Congratulations on purchasing a MDB Family product. This crib will provide many years of service if you
adhere to the following guidelines for assembly, maintenance, and operation. This crib is for residential use
only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assem-
bling the crib in addition to the Allen wrench included in the hardware box. Do not use power screwdrivers.
All of our cribs are made from natural woods. Please understand that natural woods have color variations
which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARD-
WARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC
VARIATIONS.
* This crib can later be converted into a
toddler bed or a full-size bed. To convert
to a toddler bed, turn to page 7. To con-
vert to a full-size bed, turn to page 8.
revised 19OCT2011
Crib (7201) - Assembly and Operation Manual
page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MDB Crib (7201)
Summary of Contents for MDB Crib (7201)
- Page 1 Crib (7201) - Assembly and Operation Manual Congratulations on purchasing a MDB Family product. This crib will provide many years of service if you adhere to the following guidelines for assembly, maintenance, and operation. This crib is for residential use only.
- Page 2 PARTS A. Back Panel B. Front Panel E-1. Right E-2. Left Back Post Back Post C. Right Side Panel D. Left Side Panel F-1. Right F-2. Left Front Post Front Post G. Spring Frame H. Guardrail HARDWARE H1. 3-1/2" Allen Head H2.
-
Page 3: Tools Needed
Tools Needed (not included) H7. Barrel Nut (12) H8. Allen wrench Phillips Screwdriver Guard rail hardware : H9. 2" Allen Head H10. Lock washer (4) Bolt (4) STEP 1. Insert two barrel nuts (H7) to each side panels (C and D). Attach posts (E-1, F-1) to right side panel (C) using two 2-1/2”... - Page 4 STEP 2. Insert four barrel nuts (H7) to the back panel (A). Attach the back panel (A) to the left side panel and right side panel assemblies using four 3-1/2” Allen head bolts (H1) and lock washers (H6). Use the Allen wrench (H8) to tighten the bolts securely.
-
Page 5: Sample Label
STEP 4. Insert four barrel nuts (H7) to the front panel (B). Attach the front panel (B) to the crib assembly using four 3-1/2” Allen head bolts (H1) and lock washers (H6). Use the Allen wrench (H8) to tighten the bolts securely. -
Page 6: One-Year Limited Warranty
DO NOT substitute parts. Contact a soft rag. Rinse and dry thoroughly. If you ever MDB FAMILY for replacement parts and instructional literature if needed. refinish this furniture, be sure to use only a non-toxic •... - Page 7 Crib (7201) - Daybed Conversion Assembly All of the parts and hardware you will need are supplied with the crib at the time of purchase. STEP 1. Unscrew the 3-1/2" Allen head bolts (H1) and lock washers (H6) and remove the front panel (B). STEP 2.
- Page 8 The intended user’s minimum age must be at least 15 months old and maximum weight must not exceed 50 lbs (22.7 kg). WARNING : Failure to follow these warnings and the assembly instructions could result in serious injury or death from entrapment or strangulation. DO NOT place bed near windows where cords from blinds or drapes may strangle a child.
- Page 9 STEP 2. STEP 1. Remove the crib sides and spring frame. Use the Allen head bolts (D) to attach the Left (E) and Right (F) brackets to the front panel posts. Right post and bracket are shown. STEP 3. STEP 4. Attach the rails to the brackets with the screws Attach the rails to the headboard with the (C) and tighten securely with a Phillips head...
