29.06.1999 / Page 2
Doc. No: 4812 718 14566
Technical data
Dimension
Height
Width
Depth
Weight
Decor plate
Thickness max.
Width
Height
Weight max.
Electronic boards
Service boards
Serial boards
UB
DB
CB
Dataset
Succession of programs
Programs
Succession
Alarms
Refill salt
Refill rinse aid
Options
Zone washing
Delay function
Program information
Start indicator
Pre wash
Main wash
Drying
End
ADP 962/3 WHM
8542 962 10410
85.0
cm
59.7
cm
55.5
cm
52.7
kg
4
mm
583
mm
595
mm
1,8
kg
see spare part list
4619 720 78931
4619 720 78871
096621
096611
see program diagram
1-3-4b-5b-6b-7
Whirlpool Europe
Customer Service
Volume (normal program)
Water
Regeneration
Back rinse 3x
Prewash
Prewash/Zone washing
Main wash
Main wash/Zone washing 3.5 l
Intermediate rinse 1
Intermediate rinse 1/
Zone washing
Intermediate rinse 2
Intermediate rinse 2/
Zone washing
Clear rinse
Clear rinse/Zone washing 3.5 l
Safety / overflow
Measuring the level
Remove the coarse sieve, put in a measuring
meter into the sump, measure the hight of the
water level.
Detergent max.
Pre-wash
Main-wash
Rinse aid
6 Dosage steps
Water softener
Saltcontainer
Resin container
Regeneration dosage
Water pressure
Inlet pressure
Spray pump pressure
Rotations
Spray pump motor
Drain pump motor
Spray arm lower
Spray arm upper
Ceiling rotor
S E R V I C E
Volume
Level
0.3 l
15 mm
1.0 l
68 mm
4.8 l
122 mm
4.0 l
120 mm
4.5 l
121 mm
117 mm
4.0 l
120 mm
3.5 l
117 mm
4.0 l
120 mm
3.5 l
117 mm
4.0 l
120 mm
117 mm
8.5 l
141 mm
10
cm
45
cm
125
cm
1 - 6
ml
2
kg
900
cm
300
cm
0.3-10
bar
0.4
bar
2800
RPM
3000
RPM
20 - 40
RPM
25 - 35
RPM
45 - 65
RPM
