Icom IC-910H Service Manual page 8

Nov. 2008
[PLL UNIT]
REF ORDER
NO. NO.
C404 4030006950 S.CER C1608 CH 1H 040C-T
C405 4030009500 S.CER C1608 CH 1H 0R5B-T
C407 4030006860 S.CER C1608 JB 1H 102K-T
C408 4030006860 S.CER C1608 JB 1H 102K-T
C410 4030011340 S.CER C1608 CH 1H 471J-T
C413 4030006960 S.CER C1608 CH 1H 050C-T
C421 4030006980 S.CER C1608 CH 1H 070D-T
C422 4030006930 S.CER C1608 CH 1H 020C-T
C423 4030006980 S.CER C1608 CH 1H 070D-T
C426 4030006960 S.CER C1608 CH 1H 050C-T
C428 4030006980 S.CER C1608 CH 1H 070D-T
C430 4030006960 S.CER C1608 CH 1H 050C-T
C471 4030008920 S.CER C1608 JB 1H 473K-T
C472 4030012600 S.CER C2012 JB 1A 105M-T
C474 4030007090 S.CER C1608 CH 1H 470J-T
C475 4030006860 S.CER C1608 JB 1H 102K-T
C476 4030006860 S.CER C1608 JB 1H 102K-T
C478 4030011600 S.CER C1608 JB 1E 104K-T
C480 4030006860 S.CER C1608 JB 1H 102K-T
C481 4030006860 S.CER C1608 JB 1H 102K-T
C482 4030006860 S.CER C1608 JB 1H 102K-T
C483 4030006860 S.CER C1608 JB 1H 102K-T
C484 4030006860 S.CER C1608 JB 1H 102K-T
C485 4030006920 S.CER C1608 CH 1H 010C-T
C487 4030006860 S.CER C1608 JB 1H 102K-T
C488 4030006860 S.CER C1608 JB 1H 102K-T
C501 4030008920 S.CER C1608 JB 1H 473K-T
C502 4510008540 S.ELE EEE1CA100SR
C503 4510008540 S.ELE EEE1CA100SR
C504 4030008920 S.CER C1608 JB 1H 473K-T
C505 4030006860 S.CER C1608 JB 1H 102K-T
C511 4030006880 S.CER C1608 JB 1H 472K-T
C512 4510008500 S.ELE EEE1CA101WP
C513 4030006860 S.CER C1608 JB 1H 102K-T
C514 4030006880 S.CER C1608 JB 1H 472K-T
C515 4030006980 S.CER C1608 CH 1H 070D-T
C535 4030006880 S.CER C1608 JB 1H 472K-T
C541 4030006860 S.CER C1608 JB 1H 102K-T
C542 4030006860 S.CER C1608 JB 1H 102K-T
C543 4030006880 S.CER C1608 JB 1H 472K-T
C544 4030007030 S.CER C1608 CH 1H 150J-T
C545 4030006860 S.CER C1608 JB 1H 102K-T
C551 4030006860 S.CER C1608 JB 1H 102K-T
C552 4030006880 S.CER C1608 JB 1H 472K-T
C553 4030006860 S.CER C1608 JB 1H 102K-T
C554 4030007050 S.CER C1608 CH 1H 220J-T
C555 4030006880 S.CER C1608 JB 1H 472K-T
C556 4030006920 S.CER C1608 CH 1H 010C-T
C557 4030007050 S.CER C1608 CH 1H 220J-T
C558 4030006860 S.CER C1608 JB 1H 102K-T
C559 4030007110 S.CER C1608 CH 1H 680J-T
C560 4030007110 S.CER C1608 CH 1H 680J-T
C574 4030006880 S.CER C1608 JB 1H 472K-T
C575 4030011600 S.CER C1608 JB 1E 104K-T
C601 4030007170 S.CER C1608 CH 1H 221J-T
C602 4030007100 S.CER C1608 CH 1H 560J-T
C603 4030011330 S.CER C1608 CH 1H 391J-T
C604 4030007160 S.CER C1608 CH 1H 181J-T
C605 4030007160 S.CER C1608 CH 1H 181J-T
C608 4030007110 S.CER C1608 CH 1H 680J-T
C609 4030006900 S.CER C1608 JB 1H 103K-T
C610 4030006900 S.CER C1608 JB 1H 103K-T
C611 4030006900 S.CER C1608 JB 1H 103K-T
C613 4030006880 S.CER C1608 JB 1H 472K-T
C614 4030006900 S.CER C1608 JB 1H 103K-T
C615 4030006900 S.CER C1608 JB 1H 103K-T
C616 4030006900 S.CER C1608 JB 1H 103K-T
C617 4030006900 S.CER C1608 JB 1H 103K-T
C618 4030011600 S.CER C1608 JB 1E 104K-T
C619 4550007520 S.TAN F931A106MAABMA
C620 4030007130 S.CER C1608 CH 1H 101J-T
C621 4030007130 S.CER C1608 CH 1H 101J-T
C701 4030007170 S.CER C1608 CH 1H 221J-T
C702 4030007100 S.CER C1608 CH 1H 560J-T
C703 4030011330 S.CER C1608 CH 1H 391J-T
C704 4030007160 S.CER C1608 CH 1H 181J-T
C705 4030007160 S.CER C1608 CH 1H 181J-T
C708 4030007110 S.CER C1608 CH 1H 680J-T
C709 4030006900 S.CER C1608 JB 1H 103K-T
C710 4030006900 S.CER C1608 JB 1H 103K-T
C711 4030006900 S.CER C1608 JB 1H 103K-T
C713 4030006880 S.CER C1608 JB 1H 472K-T
C714 4030006900 S.CER C1608 JB 1H 103K-T
C715 4030006900 S.CER C1608 JB 1H 103K-T
C716 4030006900 S.CER C1608 JB 1H 103K-T
C717 4030006900 S.CER C1608 JB 1H 103K-T
C718 4030011600 S.CER C1608 JB 1E 104K-T
C719 4550007520 S.TAN F931A106MAABMA
C720 4030007130 S.CER C1608 CH 1H 101J-T
C721 4030007130 S.CER C1608 CH 1H 101J-T
J1 6510022541 S.CON 20FMN-BMTTR-A-TBT(LF)(SN)
J541 6510007020 CON TMP-J01X-V6
DESCRIPTION
[MAIN UNIT]
REF ORDER
NO. NO.
IC101 1110003141 IC LA1150N-E
IC201 1110004840 S.IC NJM1496V-TE1-#ZZZB
IC351 1110004870 S.IC TA4101F (TE12L.F)
IC401 1110003491 S.IC TA31136FNG(D,EL)
1110003490 S.IC TA31136FN(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
IC451 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC452 1130008230 S.IC BU4053BCFV-E2
IC701 1110003141 IC LA1150N-E
IC801 1180002040 REG BA09T
IC803 1110002021 IC TA7805S(Q)
IC851 1110004870 S.IC TA4101F (TE12L.F)
IC951 1110003491 S.IC TA31136FNG(D,EL)
1110003490 S.IC TA31136FN(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
1110003491 S.IC TA31136FNG(D,EL)
IC1001 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1002 1130008230 S.IC BU4053BCFV-E2
IC1101 1130007041 S.IC TC7W32F(TE12L,F)
IC1451 1130007570 S.IC BU4094BCFV-E2
IC1461 1130007570 S.IC BU4094BCFV-E2
IC1471 1130007570 S.IC BU4094BCFV-E2
IC1481 1130007570 S.IC BU4094BCFV-E2
IC1491 1130007570 S.IC BU4094BCFV-E2
IC1511 1130007570 S.IC BU4094BCFV-E2
IC1521 1110004310 S.IC M62352GP 75EC
IC1522 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1531 1130008230 S.IC BU4053BCFV-E2
IC1551 1130008230 S.IC BU4053BCFV-E2
IC1552 1130008230 S.IC BU4053BCFV-E2
IC1601 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1651 1110005240 S.IC NJM4565M-TE1-#FMZB
IC1652 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1653 1130008230 S.IC BU4053BCFV-E2
IC1654 1110005240 S.IC NJM4565M-TE1-#FMZB
IC1701 1140005281 S.IC UPC5023GS-077-E1-A
IC1801 1130008230 S.IC BU4053BCFV-E2
IC1802 1130008230 S.IC BU4053BCFV-E2
IC1803 1190000350 S.IC M62363FP-650C
IC1804 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1806 1130008230 S.IC BU4053BCFV-E2
IC1807 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1808 1110003300 S.IC M5282FP 70CD
IC1809 1110003300 S.IC M5282FP 70CD
IC1852 1110002541 IC LA4445-E
Q1 1580000540 S.FET 3SK131-T2-LA
Q21 1590000430 S.TRA DTC144EUA T106
Q22 1590000680 S.TRA DTC114EUA T106
Q51 1580000540 S.FET 3SK131-T2-LA
Q52 1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002690 S.TRA 2SC4116-GR (TE85R)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q101 1560000561 S.FET 2SK882-GR(TE85L,F)
Q102 1560000561 S.FET 2SK882-GR(TE85L,F)
Q103 1590001650 S.TRA XP4601(TX)
Q105 1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002690 S.TRA 2SC4116-GR (TE85R)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q106 1590000430 S.TRA DTC144EUA T106
Q107 1590001660 S.TRA XP4312(TX)
Q151 1590001660 S.TRA XP4312(TX)
Q152 1590001660 S.TRA XP4312(TX)
Q153 1590001660 S.TRA XP4312(TX)
Q201 1590000430 S.TRA DTC144EUA T106
Q251 1590001660 S.TRA XP4312(TX)
Q252 1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000770 S.TRA 2SA1586-GR (TE85R)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
1510000771 S.TRA 2SA1586-GR(TE85L,F)
Q253 1590000670 S.TRA FMW1 T148
Q254 1530002691 S.TRA 2SC4116-GR(TE85R,F)
1530002690 S.TRA 2SC4116-GR (TE85R)
1530002691 S.TRA 2SC4116-GR(TE85R,F)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7
DESCRIPTION
[EUR]
[USA]
[AUS]
[SWE]
[USA-1]
[KOR]
[ITR]
[CHN]
[EUR]
[USA]
[AUS]
[SWE]
[USA-1]
[KOR]
[ITR]
[CHN]
[EUR]
[USA]
[AUS]
[SWE]
[USA-1]
[KOR]
[ITR]
[CHN]
[EUR]
[USA]
[AUS]
[SWE]
[USA-1]
[KOR]
[ITR]
[CHN]
[EUR]
[USA]
[AUS]
[SWE]
[USA-1]
[KOR]
[ITR]
[CHN]
[EUR]
[USA]
[AUS]
S.=Surface mount
