Altronix Vertiline CCTV Rack Mount Power Supplies provide 8 power outputs in a space saving 1U EIA 19" rack mount
chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC and/or 28VAC power
outputs with surge suppression. Vertiline CCTV Rack Mount Power Supplies are also available in sixteen (16) and twenty-
four (24) output models with various power ratings.
• Selectable 115VAC 60 Hz/230VAC 50/60 Hz input.
• Eight (8) individually selectable 24VAC or 28VAC
power outputs with OFF position.
• Eight (8) power LED indicators.
• External blade fuses or PTC protected outputs.
• Surge suppression.
• Illuminated power disconnect circuit breaker with
manual reset.
Eight (8) Output Rack Mount Configuration Reference Chart:
Altronix
Model
Number
24VAC or
Vertiline8
28VAC
Vertiline8D 24VAC or
28VAC
24VAC or
28VAC 10 amp 8 Fused
Vertiline83
Vertiline83D 24VAC or
28VAC 10 amp 8
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should conform to
all local codes and in accordance with the National Electrical Code.
1. Set the input voltage selector switch located on the left side of the Vertiline unit (facing front panel) for
115VAC or 230VAC operation (Fig. 1c, pg. 4).
2. Attach mounting brackets to Vertiline unit for rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to
Vertiline for shelf installation (Fig. 6, pg. 7).
3. Secure the unit in a rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at least
3" from any video monitors). When installing the unit in a rack allow for one half of a U spacing above the unit
for ventilation.
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the Vertiline unit (Fig. 1f, pg. 4).
Insert the plug end of the line cord into a grounded AC receptacle.
5. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 3, pg. 6).
6. Select 24VAC or 28VAC power output for cameras 1-8 with the corresponding voltage adjustment switches
(Fig. 1b, pg. 4).
7. Measure output voltage before connecting cameras. This helps avoid potential damage.
All terminals with common suffix (P) "1P, 2P ..." are the same polarity.
8. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 3, pg. 6).
- 2 -
5 amp 8 Fused --
5 amp 8 -- PTC 2.5 amp
--
-- PTC 2.5 amp

Installation Instructions:

Overview:

Specifications:

• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking screw flange.
• Ease of installation saves time and eliminates costly labor.
• Compact 1U rack mount chassis.
• Fits standard EIA 19" rack.
• Units can be rack, wall or shelf mounted.
3 amp 3 amp
10 amp 1.5 amp .8 amp
- -
3 amp 3 amp
15 amp 3 amp 1.5 amp
- -
UL Listed for
Commercial
CCTV Equipment
(UL 2044).
Vertiline8
