- Page 1 Form: P7187 03541000 Edition 3 June 2009 Random Orbital Sander Models R025A-( )-( ) and R026A-( )--( ) Installation and Maintenance Information Save These Instructions...
-
Page 2: Model Identification
Product Safety Information Intended Use: A Rotary Air Sander, Polisher or Buffer is a compressed air powered, hand-held, rotary power tool equipped with a flexible pad or drum that is driven in a rotary or rotary/orbital motion. A Sander has a fiber disc or abrasive paper attached to the pad or a band attached to the drum and is used for material removal. -
Page 3: Air Supply Requirements
Routine Lubrication Requirements Air line debris, moisture and carry-over oil from the compressor can EVERY 160 HOURS OF TOOL OPERATION, Inject grease # 68, one restrict the muffler and leave contaminants in the motor. Every 160 or two strokes, thru threaded end of spindle (27) for lubrication of hours of tool operation, or sooner if motor speeds drop below ac- needle bearing contained in counterbalance (26). - Page 4 R025A–( )-( ) and RO26A-( )--( ) Series Random Orbital Sander Exploded View Face with rounded O.D. on this side 11 [Not used on models RO2( )A-VL] 31 [Used on models RO2( )A-VL] 12 [Used on models RO2( )A-C( )V] 13 [Used on models RO2( )A-PS( )] Install Retaining Ring (15) As shown (Bowed away from Bearing)
-
Page 5: Part Description
R025A–( )-( ) and RO26A-( )--( ) Series Random Orbital Sander Parts List Item Part Description Part Number Item Part Description Part Number Housing (includes pin) 49816-2 Seal IR49819 Valve Stem IR48065–2 Rotor 356-53 Lever See Table Blade (5) IR48254-1 Roll Pin 356-15 Front End Plate... -
Page 6: Maintenance
Maintenance WARNING Always wear eye protection when operating or performing maintenance on this tool. Always turn off the air supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this tool or before performing any maintenance on this tool. NOTICE •... - Page 7 Notes...
