Form P7373
04576070
Edition 2
June 2009
Random Orbital Sander
Model R025A–CFS
Installation and Maintenance
Information
Save These Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the R025A–CFS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ingersoll-Rand R025A–CFS

  • Page 1 Form P7373 04576070 Edition 2 June 2009 Random Orbital Sander Model R025A–CFS Installation and Maintenance Information Save These Instructions...
  • Page 2 Product Safety Information Intended Use: A Rotary Air Sander, Polisher or Buffer is a compressed air powered, hand-held, rotary power tool equipped with a flexible pad or drum that is driven in a rotary or rotary/orbital motion. A Sander has a fiber disc or abrasive paper attached to the pad or a band attached to the drum and is used for material removal.
  • Page 3 R025A–CFS Series Random Orbital Sander Exploded View (Dwg. TPA1667) 04576070_ed2...
  • Page 4: Part Description

    R025A–CFS Series Random Orbital Sander Parts List Item Part Description Part Number Item Part Description Part Number Housing (includes pin) 04561429 39442 Valve Stem 48065–2 Counterbalance (includes needle 49808–5 Lever 48274–2 bearing) Roll Pin Y178–134 Spindle Assembly (includes bearing) 49807 Grip Ring 49798 Retaining Ring...
  • Page 5: Maintenance

    Maintenance WARNING Always wear eye protection when operating or performing maintenance on this tool. Always turn off the air supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this tool or before performing any maintenance on this tool. Lubrication Inject 0.5 to 1.0 cc of Ingersoll Rand No.10 Oil into the air Inlet Whenever one of the Sanders is disassembled for overhaul or...
  • Page 6 Assembly of the Throttle 10. Install the Retaining Ring (13) in the groove in the 1. Install Valve Stem (2) in Housing (1) so that the hole in the Valve Counterbalance with the bow in the Retaining Ring positioned as Stem aligns with the hole in the Housing to accept the Tip shown in Drawing TPA1667.
  • Page 7: Troubleshooting Guide

    Troubleshooting Guide Trouble Probable Cause Solution Low power or low free speed Insufficient air pressure Check air line pressure at the Inlet of the tool. It must be 90 psig (6.2 bar/620 kPa). Cold air head frozen Shut down the CFS200A Unit and allow the tool to warm for about 1/2 hour.
  • Page 8 www.irtools.com © 2009 Ingersoll Rand Company...
