Quatech DSP-100 User Manual

Dual channel rs-232 pcmcia asynchronous adapter for pcmcia card standard compatible machines
Hide thumbs Also See for DSP-100:
Table of Contents

Advertisement

Quick Links

Dual Channel RS-232 PCMCIA
for PCMCIA Card Standard compatible machines
INTERFACE CARDS FOR IBM PC/AT AND PS/2
QUATECH, INC.
5675 Hudson Industrial Parkway
Hudson, Ohio 44236
DSP-100
Asynchronous Adapter
User's Manual
TEL: (330) 434-3154
FAX: (330) 434-1409
www.quatech.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSP-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Quatech DSP-100

Summary of Contents for Quatech DSP-100

  • Page 1 Dual Channel RS-232 PCMCIA Asynchronous Adapter for PCMCIA Card Standard compatible machines User's Manual INTERFACE CARDS FOR IBM PC/AT AND PS/2 QUATECH, INC. 5675 Hudson Industrial Parkway Hudson, Ohio 44236 DSP-100 TEL: (330) 434-3154 FAX: (330) 434-1409 www.quatech.com...

  • Page 2: Warranty Information

    No representation is made regarding the suitability of this product for any particular purpose. Quatech Inc. reserves the right to edit or append to this document or the product(s) to which it refers at any time and without notice.

  • Page 3: Declaration Of Conformity

    Application of Council Directive: Standards to which Conformity is Declared: Type of Equipment: Equipment Class: Product Name: Model Number : DSP-100 User's Manual (Rev. G and later) Quatech, Inc. 662 Wolf Ledges Parkway Akron, OH 44311 (USA) 89/336/EEC * EN50081-1...

  • Page 4: Table Of Contents

    Installing a DSP-100 Under Windows 2000 ........

  • Page 5: Introduction

    The DSP-100 is a dual channel RS-232 asynchronous serial adapter for systems equipped with PCMCIA Type II and/or Type III expansion sockets. The DSP-100 is a PCMCIA Type II (5 mm) card and is PCMCIA PC Card Standard Specification 2.1 compliant.
  • Page 6 This page intentionally left blank. DSP-100 User’s Manual (Rev. G and later)

  • Page 7: Dos/Windows 3

    DOS support is not guaranteed. Two configuration software programs are provided with the DSP-100: a Client Driver, and a card Enabler. Both of these programs are executed from DOS (before entering Windows) and allow operation of the DSP-100 in both the DOS and Windows 3.x environments.

  • Page 8: Dsp-100 Client Driver For Dos

    2.1 DSP-100 Client Driver for DOS In order to use the DSP-100 Client Driver, the system must be configured with Card and Socket Services software. Card and Socket Services software is not provided with the DSP-100 but is available from Quatech.

  • Page 9: Command Line Options

    Card and Socket Services. Iirq specifies the interrupt level (IRQ) of the DSP-100 in decimal. irq must be one of the following values: 3, 4, 5, 7, 9, 10, 11, 12, 14, 15, or 0 if no IRQ is desired. If this option is omitted, an interrupt level will be assigned by Card and Socket Services.
  • Page 10 In example 4, a single command line argument is provided. Because the parameter order is not significant, the Client Driver will attempt to configure a DSP-100 inserted into any socket with a base address of 300H and IRQ 5. If address 300H or IRQ 5 is unavailable, the DSP-100 will not be configured.

  • Page 11: Common Problems

    DSP-100 is to be installed. In this example, the Client Driver will attempt to configure a DSP-100 inserted into socket 0 with a base address of 300H and IRQ 5. If the DSP-100 is inserted into socket 1, the Client Driver will attempt to configure it with base address 340H and IRQ 10.

  • Page 12: Dsp-100 Enabler For Dos

    Some versions of Card and Socket Services dated before 1993 do not support general purpose I/O cards. If after careful installation of the Client Driver the DSP-100 does not configure or operate properly, an updated version of Card and Socket Services may be required. Card and Socket Services software is available from Quatech.

  • Page 13: Command Line Options

    Iirq specifies the interrupt level (IRQ) of the DSP-100 in decimal. irq must be one of the following values: 3, 4, 5, 7, 9, 10, 11, 12, 14, 15, or 0 if no IRQ is desired. This option is required if the 'R' option is not used.
  • Page 14 2.2.1.2 Example 2 DSP130EN.EXE (s0,b300,i5) In example 2, the Enabler will configure the DSP-100 in socket 0 with a base address of 300H and IRQ 5 using a configuration memory window at segment D000. 2.2.1.3 Example 3 DSP130EN.EXE (i10,h,b340,s1)

  • Page 15: Common Problems

    2.2.1.5 Example 5 DSP130EN.EXE (o1,i5,b340,s1) In example 2, the Enabler will configure the DSP-100 in socket 1 with a base address of 340H and IRQ 5 using a configuration memory window at segment D000. 2.2.1.6 Example 6 DSP130EN.EXE (s0,b300,i5,r) In example 6, the Enabler will release the configuration used by the DSP-100 in socket 0 using a configuration memory window at segment D000.
  • Page 16 Card and Socket Services Software: In order to use the DSP-100 Enabler for DOS, the system MUST NOT be configured with Card and Socket Services software. If a Card and Socket Services software is installed, the Enabler may interfere with its operation and with the device(s) it controls. For systems configured with Card and Socket Services, the DSP-100 Client Driver is the recommended method of configuration.

  • Page 17: Windows 95/98/Millennium (Me)

    3. Windows 95/98/Millennium (ME) To allow easy configuration of the DSP-100, a Windows 95/98/ME "INF" configuration file has been written for the hardware. 3.1 Installing a DSP-100 Under Windows 95/98/ME 1. Insert the DSP-100 into any available PC Card socket.

  • Page 18: Viewing Resource Settings With Device Manager

    3. The DSP-100 “parent device” belongs to this hardware class. The device name for the DSP-100 is Quatech DSP-100: Dual RS-232 Serial Port PC Card. 4. Open the Properties dialog for the DSP-100 device, then click the Resources tab to view the Input/Output Range and Interrupt Request resource allocations.

  • Page 19: Frequently Asked Questions

    A problem noted on some systems is after a basic configuration has been manually selected the basic configurations list for the DSP-100 is no longer available. The solution to this problem is to check the “Use Automatic Settings” box and allow Windows 95/98/ME to reconfigure the DSP-100 card.
  • Page 20 Base I/O Address Resource Modification Not Allowed: The DSP-100 is configured to allow only a fixed number of base I/O addresses. To change the I/O address resources for the DSP-100 select another “Basic Configuration”. Refer to the Basic Configurations table for a list of the availabe I/O address resources for the DSP-100.

  • Page 21: Installing A Dsp-100 Under Windows 2000

    4 Windows 2000 To allow easy configuration of the DSP-100, a Windows 2000 "INF" configuration file has been written for the hardware. 4.1 Installing a DSP-100 Under Windows 2000. 1. Insert the Quatech COM CD into an available CD-ROM. 2. Insert the DSP-100 into any available PC Card socket.
  • Page 22 4. Double click ‘Serial Port Adapters’ 5. Double click ‘Drivers’ DSP-100 User’s Manual (Rev. G and later)
  • Page 23 6. Double click on ‘Windows 2000, XP, for PCI, PCMCIA, ISA’ 7. Click on ‘qserbrd’ and select open Windows 2000...

  • Page 24: Dsp-100 Resource Settings In Windows 2000

    9. The same process as above in steps 1-9 will apply for the next file ‘qserpt.inf’. In step 7 be sure to choose ‘qserpt.inf’ and select ‘Open’. 4.2 DSP-100 Resource Settings in Windows 2000 Windows 2000 maintains a registry of all known hardware installed within the computer. Inside this hardware registry Windows 2000 keeps track of all the computer's resources, such as base I/O addresses, IRQ levels, and DMA channels.
  • Page 25 Windows 2000 handles the DSP-100 as a "parent/child device". v The DSP-100 is the "parent device" and is listed under the hardware class Quatech Multiport Serial Devices in the device manager. v Each serial port is a "child device" of the "parent device" DSP-100 (Quatech PCMCIA Serial Port).

  • Page 26: Viewing Resource Settings With Device Manager

    3. The DSP-100 “parent device” belongs to this hardware class. The device name for the DSP-100 is Quatech DSP-100 PCMCIA Two-Port RS-232 Serial Adapter. 4. Open the Properties dialog for the DSP-100 device, then click the Resources tab to view the Input/Output Range and Interrupt Request resource allocations. Examine and remember the Input/Output Range, then close the properties window.

  • Page 27: Changing Resource Settings With Device Manager

    6. Use the COM Port device names (COM5, COM6, etc.) to access any of the particular serial ports on the DSP-100. This name is required by a Windows 2000 application when accessing a particular port. 4.2.2 Changing Resource Settings with Device Manager 1.
  • Page 28 DSP-100 User’s Manual (Rev. G and later)
  • Page 29 460,800 921,600 5. Open the Properties dialog for the DSP-100 device, then click the Resources tab to view the Input/Output Range and Interrupt Request resource allocations. If options that are not available on the preceding pages are required, a different basic configuration will have to be selected.
  • Page 30 6. Select a Basic Configurations that displays "No conflicts" in the bottom display region titled Conflicting Device List from the drop down list. 4-10 I/O Range*** Clock Scratch Pad/ Speed Normal Normal Scratch Pad Scratch Pad Memory Scratch Pad Mapped DSP-100 (Rev. G and later) User’s Manual...
  • Page 31 Do not select a value that causes a conflict with any other installed hardware. 9. If any changes have been made to the DSP-100’s configuration the card will automatically be reconfigured to the new resources specified. Any time a PCMCIA card of this type is inserted Windows 2000 will attempt to configure the card at these resource settings.
  • Page 32 This page intentionally left blank. DSP-100 User’s Manual (Rev. G and later)

  • Page 33: Windows Nt

    5 Windows NT 5.1 Installing DSP-100 To allow easy configuration of the DSP-100 the Quatech Device Manager for Windows NT has been written for the hardware. This configuration utility supports the DSP-100 only in block addressing mode. To begin the installation, open Windows Explorer and search for the ‘Setup.exe’ command to install the Quatech Device Manager.
  • Page 34 1. Locate and double click the Quatech Device Manager icon on the desktop Device Manager Icon on Desktop 2. Click the ‘Add’ button at the bottom of the Quatech Device Manager Window DSP-100 User’s Manual (Rev. G and later)
  • Page 35 3. Follow the steps for the ‘Add Quatech Hardware Wizard’. Windows NT...
  • Page 36 PCMCIA Card and re-boot the computer. Additional help is available online The DSP-100 PC Card should now be configured. In the future, Windows NT will automatically recognize and configure the DSP-100. Note: Windows NT does not support ‘Plug and Play’ for PCMCIA cards. The PCMCIA Card must be inserted prior to starting Windows NT and can not be removed and reinserted while Windows NT is running.

  • Page 37: External Connections

    6. External Connections An adapter cable is included with the DSP-100 to convert the 9-pin PCMCIA output connector into a standard D-9 male connector, data terminal equipment (DTE), as shown in the figures below. External Connections Figure 14. DSP-100 Adapter Cable.
  • Page 38 This page intentionally left blank. DSP-100 User’s Manual (Rev. G and later)

  • Page 39: Specifications

    7. Specifications Bus Interface Physical Dimensions Maximum Baud Rate Power Requirements Connector Specifications PCMCIA PC Card Standard 2.1 compliant Type II PCMCIA card (5mm) 921.6K +5 volts 30 mA (typical) 45 mA (maximum) Adapter to two standard male...
  • Page 40 DSP-100 User's Manual Revision 3.12 May 2002 P/N 940-0088-312 Quatech, Inc.
