INTRODUCTION
This service manual describes the latest technical
information for the IC-R6 COMMUNICATIONS RECEIVER,
at the time of publication.
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without notice
or obligation.
MODEL VERSION
EUR
UK
CHN
ITA
USA
FRA
ESP
EXP
IC-R6
CAN
EUR-01
CHN-01
ITA-01
USA-01
FRA-01
ESP-01
CAN-01
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1110007300 NJM2552V
8210026030 3250 REAR PANEL
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
SUPPLIED
BATTERY CHARGER
–
BC-196SD
BC-153SC
BC-196SD
BC-196SA
BC-196SD
BC-196SA
IC-R6 RF UNIT 2 pieces
IC-R6 CHASSIS 3 pieces
CAUTION
NEVER connect the receiver to an AC outlet or to a DC
power supply that uses more than specified. This will ruin
the transceiver.
DO NOT expose the receiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the receiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the receiver's
front-end.
REPAIR NOTES
1. Make sure that the problem is internal before
disassembling the receiver.
2. DO NOT open the receiver until the receiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
receiver is defective.
6. READ the instructions of test equipment throughly
before connecting a test equipment to the receiver.
An
