Berkel X13AE Specifications

Model X13AE
Features
Berkel model X13AE automatic gravity feed slicer offers
a number of special features. A sanitary one piece
engineered polymer base and product table reduces
seams and joints while providing an FDA approved
surface for easy, effective cleaning. A removable and
submersible table mounted sharpener with borazon
stones for accurate sharpening. Precise thickness
control is achieved using a variable pitch barrel cam for
fine adjustment and wafer thin slices. The index knob
and operating controls are mounted outside of the drip
zone for quick and easy. The slicer can be automatically
operated in 3 speeds, and with 3 different stroke
lengths. A permanent ring guard protects the entire
non-slicing portion of the knife during slicing and
cleaning. A fence is included with the product table. A
simple kick stand supports the slicer for easy access to
clean under the slicer.
Accessories
!
Vegetable chute with pusher
!
Skewers with coring tool
!
Slaw tray
Approved By:
Date
Berkel Company ï 4406 Technology Drive ï South Bend, IN 46628-9700
574-232-8222 ï 800-348-025 ï
Form # SPC35-1106N
Item #___________________________________________
Model X13AE
Automatic Gravity Feed Slicer
Standard features
! 1-speed, 1/2 HP, permanently lubricated ball bearing
knife motor with thermal protection
! Automatic operation in three speeds; 20, 40 or 60
slices/ minute
! Three stroke lengths; 1/3, 2/3 and full stroke
! Furnished in 115/60/1, 7 am ps, AC, with 3 wire cord
and plug (see below for optional voltages)
! LED indicates power to the slicer
! One-piece FDA polymer base and product table for
reduced seams, accessibility and easy cleaning
!
Index knob conveniently located outside the drip zone
in the upper left to provide quick and easy access
!
Variable pitch barrel cam for ultra fine, precise slice
adjustment to a thickness of 1-5/16" (34mm)
!
13" (330mm) diameter, hollow ground, hardened
and polished forged stainless steel knife
! Large product table with extra capacity:
" Rectangles up to 10-
"
Squares up to 7 -
"
Rounds up to 8-
! Articulating and full length rear mounted meat pusher
to secure and advance products evenly, fence to hold
product during automatic operation
!
Ergonomic, multi-grip handle to advance product table
!
Submersible, removable product table mounted
sharpener for consistent sharpening and easy cleaning
!
Borazon sharpening stones for fast, accurate
sharpening and extended life
! No-volt release requires restarting the slicer after a
power interruption
! Permanent ring guard protects entire non-slicing
portion of the knife
! Sealed start/stop switches conveniently located on the
index knob housing out of the food zone
! Simple kick stand for easy cleaning under the slicer
Power Options
! 1/2 HP, 220/50/1 , 3.5 amps, AC, ETL Listed
! 1/2 HP, 220/60/1 , 3.5 amps, AC, ETL Listed
1 FAX 888-888-2838 ï www.berkel.com
Ω æ
î x 6- î (265 mm x 170 mm)
Ω
î (190 mm)
Ω
î (220 mm) diameter
