Zip Hydroboil
Filtered instant boiling water
01512 Zip Hydroboil 1.5 Litre White
01511 Zip Hydroboil 1.5 Litre Stainless Steel
03512 Zip Hydroboil 3 Litre White
03511 Zip Hydroboil 3 Litre Stainless Steel
05512 Zip Hydroboil 5 Litre White
05511 Zip Hydroboil 5 Litre Stainless Steel
07512 Zip Hydroboil 7.5 Litre White
07511 Zip Hydroboil 7.5 Litre Stainless Steel
81446 - February 2005
Installation and Operating Instructions
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zip Hydroboil 01512
Summary of Contents for Zip Hydroboil 01512
- Page 1 Installation and Operating Instructions ® Zip Hydroboil Filtered instant boiling water 01512 Zip Hydroboil 1.5 Litre White 01511 Zip Hydroboil 1.5 Litre Stainless Steel 03512 Zip Hydroboil 3 Litre White 03511 Zip Hydroboil 3 Litre Stainless Steel 05512 Zip Hydroboil 5 Litre White 05511 Zip Hydroboil 5 Litre Stainless Steel 07512 Zip Hydroboil 7.5 Litre White...
- Page 2 Page 2 of 12 Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005...
-
Page 3: Table Of Contents
Read all instructions and precautions before proceeding. This unit must be installed in accordance with water supply by-laws, current IEC regulations and relevant local authority by-laws. Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005 Page 3 of 12... -
Page 4: Read These Warnings First
All plumbing connections must be made in accordance with local regulations. The Zip Hydroboil instant boiling water heater is not intended for use by young children or infirm people without supervision. Young children should be prevented from having access to ensure that they are not able to use or play with the heater. -
Page 5: Installation Procedures
Approximate Weight When Filled 1.5 Litre models 10 kg 3.0 Litre models 12.5 kg 5.0 Litre models 16.5 kg 7.5 Litre models 20.5 kg Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005 Page 5 of 12... -
Page 6: A) Plumbing
Minimum - 1 bar (100 kPa). Maximum - 7 bar (700 kpa). Warning: If pressure is likely to exceed 7 bar (700 kpa), a pressure limiting valve must be installed in the cold water supply line. Zip recommends a valve rated at 3.5 bar (350 kpa) for this application. -
Page 7: Wall Mounting Template Dimensions & Electrical Diagram
318 5.O L 416 3.O L 448 5.O L 561 7.5 L POSITIONING PIN COLD EXTERNAL PLUMBING VENT INLET ELECTRICAL WIRING POSITION INTERNAL PLUMBING BENCH TOP Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005 Page 7 of 12... -
Page 8: Problem Solving
Warning- the water may be boiling - show extra care. 5. Test that in every instance the electrical resistance does not exceed 1 ohm. Page 8 of 12 Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005... -
Page 9: Operating Procedures
Operating Procedures Tap Operation Boiling water Zip Hydroboil is fitted with a two-way cool-touch safety tap for filtered instant boiling water. For filtered instant boiling water, gently press the lower end of the tap paddle inwards. Boiling water will flow until the tap paddle is released. -
Page 10: Spare Parts
Tank welded 7.5L Kit 90146 Insulation Kit 1.5L 90147 Insulation Kit 3.0L 90148 Insulation Kit 5.0L 90149 Insulation Kit 7.5L 90130 Clips for Curled Tank Kit Page 10 of 12 Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005... - Page 11 Spare Parts 11 10 12 19 8 23 9 1 20 21 Zip Hydroboil - Installation & Operating Instructions - 81446 - February 2005 Page 11 of 12...
-
Page 12: Contact Details
Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip's option to the replacement of the appliance or...
