2. Installation
If the default address and interrupt settings are sufficient, the DS-200/300
can be quickly installed and put to use. The factory defaults are listed in
Figure 1.
PORT
Serial 0
Serial 1
Figure 1 --- Default address and IRQ settings for DS-200/300
The output of the DS-200/300 is two 9-pin D-connectors labeled CN1
(serial 0) and CN2 (serial 1).
1. If the default settings are correct, skip to step 2, otherwise refer to
sections 4 and 6 of this document for detailed information on how
to set the address and IRQ level.
2. Turn off the power of the computer system in which the
DS-200/300 is to be installed.
3. Remove the system cover according to the instructions provided
by the computer manufacturer.
4. Install the DS-200/300 in any vacant expansion slot. The board
should be secured by installing the Option Retaining Bracket
(ORB) screw.
5. Replace the system cover according to the instructions provided by
the computer manufacturer.
6. Attach and secure the cable connectors to the desired equipment.
DS-200/300 User's Manual
ADDRESS
IRQ
3F8 hex
4
2F8 hex
3
ENABLED
YES
YES
2-1
