Lionel
#464R Sawmill
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 464R Sawmill and is the answer not in the manual?

Questions and answers

Summary of Contents for Lionel 464R Sawmill

  • Page 1 72-4147-250 7/04 Car available separately Lionel #464R Sawmill Owner’s Manual...
  • Page 2 Wiring and operating your Sawmill with TrainMaster Command Control Adjusting the Sawmill Replacing the lamps Notes Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ® , TrainMaster ®...
  • Page 3 Sawmill operates best at 10-14 volts (AC). As illustrated in Figure 1, you may connect the accessory to a separate power supply or to a Lionel Lockon (available separately, 6-62900) connected to your track. You will need the ends of the wires to be stripped back 1/4” to 3/8”.
  • Page 4 Sawmill directly in front of a Remote-Control Track section (available separately, 6-65530 for O gauge, 6-12746 or 6-65149 for O-27 gauge). Lionel Log Dump Cars (available separately) can be triggered to empty their loads onto the platform using the track section’s controller.
  • Page 5 Operating the Sawmill fter your Sawmill has been assembled and connected to the power supply, you are ready to start the action. Refer to Figure 4. 1. Drop the wooden boards into the slot in the Sawmill roof. 2. Place the logs on the unloading platform. 3.
  • Page 6: Wiring And Operation

    Wiring and operating your Sawmill with TrainMaster Command Control or operation in the TrainMaster Command Control environment, you may choose to wire your accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182). Refer to these manuals for additional information.
  • Page 7: Accessory Switch Controller Wiring And Operation

    Wiring and operating your Sawmill with TrainMaster Command Control (continued) Accessory Switch Controller wiring and operation Three wires (not included) are needed to connect your Sawmill to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 6. 1.
  • Page 8 Adjusting the Sawmill n the event that your Sawmill fails to operate correctly, follow these steps to align the belts inside the accessory. To protect the accessory’s electronics, power to the motor will be turned off in the Note! event that the belt becomes jammed. The lights will be unaffected. To restore normal operation, turn off power to the accessory for one minute, correct the jam, and then restore power.
  • Page 9 Adjusting the Sawmill (continued) 2. Lift away the Sawmill building, making sure that the wires are not pulled off the building. 3. Make sure that the conveyor belt is properly seated on the drive spools, as illustrated in Figure 8. Tabs fit into the Conveyor belt slots in the housing...
  • Page 10: Replacing The Lamps

    Sawmill is illuminated by two LEDs (light emitting diodes). The LEDs are expected to last for the life of the unit and are not user serviceable. Only an authorized Lionel Service Center should service this accessory, if it ever becomes necessary.
  • Page 11 Notes...
  • Page 12: Limited Warranty/Lionel Service

    Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
