USERS GUIDE
INFOCUS QUANTUM LASER AUTHENTIC I
REGULATORY
SERIES
MODEL
P135
INFOCUS QUANTUM LASER AUTHENTIC I
V2.0 02/2025
LENS TYPE/
WXGA
RESOLUTION
STANDARD THROW
—
1080P
WUXGA
4K
IN1048SL
IN10489L
—

Advertisement

loading
Need help?

Need help?

Do you have a question about the QUANTUM LASER AUTHENTIC I and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus QUANTUM LASER AUTHENTIC I

Summary of Contents for InFocus QUANTUM LASER AUTHENTIC I

  • Page 1 USERS GUIDE INFOCUS QUANTUM LASER AUTHENTIC I REGULATORY LENS TYPE/ SERIES WXGA 1080P WUXGA MODEL RESOLUTION P135 INFOCUS QUANTUM LASER AUTHENTIC I STANDARD THROW — IN1048SL IN10489L — V2.0 02/2025...
  • Page 2 Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call InFocus before you send the unit for repair. 7. Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short out parts that could result in fire or electric shock.
  • Page 3 Do not modify this product in any way. y Do not attempt to service this projector. y There are no user-serviceable parts. Service to be performed only by a InFocus authorized service provider using InFocus approved system components. To reduce the risk associated with fire and explosion: y Do not immerse the projector in any liquid or allow to get wet.
  • Page 4 Safety Labels Trademarks InFocus and the InFocus logo are trademarks of InFocus Corporation. Adobe and the Adobe logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Microsoft, PowerPoint, and Excel are registered trademarks of Microsoft Corporation.
  • Page 5 CE Statement Electromagnetic Compatibility Statement: Meets 2014/30/EU Directive Low Voltage Directive: Meets 2014/35/EU Directive WEEE Statement The following information is only for EU-member States: The mark shown below is in compliance with Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
  • Page 6 TABLE PF CPNTENTS INTRPDUCTIPN ................7 Package Overview........................7 Standard accessories ........................ 7 Product Overview ........................8 Connections..........................9 Keypad ............................. 10 Remote control ......................... 11 SETUM AND INSTALLATIPN ............12 Installing the projector ......................12 Connecting to a computer ......................14 Connecting to a DVD player .....................
  • Page 7 ADDITIPNAL INFPRIATIPN ............48 Compatible resolutions ......................48 Image size and projection distance ..................51 Projector dimensions and ceiling mount installation ..............53 RS232 Commands and Protocol Function List................. 54 Troubleshooting ........................58 Warning indicators ........................60 Specifications ........................... 61 English...
  • Page 8 INTRPDUCTIPN Mackage Pverview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase. Please check with your place of purchase. Some accessories may vary from region to region. The warranty card is only supplied in some specific regions.
  • Page 9 INTRPDUCTIPN Mroduct Pverview Note: ‡ Do not block projector intake and exhaust vents. ‡ When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake and exhaust vents. Item Item IR Receivers Kensington™ Lock Port Keypad Input / Output Lens Shift Dial...
  • Page 10 INTRPDUCTIPN Connections Item Item HDMI 2 (v1.4) Connector Audio In 2 Connector HDMI 1 (v2.0)(4K) Connector VGA Out Connector USB Power Out (5V 1.5A) RS232 Connector Connector VGA In 1 Connector RJ-45 Connector Composite Connector Power Socket Audio In 1 / Microphone Connector VGA In 2 Connector Kensington Lock Port...
  • Page 11 INTRPDUCTIPN Keypad Item Item Power LED Menu Lamp LED Keystone Correction Temp LED Information Power 10. Enter Source 11. Re-Sync Four directional select keys English...
  • Page 12 INTRPDUCTIPN Remote control AV Mute Re-Sync Source Enter Menu Keystone Volume Video HDMI Aspect Page Freeze Zoom Mouse Picture Mute Item Item AV Mute 12. Power Re-Sync 13. Source Four Directional Select Keys 14. Enter Menu 15. ECO Keystone +/- 16.
  • Page 13 Do not operate the projector in any orientation other than table top or ceiling mount. The projector should be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime of the projector light source or the projector itself. For non-standard installation advice please contact InFocus. English...
  • Page 14 SETUM AND INSTALLATIPN Mrojector installation notice ‡ Place the projector in a horizontal position. The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise laser life could decrease dramatically, and may lead to other unpredictable damage.
  • Page 15 SETUM AND INSTALLATIPN Connecting to a computer Item Item HDMI Cable Audio Out Cable VGA In Cable VGA Out Cable Audio In Cable RS232 Cable Microphone Cable Power Cord English...
  • Page 16 SETUM AND INSTALLATIPN Connecting to a DVD player Item Item HDMI Cable Video Cable HDMI Dongle Audio In Cable USB Power Cable Audio Out Cable RCA Component Cable Power Cord S-Video Cable English...
  • Page 17 SETUM AND INSTALLATIPN Connecting to HDBaseT and Network Item Item RJ-45 Cable (Cat5 Cable) RJ-45 Cable Audio Out Cable Power Cord English...
  • Page 18 SETUM AND INSTALLATIPN Adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom, lens shift, and focus...
  • Page 19 SETUM AND INSTALLATIPN Remote setup Installing / replacing the batteries Two AAA size batteries are required. (Not included) Push the clip to release the battery cover. Install new batteries (AAA/R03). Ensure that you have the batteries’ polarity (+/–) aligned correctly. Close the battery cover and press it down until it clicks into place.
  • Page 20 SETUM AND INSTALLATIPN Effective range Infra-Red (IR) remote control sensor is located on the top and front of the projector. Ensure to hold the remote control at an angle within 40 degrees perpendicular to the projector’s IR remote control sensor to function correctly. The distance between the remote control and the sensor should not be longer than 5 meters (16.4 feet).
  • Page 21 USING THE MRPJECTPR Powering on / off the projector AV Mute Re-Sync Source Enter Menu Keystone Volume Video HDMI Lens cap Aspect Page Freeze Zoom Mowering on Mouse Picture Mute Remove the lens cap. Securely connect the power lead and signal/source cable. When connected, the Power LED will turn red.
  • Page 22 USING THE MRPJECTPR AV Mute Re-Sync Source Selecting an input source Turn on the connected source such as a computer, Blu-Ray player, HDBaseT etc. Press the button on the Enter keypad, the Source button on the remote control, or the green source buttons on the remote to select an input. AV Mute Menu Re-Sync...
  • Page 23 USING THE MRPJECTPR Ienu navigation and features The projector has multilingual on screen display menus that allow you to make image adjustments and change a variety of settings. button on the projector keypad or the Ienu button on the remote To open the OSD menu, press the control.
  • Page 24 USING THE MRPJECTPR PSD Ienu tree Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu Presentation Bright HDR SIM. Cinema Display Mode Game sRGB DICOM SIM. User Off [Default] Blackboard Light Yellow Wall Color Light Green Light Blue Pink Gray...
  • Page 25 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu Red [Default] Green Blue Color Cyan Yellow Magenta Color Matching White(*) Hue / R(*) -50 ~ 50 Saturation / G(*) -50 ~ 50 Gain / B(*) -50 ~ 50 Reset...
  • Page 26 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu Off [Default] 3D Mode DLP-Link 3D [Default]  Auto [Default] 3D Format Top and Bottom Frame Sequential 3D Sync Invert Off [Default] 16:9 (1080p model) Display 16:10 (WUXGA model) Aspect Ratio...
  • Page 27 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu Audio 1 [Default] VIDEO Audio 2 Audio Input Audio 1 Audio HDBaseT Audio 2 Default [Default] Audio Input [Default] Audio/Mic Input Function Front [Default] Rear Projection...
  • Page 28 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu English [Default] Deutsch Français Italiano Español Português Polski Nederlands Svenska Norsk Suomi ελληνικά 繁體中文 Language 简体中文 日本語 한국어 Русский Magyar Čeština Setup Options ไทย...
  • Page 29 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu HDMI 1 HDMI 2 VGA IN 1 [Default] Input Source VGA IN 2 Video S-Video HDBaseT Off [Default] High Altitude Options Setup Default [Default] Logo Neutral Black [Default]...
  • Page 30 USING THE MRPJECTPR Iain Sub Ienu Sub Ienu 2 Sub Ienu 3 Sub Ienu 4 Values Ienu Serial Number Source Resolution Refresh Rate Display Mode Power Mode (Standby) Light Source Info Hours Network Status IP Address Brightness Mode System FW Version Note: Functions vary depending on model definition.
  • Page 31 USING THE MRPJECTPR Display menu Display image settings menu Display Iode There are many factory presets optimized for various types of images. ‡ Mresentation: This mode is suitable for showing in front of public in connection to the PC. Bright: Maximum brightness from any source. ‡...
  • Page 32 USING THE MRPJECTPR Note: ‡ These options are only available if the 3D mode function is disabled, the Wall Color setting is not set to Blackboard, and the Display Mode setting is not set to DICOM SIM. or HDR SIM.. ‡...
  • Page 33 USING THE MRPJECTPR Brightness Iode Adjust the brightness mode settings. ‡ DynamicBlack: Automatically adjusts the brightness based on the source signal for optimum contrast performance. ‡ Mower: Select the power percentage to adjust the overall brightness. Reset Return the factory default settings for color settings. Display 3D menu Note: ‡...
  • Page 34 USING THE MRPJECTPR Display aspect ratio menu Aspect Ratio Select the aspect ratio of the displayed image between the following options: ‡ 4:3: This format is for 4:3 input sources. ‡ 16:9: This format is for 16:9 input sources, like HDTV and DVD enhanced for Wide screen TV. ‡...
  • Page 35 USING THE MRPJECTPR 1080p auto mapping rule: Input resolution Auto/Scale Auto H-resolution V-resolution 1920 1080 1440 1080 1440 1080 1024 1440 1080 1280 1024 1440 1080 1400 1050 1440 1080 1600 1200 1440 1080 1280 1920 1080 Wide Laptop 1280 1800 1080 1280...
  • Page 36 USING THE MRPJECTPR WUXGA auto mapping rule (screen type 16:10): Input resolution Auto/Scale Auto H-resolution V-resolution 1920 1200 1600 1200 1600 1200 1024 1600 1200 1280 1024 1600 1200 1400 1050 1600 1200 1600 1200 1600 1200 1280 1920 1080 Wide Laptop 1280 1920...
  • Page 37 USING THE MRPJECTPR Input resolution Auto/Scale Auto H-resolution V-resolution 1920 1080 1280 1920 1080 HDTV 1920 1080 1920 1080 Display edge mask menu Edge Iask Use this function to remove the video encoding noise on the edge of video source. Note: This function is grayed out if the input source is VIDEO or S-VIDEO and the resolution is 1080P or WUXGA.
  • Page 38 USING THE MRPJECTPR Audio menu Audio mute menu Iute Use this option to temporarily turn off the sound. ‡ Pn: Choose “On” to turn mute on. ‡ Off: Choose “Off” to turn mute off. Note: ‡ “Mute” function affects both internal and external speaker volume. ‡...
  • Page 39 USING THE MRPJECTPR Setup menu Setup projection menu Mrojection Select the preferred projection orientation: Front, Rear, Ceiling-front, Ceiling-rear. Setup screen type menu Screen Type (for WUXGA model only) Choose the screen type from 16:9 and 16:10. Setup power settings menu Direct Mower Pn Choose “On”...
  • Page 40 USING THE MRPJECTPR Change Massword Sets or modifies the security password. Note: Password default value is “1234” (first time). Setup HDII CEC menu Note: ‡ When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them on the same power on or power off status using the HDMI Link control feature in the projector’s OSD.
  • Page 41 USING THE MRPJECTPR Setup options menu Language Select the multilingual OSD menu between English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Swedish, Norwegian, Finnish, Greek, traditional Chinese, simplified Chinese, Japanese, Korean, Russian, Hungarian, Czechoslovak, Arabic, Thai, Turkish, Farsi, Vietnamese, Indonesian, Romanian, and Slovakian. Closed Caption Closed Caption is a text version of the program sound or other information displayed on the screen.
  • Page 42 USING THE MRPJECTPR Network menu Network LAN menu Network Status Display the network connection status (read-only). IAC Address Display the MAC address (read-only). DHCM Use this option to enable or disable the DHCP function. ‡ Off: To assign IP, subnet mask, gateway, and DNS configuration manually. ‡...
  • Page 43 USING THE MRPJECTPR Iaking a direct connection from your computer to the projector* Turn “Off” the DHCP option on the projector. Configure the IP address, Subnet Mask, Gateway, and DNS on projector (“Network > LAN”). Open Network and Sharing Center page on your PC, and assign the identical network parameters to your PC as set on projector.
  • Page 44 USING THE MRPJECTPR Setup network control settings menu LAN_RJ45 function For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN / RJ45 function of the projector through a network, such as remotely manage: Power On / Off, brightness, and contrast settings.
  • Page 45 USING THE MRPJECTPR Right-click on the Local Area Connection, and select Mroperty. In the Mroperties window, select the General tab, and select Internet Mrotocol (TCM / IM). Click “Properties”. Type in the IP address and Subnet mask, then press “OK”. Press the “Menu”...
  • Page 46 USING THE MRPJECTPR – Gateway: 192.168.0.254 – DNS: 192.168.0.51 Press “Enter” to confirm settings. Open a web browser, for example Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher installed. In the Address bar, input the projector’s IP address: 192.168.0.100. Press “Enter”.
  • Page 47 USING THE MRPJECTPR The General Setup page allows changing the Projector Name and the admin password. On the Projector Control page, you can perform many common network control functions such as changing the source and adjusting volume. Network settings can be configured on the Network Setup page. If the IP address is changed the new IP address will have to be put in the url window of the browser to access Projector Control.
  • Page 48 USING THE MRPJECTPR Alert setup will send an email if there is a fault with the projector. Click the check boxes to enable notification and select which faults you want to have reported. Info menu Info menu View the projector information as listed below: ‡...
  • Page 49 ADDITIONAL INFORMATION Compatible resolutions Digital compatibility Digital (HDMI 1.4) Digital native resolution: 1920 x 1080 @ 60Hz (IN1048SL) and 1920 x 1200 @ 60Hz (IN1049SL) Descriptor timing Descriptor timing Established Timing Standard Timing Supported Video Mode (Detail timing) (Detail timing) 720 x 400 @ 70Hz 1280 x 720 @ 60Hz 1080p:...
  • Page 50 ADDITIONAL INFORMATION Digital (HDMI 2.0) Digital native resolution: 1920 x 1080 @ 60Hz (IN1048SL) and 1920 x 1200 @ 60Hz (IN1049SL) Descriptor timing Descriptor timing Established Timing Standard Timing Supported Video Mode (Detail timing) (Detail timing) 1152 x 870 @ 75Hz 3840 x 2160 @ 24Hz 3840 x 2160 @ 25Hz 3840 x 2160 @ 30Hz...
  • Page 51 ADDITIPNAL INFPRIATIPN True 3D video compatibility Input timing 1280 x 720P @ 50Hz Top-and-Bottom 1280 x 720P @ 60Hz Top-and-Bottom 1280 x 720P @ 50Hz Frame packing HDMI 1.4a 1280 x 720P @ 60Hz Frame packing 3D Input 1920 x 1080i @ 50Hz Side-by-Side(Half) 1920 x 1080i @ 60Hz Side-by-Side(Half)
  • Page 52 ADDITIPNAL INFPRIATIPN Image size and projection distance 1080p series Projection image size is from 20” to 300” (0.5m to 7.6m). Top View Screen Screen (Width) Projection Distance Width Screen (Height) Screen Side View Offset Projection Distance 16:9 Screen size Mrojection distance Offset diagonal (inches)
  • Page 53 ADDITIPNAL INFPRIATIPN WUXGA series Projection image size is from 21” to 302” (0.5m to 7.7m). Top View Screen Screen (Width) Projection Distance Width Screen (Height) Screen Side View Offset Projection Distance 16:9 Screen size Mrojection distance Offset diagonal (inches) (meters) (feet) (meters) (cm)
  • Page 54 ADDITIPNAL INFPRIATIPN Mrojector dimensions and ceiling mount installation To prevent damage to your projector, please use only approved InFocus ceiling mounts: https://www.infocus.com/accessories/mounts If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...
  • Page 55 ADDITIONAL INFORMATION RS232 Commands and Protocol Function List RS232 Pin Assignments Descriptor timing -B0 (Detail timing) RS232 Protocol Function List Baud Rate: 19200 Parity Bit: None Data Bit: 8 Stop Bit: 1 Laser on delay = 20s Power Down delay = 5s (IN1048SL) Power Down delay = 125s (IN1049SL) Source change delay = 8s Intercommand delay minumum = 500ms...
  • Page 56 ADDITIPNAL INFPRIATIPN Blank Key (AV Iute) return code (ok) ON & return (BLK1!) (0-1,1) OFF & return (BLK0!) (0-1,0) Source return code (ok) Status ? (SRC?) (0-22,n) n=0-22 Computer1 (VGA IN 1) (SRC0) Computer2 (VGA IN 2) (SRC1) VIDEO (SRC11) S-VIDEO (SRC12) HDMI1...
  • Page 57 ADDITIPNAL INFPRIATIPN Total Hours (Light Source Hours) return code (ok) Status ? (LMT?) (0-65535,n) n=lamp hours Ceiling Set return code (ok) Status ? (CEL?) (0-3,n) n=0,1,2,3 Front table (CEL0) Front ceiling (CEL1) Rear table (CEL2) Rear ceiling (CEL3) Front table & return (CEL0!) (0-3,0) Front ceiling &...
  • Page 58 ADDITIPNAL INFPRIATIPN Key Mad return code (ok) Down (NAV2) Select (NAV3) Left (NAV4) Right (NAV5) Menu & return (NAV0!) (0-5,0) Up & return (NAV1!) (0-5,1) Down & return (NAV2!) (0-5,2) Select & return (NAV3!) (0-5,3) Left & return (NAV4!) (0-5,4) Right &...
  • Page 59 ADDITIPNAL INFPRIATIPN Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...
  • Page 60 ADDITIPNAL INFPRIATIPN Pther problems The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Remote control problems If the remote control does not work ‡...
  • Page 61 ADDITIPNAL INFPRIATIPN Warning indicators When the warning indicators (see below) light up or flash, the projector will automatically shutdown: ‡ “Lamp” LED indicator is lit red and if “Power” indicator flashes red. ‡ “Temp” LED indicator is lit red and if “Power” indicator flashes red. This indicates the projector has overheated.
  • Page 62 ADDITIPNAL INFPRIATIPN Specifications Pptical Description Maximum resolution 1920x1200@60Hz(RB) ‡ 1080p Native resolution ‡ WUXGA Lens Manual zoom, focus and verical shift ‡ 1080p: 20” ~ 300” (51cm ~ 762cm) Image size (diagonal) ‡ WUXGA: 21” ~ 302” (53cm ~ 767cm) ‡...
