LevelOne WNC-0305USB User Manual page 13

Encryption Method
Create with
Passphrase
Enter Key Manually
Passphrase
Confirm
802.1x Authentica-
tion Protocol
Configure WPA
Radius
To add a profile
1. On the Profile Manager tab, complete the settings on this screen.
2. Verify that the settings you configured are correct.
3. Click Save Profile.
4. Then click Apply Profile to connect the wireless network.
To delete a profile
1. On the Profile Manager tab, select the profile that you want to delete.
2. Click Delete Profile.
The available options depend on the Authentication method
selected above. The possible options are:
•
Security Off - No data encryption is used.
•
WEP - If selected, you must enter the WEP data shown
below. This WEP data must match the Access Point or
other Wireless stations.
•
AES, TKIP - These options are available with WPA-
PSK, WPA2-PSK, Select the correct option.
Enable this check box and enter a word or group of print-
able characters in the Passphrase box, select the desired
encryption to automatically configure the WEP Key.
Enable this check box and select the desired key in the
drop-down list. Then enter the key values you wish to use
and select the desired encryption. Other stations must have
matching key values.
*Support WEP Hex Key only.
For WPA-PSK and WPA2-PSK modes, you need to enter
the desired value (8~63 characters). Data is encrypted
using a 256Bit key derived from this key. Other Wireless
Stations must use the same key.
For WPA-PSK and WPA2-PSK modes, re-enter the value in
this field.
For WPA Radius and WPA2 Radius modes, select the
desired option in the drop-down list. The options are
EAP/TLS, Protected EAP(PEAP), Light EAP(LEAP)
For WPA Radius and WPA2 Radius modes, click this
button to open a sub-window where you can enter details of
the Radius Server.
