Technical data
Dimension
Height
Width
Depth
Weight
Succession of programs
Programs
Succession
Datas Energy Label
Energy Performance
Cleaning Performance
Drying Performance
Reference program
Specification/ PI-Expression
Program Daily 65˚C
Water consumtion
Energy consumption
Program duration
Program Eco 50˚C
Water consumtion
Energy consumption
Program duration
Noise level
- without door insulation
Detergent
Separate contained
- chamber I
- chamber II
Water connection
Water connection up to
Capacity
ADP262WH
8511 262 15513
85.0 cm + 1.5
59.8 cm
57 .0 cm
51.7 kg
see program diagram
1 - 2 - 3 - 4 - 5 - 6
C
C
C
Bio/ Normal 50˚
16 l
1.64 kWh
~ 100 min
20 l
1.44 kWh
~ 100 min
~ 57 dB (A)
15 - 25 ml
5 ml
~ 25 ˚C
60 ˚C
12 stand.
place
settings
Whirlpool Europe
Customer Service
Volume
Water
Basic/working level
Safety level
Overflow-level
Rinse aid
Clear rinse max.
Minimum for indication off 90
6 Dossier steps
Salt container
Flow Rates / Inlet Volumes
Spray pump
Drain pump
Height of drain hose max. 1.0
Height of drain hose min. 0.4
Length of drain hose max. 3.7
Length of drain hose min. 1.4
Water inlet electrovalve
Water Pressure
Inlet pressure
Spray pump pressure
Rotations
Spray pump - motor
Drainpump - Motor
Spray arm lower
Spray arm upper
Electrical Data
Base level
Voltage
Frequency
Total power
Fuses
Timer
Model
PCB Type
Basic step time
2 Normal times
S E R V I C E
4.4 l
12.0 l
13.5 l
3
150 cm
3
cm
± 0.5
3
1 - 6 cm
2 kg
70 l / min
18 l / min
m
m
m
m
lpm ± 2.5%
2.5
0.3 - 10 bar
0.32 bar
2800 RPM
3000 RPM
RPM ± 5
40
RPM ± 5
25
240 V
50 Hz
2.6 kW
16 A
Bitron Series 5000
B
7 .5 s
30/150 s
