IN3144_IN3146_IN3148HD User’s Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
Page 4
Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees. In addition, the projector should not be installed in any other way except desktop and ceiling mount positions. Otherwise lamp life could decrease dramatically, and may lead to other unpredictable damage.
Page 5
IN3144_IN3146_IN3148HD User’s Manual Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
IN3144_IN3146_IN3148HD User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR EMOTE CONTROL CABLE OWER CORD ATTERIES NOT INCLUDED CD-ROM & UICK TART UIDE AFETY WARRANTY BOOKLET ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work.
IN3144_IN3146_IN3148HD User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE IR receiver Receive IR signal from remote control. Lens Projection Lens. Keypad See Top view—Keypad and LEDs. Focus ring Focuses the projected image. Zoom ring Enlarges the projected image. Important: Do not block ventilation openings.
IN3144_IN3146_IN3148HD User’s Manual Top view—Keypad and LEDs ABEL ESCRIPTION EE PAGE LAMP LED Blinking Red Error code TEMP LED Over Temperature T1 Green Lamp Ready POWER LED Blinking Start, Cooling or error code. Green Navigates the OSD. Quick Menu – For Keystone Menu Open and exit OSD menus.
IN3144_IN3146_IN3148HD User’s Manual Rear view 2 3 4 5 6 7 ABEL ESCRIPTION EE PAGE AC IN Connect a POWER cable. RJ45 Connect a LAN cable from Ethernet. When connected to the screen through a commercially available cable, 12V TRIGGER the screen deploys automatically on start up of the projector.
Page 12
IN3144_IN3146_IN3148HD User’s Manual S-VIDEO Connect an S-VIDEO cable from a video device. USB POWER Connect an USB cable for power supply. (5V/1.5A) DC12V Trigger Note: To use this feature, you must plug in the connector before turning on/off the projector. ...
Rotate adjuster lever to adjust angle position. Note: It is recommended to use InFocus ceiling mount p/n PRJ-MNT-UNIV. Refer to the installation guide that comes with the mount for more information. The warranty does not cover any damage caused by use of non-approved ceiling mount kits or by installing in an improper location.
IN3144_IN3146_IN3148HD User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
Page 15
IN3144_IN3146_IN3148HD User’s Manual ABEL ESCRIPTION EE PAGE Power ON Turn the projector on. LED indicator Only lights when the remote keys are pressed. Display Mode Choose a suitable preset mode for usage environment. Contrast Display the Contrast setting bar and use the right and left keys to adjust. Display the Brightness setting bar and use the right and left keys to Brightness adjust.
IN3144_IN3146_IN3148HD User’s Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level.
2. Dispose of used batteries according to local ordinance regulations. 3. Remove the batteries when not using the projector for prolonged periods. 4. Do not mix old and new batteries, or mix battery types. Note: Batteries are not normally included with InFocus projectors. — 10 —...
IN3144_IN3146_IN3148HD User’s Manual Turning the projector on and off Connect the power cord to the projector. Connect the other end to a wall outlet. POWER LED on the projector light. Turn on the connected devices. Ensure the POWER LED is not flashing.
Page 19
IN3144_IN3146_IN3148HD User’s Manual To turn the projector off, press the POWER OFF button. When the “Power Off? Press Power again” message appears, press the POWER OFF button. The projector turns off. Caution: Do not unplug the power cord until the POWER LED stops flashing–indicating the projector has cooled down.
Keep the password in a safe place. Without the password, you will not be able to use the projector. If you lose the password, contact InFocus Support for information on clearing the password. Press the MENU button to open the OSD menu.
Page 21
Enter the password in the order you set it on step 5. If you forget the password, please contact InFocus. Visit our website at www.infocus.com/support or call us. — 14 —...
IN3144_IN3146_IN3148HD User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector: The projector table or stand should be level and sturdy. Position the projector so that it is perpendicular to the screen. ...
IN3144_IN3146_IN3148HD User’s Manual Adjusting the Zoom, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the projected image and screen size Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons on the remote control to correct trapezoid image issues...
IN3144_IN3146_IN3148HD User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control arrow buttons to navigate and make changes to the OSD. 1.
IN3144_IN3146_IN3148HD User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the ◄► buttons to navigate to Settings 1. Press the ▲▼ buttons to move to the Advanced 1 menu. (Enter) or ►...
IN3144_IN3146_IN3148HD User’s Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. ETTINGS Image Display Mode Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User Brightness 0~100 Contrast 0~100 Computer Horizontal Position -5~5 (depend on Autolock) Vertical Position -5~5 (depend on Autolock)
Page 27
IN3144_IN3146_IN3148HD User’s Manual ETTINGS Settings 1 Source Source reference Input Source Select (IR/Keypad) Projection Normal, Rear, Ceiling, Rear+Ceiling Aspect Ratio Fill, 4:3, 16:9, Letter Box, Native, 2.35:1 Keystone -40~40 Digital Zoom -10~10 Audio Volume 0~10 Mute Off, On Off, On English, Français, Deutsch, Español, Advanced 1 Language...
Page 28
IN3144_IN3146_IN3148HD User’s Manual ETTINGS Settings 2 Auto Source Off, On No Signal 0~180 Power Off Auto Power Off, On Lamp Mode ECO , Normal, Smart ECO Reset All Status Active Source Video Information Lamp Hours(ECO, Normal, Smart ECO) Software Version Advanced 1 Menu Position Center, Down, Up, Left, Right...
IN3144_IN3146_IN3148HD User’s Manual Image Menu Attention ! When image options are changed, the Display Mode changes to User. Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Image Menu. Press the ▲▼ buttons to move up and down in the Image menu. Press the ◄► buttons to enter and change setting values.
IN3144_IN3146_IN3148HD User’s Manual Computer Menu Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Image menu. Press the ▲▼ buttons to move to the Computer menu and then press (Enter) or ►. Press the ▲▼...
IN3144_IN3146_IN3148HD User’s Manual Advanced Features Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Image menu. Press the ▼▲ buttons to move to the Advanced menu and then press (Enter) or ►. Press the ▼▲...
IN3144_IN3146_IN3148HD User’s Manual White Balance Press the ENTER button to enter the White Balance sub menu. ESCRIPTION Press the ◄► buttons to adjust the Red Gain. R Gain Press the ◄► buttons to adjust the Green Gain. G Gain Press the ◄► buttons to adjust the Blue Gain. B Gain Press the ◄►...
IN3144_IN3146_IN3148HD User’s Manual Color Manager Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Image menu. Press the ▼▲ buttons to move to the Color Manager menu and then press (Enter) or ►. Press the ▼▲...
IN3144_IN3146_IN3148HD User’s Manual Settings 1 Menu Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Settings 1 menu. Press the ▲▼ buttons to move up and down in the Settings 1 menu. Press the ◄► buttons to enter and change setting values.
IN3144_IN3146_IN3148HD User’s Manual Audio Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Settings 1 menu. Press the ▼▲ buttons to move to the Audio menu and then press (Enter) or ►. Press the ▼▲...
IN3144_IN3146_IN3148HD User’s Manual Advanced 1 Features Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Settings 1 menu. Press the ▲▼ buttons to move to the Advanced 1 menu and then press (Enter) or ►.
Page 37
IN3144_IN3146_IN3148HD User’s Manual 3D Setting ESCRIPTION Press the ◄► buttons to enter and select different 3D modes. Press the ◄► buttons to enter and enable or disable 3D Sync Invert. 3D Sync Invert Press the ◄► buttons to enter and enable or disable different 3D formats. 3D Format Note: 1.
IN3144_IN3146_IN3148HD User’s Manual Advanced 2 Features Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Settings 1 menu. Press the ▲▼ buttons to move to the Advanced 2 menu and then press (Enter) or ►.
IN3144_IN3146_IN3148HD User’s Manual Settings 2 Menu Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Settings 2 menu. Press the ▲▼ buttons to move up and down in the Settings 2 menu. ESCRIPTION Press the ◄►...
IN3144_IN3146_IN3148HD User’s Manual Status Press the ▲▼ buttons to move up and down in the Settings 2 menu. Select the Status menu and (Enter) or ► to enter. press ESCRIPTION Active Source Displays the current active source type. Displays resolution/video information for RGB sources and color standard for Video Video Information sources.
IN3144_IN3146_IN3148HD User’s Manual Advanced 1 Features Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Settings 2 menu. Press the ▲▼ buttons to move to the Advanced 1 menu and then press (Enter) or ►.
Page 42
IN3144_IN3146_IN3148HD User’s Manual Lamp Hour Reset Please refer to Resetting the Lamp Timer on page to reset the lamp hour counter. Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If DHCP is turned Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields.
Page 43
This projector supports all commands of PJLink Class1 (Version 1.00). http://pjlink.jbmia.or.jp/english/ For detailed information about the diverse types of external devices which can be connected to the LAN/RJ45 port to control the projector, as well as related control commands, go to www.infocus.com/support — 36 —...
Page 44
IN3144_IN3146_IN3148HD User’s Manual LAN_RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (laptop). 2. On the PC (laptop), select Start → Control Panel →Network and Internet. — 37 —...
Page 45
IN3144_IN3146_IN3148HD User’s Manual 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the Networking tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. —...
Page 46
IN3144_IN3146_IN3148HD User’s Manual 7. Press the Menu button on the projector. 8. Select Settings2→ Advanced1 → Network 9. After getting into Network, input the following: DHCP: Off IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS Server: 0.0.0.0 (Enter) / ►...
Page 47
IN3144_IN3146_IN3148HD User’s Manual RS232 by Telnet Function Besides using Hyper-Terminal for projector control, you can also use RS232 by Telnet with the LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” 1. Locate the IP address from the projector's OSD. 2. Make sure that the laptop/PC can access the projector's web page. 3.
Page 48
IN3144_IN3146_IN3148HD User’s Manual 5. Type the Telnet command in the following format: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) 6. When the Telnet connection is ready and you have input an RS232 command, press Enter. Enabling Telnet in Windows 7/8/10 1.
Page 49
IN3144_IN3146_IN3148HD User’s Manual 4. Select Turn Windows features on or off. 5. Select Telnet Client, and click OK. Telnet specifications Telnet: TCP Telnet port: 23 Telnet utility: Windows Telnet.exe (console mode) Disconnecting Telnet when Telnet is active: Close Windows Telnet utility. Telnet Limitations: 1.
IN3144_IN3146_IN3148HD User’s Manual Advanced 2 Features Press the Menu button to open the OSD menu. Press the ◄► buttons to move to the Settings 2 menu. Press the ▲▼ buttons to move to the Advanced 2 menu and then press (Enter) or ►.
Page 51
IN3144_IN3146_IN3148HD User’s Manual Source Filter Press the ENTER button to enter the Source Filter sub menu. This sub menu allows you to enable and disable source inputs. ESCRIPTION Press the ◄► buttons to enter and enable or disable the VGA1 source. VGA 1 Press the ◄►...
IN3144_IN3146_IN3148HD User’s Manual AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when the lamp fails or reaches recommended lamp life hours. It should only be replaced with a certified replacement part, which you can order from your local dealer.
Page 53
IN3144_IN3146_IN3148HD User’s Manual Remove the lamp compartment cover. Disconnect the lamp connector Remove the two screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. — 46 —...
Page 54
IN3144_IN3146_IN3148HD User’s Manual Reverse steps 1 to 6 to install the new lamp module. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the screws. ! Warning: Lamp Connector must be installed flush with the connector base as shown in the image below. A gap between the Lamp Connector and the connector base will cause damage to the projector.
IN3144_IN3146_IN3148HD User’s Manual Resetting the Lamp Timer After replacing the lamp, you should reset the lamp hour timer to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Settings 2 menu.
IN3144_IN3146_IN3148HD User’s Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn.
Note: A Cable Lock System can be purchased from InFocus or your dealer. Refer to the information that comes with the lock for instructions on how to use it. The security lock slot corresponds to Kensington’s MicroSaver Security System. If you have any questions or concerns, contact: Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A.
IN3144_IN3146_IN3148HD User’s Manual ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. After spending time troubleshooting, the problem can often be traced to something as simple as a loose connection.
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before restarting the projector. If the Power or Lamp LEDs are still blinking or any other situation that isn't listed in the chart above , please contact InFocus Support. — 52 —...
IN3144_IN3146_IN3148HD User’s Manual Image Problems Problem: No image appears on the screen 1. Verify the settings on your notebook or desktop PC. 2. Turn off all the equipment and power everything up again. The projector should be turned on last. Problem: The image is blurred 1.
3. Have the projector serviced. Having the Projector Serviced If you are unable to solve the problem, you should have the projector serviced. Pack the projector in the original carton and contact InFocus Support at www.infocus.com/support or call us. — 54 —...
IN3144_IN3146_IN3148HD User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.
Screen trigger: DC Jack x 1 (DC12V 200mA output function) USB (Type mini B) - service only Security Kensington lock / Security Bar Note: InFocus reserves the right to alter product offerings and specifications at any time without notice. — 56 —...
IN3144_IN3146_IN3148HD User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
IN3144_IN3146_IN3148HD User’s Manual PPENDIX Serial Communication The following table describes the serial communication configuration that should be used when interfacing to CLI via the serial port. Windows HyperTerminal or ProComm are two tools that can be used to send CLI commands across the serial port.
Page 72
IN3144_IN3146_IN3148HD User’s Manual Item Function Command Min Max Return Note Do auto image (AIM1) 10 Get no signal power off timer (AOT?) (0-36,1) 11 Set no signal power off timer (AOTn) Timer = n x 5 minutes 12 Get Auto source value (ASC?) (0-1,1) 0: Off...
Page 73
IN3144_IN3146_IN3148HD User’s Manual Item Function Command Min Max Return Note 45 Get lamp total hours (LMT?) (0-9999,0) 46 Get lamp life (LIF?) (0-2500,0) 0: Eco 47 Get lamp mode (IPM?) (0-2,1) 1: Normal 2: Smart Eco 0: Eco 48 Set lamp mode (IPMn) 1: Normal 2: Smart Eco...
Page 74
IN3144_IN3146_IN3148HD User’s Manual Item Function Command Min Max Return Note 0: Presentaion 1: Bright 2: Game 3: Movie 66 Get display mode (PST?) (0-7,0) 4: TV 5: sRGB 6: BlackBoard 7: User 67 Set next display mode (PST+) 68 Set upper display mode (PST-) 0: Presentaion 1: Bright...
