocus projector
page
2.
page
3.
pages
4-5.
page
6.
pages
7-8.
pages
9-10.
pages
11-16.
Component Composite
Y
VGA
RS-232
Pb
L
Pr
M1-DA
S-video
R

Advertisement

loading
Need help?

Need help?

Do you have a question about the Projector and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InFocus Projector

Summary of Contents for InFocus Projector

  • Page 1 InFocus Projector Setup Guide for a Mac Desktop Computer How to connect a desktop computer to an InFocus projector Component Composite RS-232 M1-DA S-video Table of Contents - If you have an Apple eMac, see page - If you have an Apple iMac G3, see...
  • Page 2 Connecting an Apple eMac to an InFocus projector Setup Requirements Apple eMac with monitor/video out port Projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A) USB ports Monitor/video out Apple VGA adapter (Apple part# M8639G/A) port...
  • Page 3 Connecting an Apple iMac G3 to an InFocus projector Setup Requirements Apple iMac G3 (2002) with VGA port USB connector for Microsoft PowerPoint InFocus projector with M1 port or mouse control with InFocus remote. M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A)
  • Page 4 Connecting an Apple iMac G4 Flat Panel (under 1Ghz) to an InFocus projector Setup Requirements Apple iMac G4 Flat Panel (under 1Ghz) with monitor/video out port InFocus projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A)
  • Page 5 Connecting an Apple iMac G4 Flat Panel (over 1Ghz) to an InFocus projector Setup Requirements Apple iMac G4 Flat Panel (over 1Ghz) with monitor/video out port InFocus projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A)
  • Page 6 Connecting an Apple iMac G5 to an InFocus projector Setup Requirements NOTE: We recommend connecting the computer audio to external speakers to provide the best audio experience. Apple iMac G5 with Monitor/Video Out Port Projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A)
  • Page 7 Connecting an Apple Mac mini computer to an InFocus projector with a VGA connector Setup Requirements Apple Mac mini with DVI-I out port Good Projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A) Apple DVI to VGA adapter (Apple part #M8754G/A)
  • Page 8 Connecting an Apple Mac mini computer to an InFocus projector with a DVI connector Setup Requirements Apple Mac mini with DVI-I out port Better Projector with M1 port M1 to DVD/USB cable (6 ft, InFocus part #SP-DVI-D) Apple Mac mini Connector Panel...
  • Page 9 Connecting an Apple Power Mac computer to an InFocus projector with a VGA connector Setup Requirements Good Apple Power Mac computer with DVI (digital video interface) monitor port Projector with M1 port M1 to VGA/USB cable (6 ft, InFocus part #SP-DVI-A)
  • Page 10 Connecting an Apple Power Mac computer to an InFocus projector with a DVI connector Setup Requirements Better Apple Power Mac computer with DVI (digital video interface) monitor port Projector with M1 port M1 to DVI/USB cable (6 ft, InFocus part #SP-DVI-D)

  • Page 11: Common Issues

    2. Turn on the projector first, then the computer. 3. If no image appears, make sure the resolution and refresh rate are configured to match the native resolution of the projector. Most InFocus projectors are either 800 x 600 (SVGA) or 1024 x 768 (XGA) 4.
  • Page 12 5. On some Mac models, you may see an Arrange tab that will allow you to activate the external monitor port by clicking on Mirror Displays or dragging the monitors over each other. Typically, your computer image will appear on the projector upon turning on your computer.
  • Page 13 If you only see a background without any icons, you have Extended Desktop enabled. This means that half of your desktop will be on your laptop and the other half will be on the projector. Typically, the computer defaults to Video Mirroring each time you turn it on.
  • Page 14 (The actual screen may vary, depending on which operating system and computer model you have.) Note: We recommend that you keep the resolution set at the native resolution of the projector. and the refresh rate set between 60-85Hz. Most computers will default to the native resolution of the projector.
  • Page 15 1. If you are using a laptop, always use AC power instead of the battery. 2. Make sure the resolution is configured according to the native resolution of the projector. Refresh rate should be set between 60 Hz to 85 Hz.
  • Page 16 1024 x 768 75 Hz eMac Resolution Refresh Rate 640 x 480 138 Hz 800 x 600 112 Hz 1024 x 768 89 Hz 1152 x 864 80 Hz 1280 x 960 72 Hz Copyright © 1999-2005 InFocus Corporation. All Rights Reserved.
