Concerning Compact Discs

Only compact discs bearing this mark can be used with this unit.
However, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage
the unit.
CD-R and CD-RW discs recorded with the audio
CD format can be played back, though some may
not be played back because of the disc characteris-
tics or recording condition.
How to remove a disc from its case
How to hold a disc
If the disc surface is dirty
Wipe it with a damp cloth and then wipe dry.
Wipe from the center toward the outer edge.
Play surface (shiny surface)
If moisture has formed on a disc
When moisture has formed because the
disc was brought suddenly into a warm
room from a cold environment, wipe off
the moisture using a soft dry cloth.
When storing discs
Avoid locations which are
• Exposed to direct sunlight.
• Susceptible to high levels of humidity or
dust.
• Directly exposed to heat from a heating
appliance.
• On top of a car dashboard or near the
rear window.
Precautions
Before using this unit, be sure to read the applicable items of the
operating instructions and these safety-suggestions carefully.
Afterwards keep them handy for future reference. Take special
care to follow the warnings indicated on the unit itself as well as
in the operating instructions.
Safety
1. Care of AC adaptor - The cord of the AC adaptor should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them. Never take hold of the AC
adaptor if your hand is wet, and always grasp the plug when
connecting or disconnecting it.
2. Disconnect when not in use - When not in use, be sure to
disconnect the AC adaptor from the AC power outlet.
3. Batteries - If the set is not used for a long period of time or is
used only from an AC power source, remove all the batteries to
prevent potential damage due to battery leakage. Do not mix
(old and new ) batteries or different types of batteries.
Installation
I Environment
1. Condensation - Moisture may form on the lens in the follow-
ing conditions...
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• when the unit is suddenly moved from a cold environment
to a warm one. If moisture forms inside this unit, it may not
operate properly. To correct this problem wait about one
hour for the moisture to evaporate.
I Placement
1. Foreign Material - Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or
shock.
2. Magnetism - The unit should be situated away from equip-
ment or devices that generate strong magnetic fields.
3. Stacking - Do not place any objects on top of the unit.
1
How to store the disc in its case
Label side up
Handling precautions
• On the label side (the side with writing)
Do not write anything using a pencil,
ball-point pen, etc. Do not use adhesive
paper or labels.
• On the disc (shiny) side
Handle this side carefully to keep it free
from fingerprints or scratches. Do not
use record cleaners, solvents, etc.
• Do not attach labels or stickers to CDs.
Do not use CDs with exposed adhesive
from tape or left over peeled off stickers.
• Do not use scratch-proof protectors or
covers other than those specified for use
with this unit.
Maintenance
(See page 3 for details.)
Clean the cabinet, panel and controls with a soft cloth lightly
moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
1. Damage Requiring Service - The unit should be serviced by
qualified service personnel when:
(a) The AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not appear to operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped, or the enclosure damaged.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open
and interlock failed or defeated. Avoid direct ex-
posure to beam.
3. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualitied service personnel.
PORTABLE CD PLAYER XL-PM25BK
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the player. Retain this
information for future reference.
Model No.
Serial No.
INSTRUCTIONS

Supplied Accessories

Check the packing carton for these accessories.
AC adaptor (AA-R4513) ................................................................................................................. 1 pc.
Stereo headphones .......................................................................................................................... 1 pc.
Remote control ................................................................................................................................. 1 pc.
Rechargeable batteries (BN-R1211J) .......................................................................................... 2 pcs.
Use numbers in parentheses when asking for replacement parts.
Thank you for purchasing this JVC product. Please read these instructions carefully before starting
operation to be sure to obtain optimum performance and a longer service life from the unit.
EN
0403SKMCREORI
THE FOLLOWING NOTICES ARE APPLIED ONLY FOR THE U.S.A.:
POWERED BY NICKEL-CADMIUM BATTERY.
MUST BE RECYCLED OR DISPOSED OF PROPERLY.
ATTENTION:
The product that you have purchased is powered by a re-
chargeable battery. The battery is recyclable. At the end of
it's useful life, under various state and local laws, it may be
illegal to dispose of this battery into the municipal waste
stream.
Check with your local solid waste officials for details in
your area for recycling options or proper disposal.
CAUTION!
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or tele-
vision reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to cor-
rect the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and re-
ceiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Any unauthorized changes or modifications to this equip-
ment would void the user's authority to operate this device.
LVT0997-001A [J,C]
Ni-Cd
