Berkel X13 Owner's/Operator's Manual
Hide thumbs
Also See for X13:
- Service manual (36 pages) ,
- Owner's/operator's manual (16 pages) ,
- Parts list and electrical diagram (14 pages)
Table of Contents
Advertisement
NOTICIA IMPORTANTE
Este manual contiene importantes instrucciones
de seguridad que deben ser seguidas el pie de la
letra cuando utilice esta maquina.
16 • X13 & X13A O
WNER
/O
M
PERATOR
ANUAL
O
/O
WNER
M
ANUAL
M
ODELS
X13 & X13A
S
LICERS
IMPORTANT NOTICE
This manual contains Important Safety
Instructions which must be strictly
followed when using this equipment.
PERATOR
BK46711 (February 2006)
Advertisement
Table of Contents
Related Manuals for Berkel X13
Summary of Contents for Berkel X13
- Page 1 This manual contains Important Safety de seguridad que deben ser seguidas el pie de la Instructions which must be strictly letra cuando utilice esta maquina. followed when using this equipment. 16 • X13 & X13A O WNER PERATOR ANUAL BK46711 (February 2006)
- Page 2 SING QUIPMENT Berkel’s slicers are designed to slice meat and other food products safely and efficiently. However, unless the operator is properly trained and supervised, there is the possibility of a serious injury. It is the responsibility of the owner to ensure that this slicer is used properly and safely, strictly following the instructions contained in this manual and any requirements of local law.
-
Page 3: Table Of Contents
Troubleshooting ............................ 11 Specifications ............................12 Optional Accessories ..........................13 Warranty .............................. 14 The Berkel Company • World’s Leading Manufacturer of Slicers and Food Processing Equipment ERKEL OMPANY 4406 Technology Drive · South Bend, Indiana 46628-9770 574/232-8222 · Fax 888/888-2838... -
Page 4: General Safety Instructions
EN CASO de que los membretes de ‘PELIGRO’ se desprendan de la mçquina o sean illegibles, llame al fabricante o a su representante de service Berkel para que lo reemplace sin cargo. 2 • X13 & X13A O 2 • X13 & X13A O... - Page 5 USE ONLY the attachments provided by the manufacturer. SHOULD any warning label on a machine come off or become unreadable, contact the manufacturer or your Designated Berkel Service Location for a free replacement. X13 & X13A O •...
-
Page 6: Equipment Description
QUIPMENT ESCRIPTION Pusher Slide Bar Pusher Handle ON/OFF Switch ( and speed/stroke selection on X13A) Product Table Handle Thickness Control Knob 4 • X13 & X13A O 4 • X13 & X13A O WNER PERATOR ANUAL wner peratOr anual... - Page 7 Locking Knob Pusher Gauge Plate Product Table Locking Knob Center Plate Mounting Stud Support Arm Automatic Product Table Engage Knob (X13A only) X13 & X13A O • 5 X13 & X13A O • 5 WNER PERATOR ANUAL wner peratOr anual...
-
Page 8: Intended Uses And Characteristics
The model X13 and X13A slicers are designed for cutting the following types of products: • Meat (without bones) • Cheese • Vegetables The following types of items are NOT suitable for slicing on the Model X13 or X13A slicers: • Non-food products • Frozen foods • Bone in products... -
Page 9: Operation
(i.e. disconnecting the power cord from the outlet). Once power is reconnected to the slicer, the default for automatic is slow speed and full stroke length. X13 & X13A O • 7 X13 &... -
Page 10: Cleaning And Sanitizing
Pull the product table to the front of the slicer. If it is an automatic slicer, make sure the engagement knob is in the manual position before pulling the product table to the front of the slicer. 8 • X13 & X13A O 8 • X13 & X13A O... - Page 11 19. Screw the red handle back to the pusher on the product table. Reinstall the center plate and the product table to the slicer. After assembly, spray with sanitizer solution and allow to air dry. 20. Plug in slicer. Place sharpener in proper storage location. X13 & X13A O • 9 X13 & X13A O •...
-
Page 12: Sharpening
8. After sharpening, clean the slicer as outlined on page 8. Repair Parts/Repair Service/Exploded Views Please contact your Designated Berkel Service Location (DBSL) for any repair parts/repair service re- quired on your Berkel slicer. For the nearest DBSL, please visit www.berkel.com... -
Page 13: Troubleshooting
2. Is the pilot light illuminated but blinking? If so, then push the stop button and then the start button. If the light is still blinking, then contact your nearest Designated Berkel Service Location. If you do not know your nearest Designated Berkel Service Location, then see page 10 for details on whom to contact. -
Page 14: Specifications
Automatic 98 lbs. Shipping Weight: Manual 118 lbs. Automatic 128 lbs. Voltage/Amperage: 115/60/1; 5.5 amps (208-230/60/1; 3.5 amps optional motor) Horsepower: 1/2hp 12 • X13 & X13A O 12 • X13 & X13A O WNER PERATOR ANUAL wner peratOr anual... -
Page 15: Optional Accessories
The juice cup is designed to fit onto the back lip at the receiving area of the slicer where it will catch the juice (tomatoes, for example) while allowing the product to drop freely on the receiving area. X13 & X13A O • 13 X13 &... -
Page 16: Warranty
These warranties are given only to the first purchaser from a Berkel Authorized Channel of Distribution. No warranty is given to subsequent transferees. The foregoing warranty provisions are a complete and exclusive statement of the warranty between the buyer and seller.
