Getting Started - Targa external network hard disk User Manual

English

Getting Started

Please read this user manual before using the device for the first time. This prevents
incorrect operation and use. Unpack the Targa DataBox NDAS 500 eSATA and keep
the packaging.
Front view
1
2
1 LED indicator (Power on = blue, HDD access = orange)
2 On/Off button
3 USB port
4 eSATA connector
5 Network connection
6 Connection for external power adapter
7
Power adapter [A]
7 Connector for Targa DataBox NDAS 500 eSATA
(Depending on the country version of your power supply, the item
shown in the illustration may differ from the original version.)
8 USB connector for Targa DataBox NDAS 500 eSATA
9 USB connector for PC
10 Network cable (both connectors are identical)
11 eSATA cable (both connectors are identical)
8
8 9
USB cable [B]
Targa NDAS 500 eSATA
Back view
4
3
10
Network cable [C]
5 6
11
eSATA cable [D]
